IOE Model Questions 2080
The 19 sample questions IOE published with the 2080 entrance syllabus to show the question style. Section A questions carry 1 mark and Section B questions 2 marks. The worked answers are ours.
Section A · 1 mark each
1. The value of k for which one root of the equation 3x² + 7x + 6 − k = 0 is equal to zero is
IOE model question 2080Show hintHide hint
Put x = 0 in the equation.
Show answerHide answer
Answer: D. 6
If x = 0 is a root, substituting gives 6 − k = 0, so k = 6.
2. If the line x + y − 1 = 0 touches the parabola y² = kx, then the value of k is
IOE model question 2080Show hintHide hint
Substitute the line into the parabola and set the discriminant to zero.
Show answerHide answer
Answer: D. −4
Put x = 1 − y: y² = k(1 − y), so y² + ky − k = 0. Tangency needs a zero discriminant: k² + 4k = 0, so k = 0 or k = −4. k = 0 is not a parabola, so k = −4.
3. The derivative of sech⁻¹x is valid for
IOE model question 2080Show hintHide hint
Where is 1/(x√(1 − x²)) defined?
Show answerHide answer
Answer: B. x < 1
The official options don't include the exact condition 0 < x < 1; “x < 1” is the closest.
d/dx (sech⁻¹x) = −1/(x√(1 − x²)), which is defined only for 0 < x < 1. Of the options, x < 1 is the one that fits (strictly the condition is 0 < x < 1).
4. The integrating factor of the differential equation dy/dx + (x/(1 + x))y = 1 + x is
IOE model question 2080Show hintHide hint
Write x/(1 + x) as 1 − 1/(1 + x) before integrating.
Show answerHide answer
Answer: B. eˣ/(1 + x)
IF = e^(∫x/(1 + x) dx) = e^(∫(1 − 1/(1 + x)) dx) = e^(x − ln(1 + x)) = eˣ/(1 + x).
8. Two ice blocks when pressed together join to form one block, because
IOE model question 2080Show hintHide hint
Think of regelation.
Show answerHide answer
Answer: B. melting point falls with pressure
Pressure lowers the melting point of ice, so the ice at the contact melts; when the pressure is released the water refreezes and joins the blocks (regelation).
9. If you are given three equal resistors, how many different combinations of these resistors are possible?
IOE model question 2080Show hintHide hint
List series, parallel and the two mixed arrangements.
Show answerHide answer
Answer: C. 4
Using all three: all in series (3R), all in parallel (R/3), two in series with the third in parallel (2R/3), and two in parallel with the third in series (3R/2): four combinations.
12. Any p-orbital can accommodate up to
IOE model question 2080Show hintHide hint
One orbital, not the whole subshell.
Show answerHide answer
Answer: D. two electrons with anti-parallel spins
Each orbital (one of px, py, pz) holds at most two electrons, and by Pauli's exclusion principle they must have opposite spins. Six is the capacity of the whole p subshell.
14. In Williamson’s synthesis, a haloalkane is treated with
IOE model question 2080Show hintHide hint
It is a method of making ethers.
Show answerHide answer
Answer: C. sodium alkoxide
Williamson ether synthesis: R–X + R′–ONa → R–O–R′ + NaX, an SN2 reaction of a haloalkane with sodium alkoxide.
16. He is one person I count ………… in times of difficulty.
IOE model question 2080Show hintHide hint
Which preposition makes “count” mean “rely”?
Show answerHide answer
Answer: D. on
“Count on someone” means to rely on them.
17. Which of the following pairs have the same initial vowel sound?
IOE model question 2080Show hintHide hint
Look for the unstressed schwa.
Show answerHide answer
Answer: A. ago, alone
Both ago /əˈɡəʊ/ and alone /əˈləʊn/ begin with the schwa /ə/. inn /ɪ/ vs eel /iː/, owl /aʊ/ vs all /ɔː/, up /ʌ/ vs on /ɒ/ differ.
18. The word ‘procrastination’ has its stress on the ………… syllable.
IOE model question 2080Show hintHide hint
-tion words stress the syllable before -tion.
Show answerHide answer
Answer: C. 4th
pro-cras-ti-NA-tion /prəˌkræstɪˈneɪʃn/: words ending in -tion are stressed on the syllable just before the ending, which is the 4th here.
Section B · 2 marks each
5. If a⃗ = i + 2j + 3k and b⃗ = 2i + 3j − 2k, then the projection of b⃗ on a⃗ is
IOE model question 2080Show hintHide hint
Use (a·b)/|a|.
Show answerHide answer
Answer: A. 2/√14 or C. √(2/7)
2/√14 and √(2/7) are the same number, so options A and C are both correct as printed in the official model set.
Projection of b on a = (a·b)/|a| = (2 + 6 − 6)/√(1 + 4 + 9) = 2/√14.
6. If a lottery ticket is drawn at random from a lottery box containing 10 prizes and 25 blanks, what is the probability of getting a prize?
IOE model question 2080Show hintHide hint
Favourable over total tickets.
Show answerHide answer
Answer: C. 2/7
There are 10 + 25 = 35 tickets, 10 of them prizes: P = 10/35 = 2/7.
7. To what depth below the surface of a sea should a rubber ball be taken so that its volume decreases by 1%? Bulk modulus of rubber is 9 × 10⁸ N m⁻². (Take density of sea water 1000 kg/m³ and g = 10 m/s².)
IOE model question 2080Show hintHide hint
Pressure needed = B × (ΔV/V), then h = P/(ρg).
Show answerHide answer
Answer: D. 1 km
The exact depth is about 900 m; “1 km” is the nearest option.
ΔV/V = P/B, so P = 0.01 × 9 × 10⁸ = 9 × 10⁶ Pa. Depth h = P/(ρg) = 9 × 10⁶/(1000 × 10) = 900 m, which is about 1 km.
10. The ratio of the areas within the electron orbits for the first excited state to the ground state for the hydrogen atom is
IOE model question 2080Show hintHide hint
r ∝ n² and area ∝ r².
Show answerHide answer
Answer: A. 16 : 1
Bohr radius rₙ ∝ n², so area ∝ r² ∝ n⁴. For n = 2 vs n = 1: 2⁴ : 1⁴ = 16 : 1.
11. 21 g of magnesium carbonate was treated with 50 mL of 12 N hydrochloric acid. How many molecules of unreacted hydrochloric acid remain?
IOE model question 2080Show hintHide hint
Find the HCl used by 0.25 mol MgCO₃ and subtract.
Show answerHide answer
Answer: B. 6.025 × 10²²
MgCO₃ (M = 84): 21/84 = 0.25 mol, which needs 0.5 mol HCl (MgCO₃ + 2HCl → MgCl₂ + H₂O + CO₂). HCl taken = 0.050 L × 12 = 0.6 mol. Left over = 0.1 mol = 0.1 × 6.025 × 10²³ = 6.025 × 10²² molecules.
13. What mass of copper will be deposited by passing 2 faradays of electricity through a solution of a copper(II) salt?
IOE model question 2080Show hintHide hint
How many faradays does one mole of Cu²⁺ need?
Show answerHide answer
Answer: C. 63.5 g
Cu²⁺ + 2e⁻ → Cu: 2 F deposit 1 mol of copper = 63.5 g.
15. It …… two weeks since he left the city.
IOE model question 2080Show hintHide hint
The time runs from the past up to now.
Show answerHide answer
Answer: C. has been
A period of time from a past point up to now takes the present perfect: “It has been two weeks since…”.
Read the passage, then answer the questions below
19. In the English language, the animals are
IOE model question 2080Show hintHide hint
Look at the adjectives the passage lists.
Show answerHide answer
Answer: B. used for unpleasant comparisons
The passage says English ‘transfers negative human traits to animals’ and gives the language ‘as many unpleasant adjectives as it could possibly want’.
