Nepal Engineering Council · Electronics & Communication Engineering · Chapter 8
Signal System and Digital Signal Processing
Tap an option to check it. Wrong picks show the right answer and the hint.
181 questions in 6 syllabus topics.
8.1 Signal and system
31 questions · AExE0801
1. A signal is best defined as:
Show hintHide hint
Think of what a microphone voltage or an image represents.
Show answerHide answer
Answer: A. A function of one or more independent variables that conveys information about a physical phenomenon
A signal is a function of independent variables (time, space, etc.) carrying information; a system is what processes it.
2. What is the total energy of the signal x(t) = e^(−2t)·u(t)?
Show hintHide hint
Square the signal before integrating.
Show answerHide answer
Answer: B. 0.25 J
E = ∫₀^∞ e^(−4t) dt = 1/4 = 0.25 J.
3. What is the average power of x(t) = 5 cos(100πt + π/3)?
Show hintHide hint
Average power of a sinusoid depends only on its amplitude.
Show answerHide answer
Answer: C. 12.5 W
For A cos(ωt + φ), the average power is A²/2 = 25/2 = 12.5 W; the phase does not matter.
4. What is the fundamental period of the discrete-time signal x[n] = cos(3πn/8)?
Show hintHide hint
N must be an integer, so find the smallest k that makes 16k/3 whole.
Show answerHide answer
Answer: D. 16 samples
N = 2πk/ω₀ = 16k/3; the smallest integer N occurs for k = 3, giving N = 16.
5. The discrete-time signal x[n] = cos(2n) is:
Show hintHide hint
A period in discrete time must be an integer number of samples.
Show answerHide answer
Answer: A. Not periodic, because ω₀/2π = 1/π is irrational
A discrete sinusoid is periodic only if ω₀/2π is a rational number; 2/(2π) = 1/π is irrational.
6. What is the value of ∫ (t² + 3)·δ(t − 2) dt taken over all time?
Show hintHide hint
The impulse picks out the value of the other factor at one instant.
Show answerHide answer
Answer: C. 7
By the sifting property the integral equals (t² + 3) at t = 2, i.e. 4 + 3 = 7.
7. The scaled impulse δ(2t) is equal to:
Show hintHide hint
Compare the areas under δ(2t) and δ(t).
Show answerHide answer
Answer: D. 0.5 δ(t)
δ(at) = δ(t)/|a|, so δ(2t) = δ(t)/2.
8. The unit step u(t) is related to the unit impulse δ(t) by:
Show hintHide hint
Think about the area accumulated by an impulse as time passes t = 0.
Show answerHide answer
Answer: B. u(t) is the running integral of δ(t)
u(t) = ∫ from −∞ to t of δ(τ) dτ, equivalently δ(t) = du(t)/dt.
9. The normalised sinc function sinc(x) = sin(πx)/(πx) has value 1 at x = 0 and is zero at:
Show hintHide hint
Where does sin(πx) vanish?
Show answerHide answer
Answer: D. All non-zero integer values of x
sin(πx) = 0 when x is an integer; at x = 0 the limit is 1, so the zeros are at x = ±1, ±2, ...
10. The signum function sgn(t) can be written in terms of the unit step as:
Show hintHide hint
Check the value of your expression for positive and for negative t.
Show answerHide answer
Answer: B. 2u(t) − 1
sgn(t) = +1 for t > 0 and −1 for t < 0, which equals 2u(t) − 1.
11. If x[n] = {1, 2, 1} (starting at n = 0) is applied to an LTI system with h[n] = {1, 1}, the output y[n] is:
Show hintHide hint
The output length is N₁ + N₂ − 1.
Show answerHide answer
Answer: C. {1, 3, 3, 1}
Linear convolution: y[0]=1, y[1]=2+1=3, y[2]=1+2=3, y[3]=1; the length is 3+2−1 = 4.
12. The convolution of the unit step with itself, u(t) * u(t), is:
Show hintHide hint
Convolving with u(t) is the same as integrating.
Show answerHide answer
Answer: C. t·u(t), the unit ramp
u(t)*u(t) = ∫₀^t 1 dτ = t for t ≥ 0, i.e. the unit ramp r(t) = t·u(t).
13. For an LTI system, the output for any input is completely determined by:
Show hintHide hint
Which single response lets you compute the output by convolution?
Show answerHide answer
Answer: B. Its impulse response
y(t) = x(t) * h(t); the impulse response fully characterises an LTI system.
14. Which of the following systems is linear and time-invariant?
Show hintHide hint
Test each one for additivity and for the effect of a shifted input.
Show answerHide answer
Answer: A. y(t) = 3 x(t − 2)
3x(t−2) is a scaled delay (LTI). x+2 fails homogeneity, t·x(t) and x(2t) are time-varying.
15. A real periodic signal has odd symmetry and half-wave symmetry (like a square wave centred on t = 0). Its trigonometric Fourier series contains:
Show hintHide hint
Apply the two symmetry rules one after the other.
Show answerHide answer
Answer: D. Only sine terms of odd harmonics
Odd symmetry removes a₀ and cosine terms; half-wave symmetry removes even harmonics, leaving odd-harmonic sines.
16. A periodic signal is x(t) = 3 + 4 cos(ω₀t) + 2 sin(3ω₀t). Its average power is:
Show hintHide hint
DC power is A², each sinusoid contributes A²/2.
Show answerHide answer
Answer: D. 19 W
By Parseval: P = 3² + 4²/2 + 2²/2 = 9 + 8 + 2 = 19 W.
17. Near a jump discontinuity, the partial sum of a Fourier series overshoots by about 9% of the jump no matter how many terms are taken. This is called:
Show hintHide hint
The effect is named after a physicist who explained it in 1899.
Show answerHide answer
Answer: B. Gibbs phenomenon
The persistent ≈9% overshoot near discontinuities is Gibbs phenomenon.
18. Which property holds for the exponential Fourier series coefficients cₖ of a real, even periodic signal?
Show hintHide hint
Combine conjugate symmetry with even symmetry.
Show answerHide answer
Answer: D. cₖ are real and even in k
A real signal gives c₋ₖ = cₖ*; even symmetry makes the coefficients real, so they are real and even.
19. The Fourier transform of x(t) = e^(−at)·u(t), a > 0, is:
Show hintHide hint
Combine the two exponents and integrate from 0 to ∞.
Show answerHide answer
Answer: C. 1/(a + jω)
X(ω) = ∫₀^∞ e^(−at) e^(−jωt) dt = 1/(a + jω).
20. The Fourier transform of the signum function sgn(t) is:
Show hintHide hint
The signum has zero average value, so no impulse at ω = 0.
Show answerHide answer
Answer: A. 2/(jω)
sgn(t) is the limit of e^(−a|t|)sgn(t); its transform tends to 2/(jω). Note u(t) = (1 + sgn t)/2 gives πδ(ω) + 1/(jω).
21. A rectangular pulse of width 2 ms is centred at t = 0. Its amplitude spectrum has the first zero crossing at:
Show hintHide hint
Nulls of the sinc occur at multiples of 1/T.
Show answerHide answer
Answer: A. 500 Hz
The transform is A·T·sinc(fT); the first null is at f = 1/T = 1/0.002 = 500 Hz.
22. A signal x(t) is band-limited to 4 kHz. The bandwidth of x(3t) is:
Show hintHide hint
Compression in time means expansion in frequency.
Show answerHide answer
Answer: B. 12 kHz
x(at) ↔ (1/|a|)X(ω/a); compressing time by 3 expands the spectrum by 3, giving 12 kHz.
23. Delaying a signal by t₀ seconds changes its Fourier transform X(ω) to:
Show hintHide hint
A delay should not change the magnitude spectrum.
Show answerHide answer
Answer: A. X(ω)·e^(−jωt₀)
The time-shift property: x(t − t₀) ↔ X(ω)e^(−jωt₀); only the phase changes.
24. The impulse response of an ideal Hilbert transformer is h(t) = 1/(πt). Its effect on the input spectrum is:
Show hintHide hint
Write the Hilbert transformer's frequency response as −j times something.
Show answerHide answer
Answer: D. A −90° phase shift for positive frequencies and +90° for negative frequencies, with unchanged magnitude
H(ω) = −j·sgn(ω): magnitude 1, phase −90° for ω > 0 and +90° for ω < 0.
25. The Hilbert transform of cos(ω₀t) is:
Show hintHide hint
Shift the cosine by −90°.
Show answerHide answer
Answer: A. sin(ω₀t)
A −90° shift of cos(ω₀t) gives cos(ω₀t − 90°) = sin(ω₀t).
26. According to the Wiener–Khinchin theorem, the power spectral density of a wide-sense stationary signal is:
Show hintHide hint
It links a time-domain correlation to a frequency-domain density.
Show answerHide answer
Answer: B. The Fourier transform of its autocorrelation function
Sₓ(f) = F{Rₓ(τ)} for a WSS process (Wiener–Khinchin).
27. The energy spectral density of x(t) = e^(−2t)·u(t) at ω = 0 is:
Show hintHide hint
ESD is the squared magnitude of the Fourier transform.
Show answerHide answer
Answer: B. 0.25
Ψ(ω) = |X(ω)|² = 1/(4 + ω²); at ω = 0 it is 1/4 = 0.25.
28. The DTFT X(e^jω) of any discrete-time sequence is always:
Show hintHide hint
Consider e^(−jωn) when ω increases by 2π.
Show answerHide answer
Answer: C. Periodic in ω with period 2π
Because e^(−j(ω+2π)n) = e^(−jωn) for integer n, X(e^jω) repeats every 2π.
29. For x[n] = (0.5)ⁿ·u[n], the value of its DTFT at ω = 0 is:
Show hintHide hint
At ω = 0 the DTFT is simply the sum of all samples.
Show answerHide answer
Answer: C. 2
X(e^jω) = 1/(1 − 0.5e^(−jω)); at ω = 0 it is 1/(1 − 0.5) = 2 (also the sum of the samples).
30. A periodic impulse train x[n] with period N = 4 has x[0] = 1 and x[1] = x[2] = x[3] = 0 in each period. Its DTFS coefficients aₖ (with the 1/N factor in the analysis equation) are:
Show hintHide hint
Only the n = 0 term survives in the sum.
Show answerHide answer
Answer: C. aₖ = 1/4 for every k
aₖ = (1/N) Σ x[n]e^(−j2πkn/N) = (1/4)·1 = 1/4 for k = 0,1,2,3.
31. A discrete-time periodic signal with fundamental period N has how many distinct Fourier series coefficients?
Show hintHide hint
Discrete-time complex exponentials repeat after N harmonics.
Show answerHide answer
Answer: A. N
The DTFS coefficients are themselves periodic with period N, so only N are distinct.
8.2 Linear time invariant system
30 questions · AExE0802
32. In ideal (impulse-train) sampling at rate fs, the spectrum of the sampled signal consists of:
Show hintHide hint
Multiplication in time is convolution in frequency.
Show answerHide answer
Answer: B. The original spectrum repeated at every integer multiple of fs, scaled by 1/Ts
Multiplying by an impulse train convolves the spectrum with an impulse train in frequency, giving copies at k·fs with weight 1/Ts.
33. What is the Nyquist rate for x(t) = cos(400πt) + sin(1000πt)?
Show hintHide hint
Convert each ω to f first and keep the largest.
Show answerHide answer
Answer: A. 1000 Hz
The components are at 200 Hz and 500 Hz; the Nyquist rate is twice the highest frequency, 2 × 500 = 1000 Hz.
34. A speech signal band-limited to 3.4 kHz is sampled at its Nyquist rate. The maximum sampling interval is approximately:
Show hintHide hint
Sampling interval is the reciprocal of the sampling rate.
Show answerHide answer
Answer: C. 147 µs
Nyquist rate = 6.8 kHz, so Ts = 1/6800 ≈ 147 µs.
35. A 7 kHz sinusoid is sampled at 10 kHz without an anti-aliasing filter. After ideal reconstruction (cutoff fs/2), the output frequency is:
Show hintHide hint
Fold the frequency about fs/2.
Show answerHide answer
Answer: C. 3 kHz
7 kHz exceeds fs/2 = 5 kHz, so it aliases to |7 − 10| = 3 kHz.
36. A signal x(t) is band-limited to 3 kHz. The minimum sampling rate for y(t) = x²(t) is:
Show hintHide hint
What does multiplication in time do to the bandwidth?
Show answerHide answer
Answer: A. 12 kHz
Squaring convolves the spectrum with itself, doubling the bandwidth to 6 kHz; Nyquist rate = 12 kHz.
37. The main purpose of an anti-aliasing filter placed before an A/D converter is to:
Show hintHide hint
It acts before sampling, not after.
Show answerHide answer
Answer: C. Limit the input bandwidth to below half the sampling rate
An analog low-pass filter before sampling removes components above fs/2 that would otherwise alias.
38. A system is time-invariant if:
Show hintHide hint
Compare the response to a delayed input with the delayed response.
Show answerHide answer
Answer: B. A time shift of the input causes an identical time shift of the output
Time invariance: x(t − t₀) → y(t − t₀) for every t₀.
39. For a continuous-time LTI system, which condition guarantees BIBO stability?
Show hintHide hint
The test uses the absolute value of h(t).
Show answerHide answer
Answer: C. ∫|h(t)| dt over all t is finite
An LTI system is BIBO stable if and only if its impulse response is absolutely integrable.
40. An LTI system has h[n] = (0.5)ⁿ·u[n]. Which statement is correct?
Show hintHide hint
Sum the geometric series of |h[n]|.
Show answerHide answer
Answer: A. It is causal and stable, since Σ|h[n]| = 2
h[n] = 0 for n < 0 (causal) and Σ(0.5)ⁿ = 1/(1 − 0.5) = 2 is finite (stable).
41. For stability of a causal LTI system, all poles of the transfer function must lie:
Show hintHide hint
The jω-axis maps onto the unit circle.
Show answerHide answer
Answer: D. In the left half of the s-plane for continuous time, and inside the unit circle of the z-plane for discrete time
Causal CT stability needs Re(poles) < 0; causal DT stability needs |poles| < 1.
42. Two LTI systems with impulse responses h₁(t) and h₂(t) are connected in cascade. The overall impulse response is:
Show hintHide hint
In frequency it is the product of H₁ and H₂.
Show answerHide answer
Answer: D. h₁(t) * h₂(t)
A cascade of LTI systems has the convolution of the impulse responses (product of frequency responses).
43. An LTI system with impulse response h(t) = K·δ(t) is:
Show hintHide hint
Does the output depend on past input values?
Show answerHide answer
Answer: D. Memoryless
The output y(t) = K·x(t) depends only on the present input, so the system has no memory.
44. The complex exponential e^(jω₀t) applied to an LTI system produces the output H(jω₀)e^(jω₀t). For this reason complex exponentials are called:
Show hintHide hint
The input shape is preserved; only a complex scale factor appears.
Show answerHide answer
Answer: C. Eigenfunctions of LTI systems
The output is the same exponential scaled by the eigenvalue H(jω₀), so e^(jω₀t) is an eigenfunction.
45. For the system y[n] = 0.5(x[n] + x[n − 1]), what is |H(e^jω)| at ω = π/2?
Show hintHide hint
Factor out e^(−jω/2) to get a cosine.
Show answerHide answer
Answer: C. 0.707
H(e^jω) = 0.5(1 + e^(−jω)) ⇒ |H| = |cos(ω/2)| = cos(π/4) ≈ 0.707.
46. The system y[n] = 0.5(x[n] + x[n − 1]) behaves as a:
Show hintHide hint
Evaluate the gain at DC and at the highest digital frequency.
Show answerHide answer
Answer: B. Low-pass filter with a null at ω = π
|H| = |cos(ω/2)| equals 1 at ω = 0 and 0 at ω = π, so it passes low frequencies.
47. An RC low-pass filter has R = 1 kΩ and C = 1 µF. Its 3 dB cutoff frequency is about:
Show hintHide hint
RC is the time constant; convert rad/s to Hz.
Show answerHide answer
Answer: C. 159 Hz
fc = 1/(2πRC) = 1/(2π × 10⁻³) ≈ 159 Hz.
48. A signal cos(t) is applied to an LTI system with H(jω) = 1/(1 + jω). The output is:
Show hintHide hint
Evaluate H at the input frequency.
Show answerHide answer
Answer: D. 0.707 cos(t − 45°)
At ω = 1: |H| = 1/√2 ≈ 0.707 and ∠H = −45°, so y(t) = 0.707 cos(t − 45°).
49. For distortionless transmission through an LTI system, the frequency response must have:
Show hintHide hint
The output may be scaled and delayed, nothing else.
Show answerHide answer
Answer: D. Constant magnitude and phase varying linearly with frequency
y(t) = K·x(t − t_d) requires H(ω) = K e^(−jωt_d): flat magnitude, linear phase.
50. A system has a phase response θ(ω) = −0.002ω rad over its passband. The delay experienced by signals is:
Show hintHide hint
Differentiate the phase with respect to ω.
Show answerHide answer
Answer: B. 2 ms
Group delay = −dθ/dω = 0.002 s = 2 ms.
51. The impulse response of an ideal low-pass filter with cutoff ωc (zero phase) is:
Show hintHide hint
Use duality between rectangle and sinc.
Show answerHide answer
Answer: B. h(t) = sin(ωc t)/(πt), a sinc pulse extending over all time
The inverse Fourier transform of a rectangular frequency response is a sinc function, extending from −∞ to ∞.
52. An ideal low-pass filter has cutoff fc = 1 kHz and unity passband gain. The peak value of its impulse response h(0) is:
Show hintHide hint
h(0) equals the area under the frequency response.
Show answerHide answer
Answer: D. 2000
h(t) = 2fc·sinc(2fc t), so h(0) = 2fc = 2000 (equal to the area under H(f)).
53. An ideal low-pass filter is not physically realizable because:
Show hintHide hint
Look at when the impulse response starts.
Show answerHide answer
Answer: A. Its impulse response is non-zero for t < 0, so it is non-causal
The sinc impulse response exists for negative time; a causal filter cannot have a brick-wall magnitude (Paley–Wiener criterion).
54. The step response of an ideal low-pass filter shows:
Show hintHide hint
Integrating a sinc gives the sine-integral function.
Show answerHide answer
Answer: B. An overshoot of about 9% with ripples, and a rise time inversely proportional to the bandwidth
The step response is the sine-integral function; Gibbs effect gives ≈9% overshoot, and wider bandwidth gives faster rise.
55. An LTI system has h(t) = e^(−t)·u(t). Its unit step response at t = 1 s is approximately:
Show hintHide hint
The step response is the running integral of the impulse response.
Show answerHide answer
Answer: A. 0.632
s(t) = ∫₀^t e^(−τ)dτ = 1 − e^(−t); s(1) = 1 − 0.368 = 0.632.
56. The impulse response of the system y[n] = x[n] − x[n − 2] is:
Show hintHide hint
Replace x[n] by δ[n].
Show answerHide answer
Answer: B. {1, 0, −1}
Setting x[n] = δ[n]: h[n] = δ[n] − δ[n − 2] = {1, 0, −1} starting at n = 0.
57. Which of the following discrete-time systems is time-variant?
Show hintHide hint
Look for a coefficient that depends explicitly on time.
Show answerHide answer
Answer: B. y[n] = n·x[n]
In y[n] = n·x[n] the coefficient depends on n, so a shifted input does not give a shifted output.
58. Which basic elements are required to implement a discrete-time LTI system from its difference equation?
Show hintHide hint
Look at the operations appearing in a difference equation.
Show answerHide answer
Answer: A. Adders, constant multipliers and unit delays
Any linear constant-coefficient difference equation can be realised with adders, gain multipliers and z⁻¹ delay elements.
59. A causal system is described by y[n] = a₁y[n−1] + a₂y[n−2] + b₀x[n] + b₁x[n−1] + b₂x[n−2]. What is the minimum number of delay elements needed (canonic form)?
Show hintHide hint
The canonic structure uses as many delays as the system order.
Show answerHide answer
Answer: D. 2
Direct form II (canonic) shares delays between the feedback and feedforward parts, needing max(N, M) = 2 delays.
60. To reconstruct a band-limited signal (bandwidth W) from its samples taken at fs > 2W, the ideal reconstruction filter is a low-pass filter whose cutoff lies:
Show hintHide hint
Sketch the baseband spectrum and its first image.
Show answerHide answer
Answer: A. Between W and fs − W
The cutoff must pass the baseband spectrum (up to W) and reject the first image starting at fs − W.
61. Flat-top sampling, compared with ideal sampling, introduces:
Show hintHide hint
The holding pulse acts like a filter.
Show answerHide answer
Answer: A. Aperture effect: high-frequency attenuation caused by the sinc-shaped spectrum of the holding pulse
Holding each sample for a pulse width τ multiplies the spectrum by a sinc of τ, attenuating high frequencies (aperture effect); an equaliser can correct it.
8.3 Z-Transform and discrete Fourier transform
30 questions · AExE0803
62. The (bilateral) z-transform of a sequence x[n] is defined as:
Show hintHide hint
The power of z carries a negative sign.
Show answerHide answer
Answer: A. X(z) = Σ x[n]·z⁻ⁿ summed over all n
The bilateral z-transform is Σ from −∞ to ∞ of x[n]z⁻ⁿ; the DTFT is its value on the unit circle.
63. The z-transform of x[n] = aⁿ·u[n] and its region of convergence are:
Show hintHide hint
It is a geometric series in a z⁻¹.
Show answerHide answer
Answer: D. 1/(1 − a z⁻¹), |z| > |a|
Σ (a z⁻¹)ⁿ converges to 1/(1 − a z⁻¹) when |a z⁻¹| < 1, i.e. |z| > |a|.
64. Both aⁿu[n] and −aⁿu[−n−1] have the same algebraic z-transform 1/(1 − a z⁻¹). They are distinguished by:
Show hintHide hint
The expression is identical, so something else must differ.
Show answerHide answer
Answer: C. Their regions of convergence
The first has ROC |z| > |a| (right-sided), the second |z| < |a| (left-sided); X(z) alone is not unique without the ROC.
65. For a finite-duration causal sequence such as x[n] = {1, 2, 3} (n = 0, 1, 2), the ROC is:
Show hintHide hint
Where do terms in z⁻¹ become infinite?
Show answerHide answer
Answer: D. The entire z-plane except z = 0
X(z) = 1 + 2z⁻¹ + 3z⁻² is finite everywhere except at z = 0 where the negative powers blow up.
66. Which statement about the region of convergence of a z-transform is correct?
Show hintHide hint
What is the value of X(z) at a pole?
Show answerHide answer
Answer: B. The ROC cannot contain any pole
At a pole X(z) is infinite, so poles bound the ROC; a two-sided sequence has an annular ROC.
67. A system has H(z) with poles at z = 0.5 and z = 2. If the system is causal, then it is:
Show hintHide hint
Causality fixes the ROC; stability needs the unit circle inside it.
Show answerHide answer
Answer: C. Unstable, because its ROC |z| > 2 does not include the unit circle
Causal ⇒ ROC outside the outermost pole (|z| > 2), which excludes |z| = 1, so it is unstable.
68. The z-transform of x[n − k] (k > 0, causal x) is:
Show hintHide hint
z⁻¹ is the unit delay operator.
Show answerHide answer
Answer: D. z⁻ᵏ X(z)
Time-shift property: a delay of k samples multiplies X(z) by z⁻ᵏ.
69. The convolution y[n] = x[n] * h[n] corresponds in the z-domain to:
Show hintHide hint
Same idea as the Laplace and Fourier convolution properties.
Show answerHide answer
Answer: D. Y(z) = X(z)·H(z)
The convolution property of the z-transform: convolution in time becomes multiplication in z.
70. The inverse z-transform of X(z) = 1/(1 − 0.5z⁻¹), |z| > 0.5, evaluated at n = 2 is:
Show hintHide hint
Identify the standard pair aⁿu[n].
Show answerHide answer
Answer: A. 0.25
x[n] = (0.5)ⁿu[n], so x[2] = 0.25.
71. X(z) = z / [(z − 1)(z − 0.5)] with ROC |z| > 1. Using the final value theorem, lim x[n] as n → ∞ is:
Show hintHide hint
Multiply X(z) by (z − 1) and let z → 1.
Show answerHide answer
Answer: A. 2
x(∞) = lim(z→1) (z − 1)X(z) = 1/(1 − 0.5) = 2. Partial fractions give x[n] = 2 − 2(0.5)ⁿ for n ≥ 0, which tends to 2.
72. X(z) = (2z² + z)/(z² − 0.5z + 0.1) is the z-transform of a causal sequence. The initial value x[0] is:
Show hintHide hint
Let z grow very large and compare the leading terms.
Show answerHide answer
Answer: B. 2
Initial value theorem: x[0] = lim(z→∞) X(z) = 2/1 = 2.
73. By Parseval's theorem, the energy of x[n] = (0.5)ⁿ·u[n] is:
Show hintHide hint
Square each sample and sum the geometric series.
Show answerHide answer
Answer: B. 4/3
Σ|x[n]|² = Σ(0.25)ⁿ = 1/(1 − 0.25) = 4/3; the same value results from (1/2π)∫|X(e^jω)|² dω.
74. A stable causal system H(z) = (1 + z⁻¹)/2 is driven by cos(πn/3). The steady-state output amplitude is:
Show hintHide hint
Evaluate H(z) on the unit circle at z = e^(jπ/3).
Show answerHide answer
Answer: C. 0.866
|H(e^jω)| = |cos(ω/2)|; at ω = π/3, cos(π/6) ≈ 0.866.
75. When a sinusoid is suddenly applied at n = 0 to a stable causal system H(z), the total response consists of:
Show hintHide hint
Separate the response into terms from the system poles and from the input poles.
Show answerHide answer
Answer: A. A transient part from the poles of H(z) that decays to zero, plus a steady-state sinusoid scaled by H(e^jω₀)
For a stable system the system-pole terms die out, leaving |H(e^jω₀)|cos(ω₀n + ∠H(e^jω₀)).
76. What is the DC gain of H(z) = 1/(1 − 0.8z⁻¹)?
Show hintHide hint
DC (ω = 0) maps to z = 1.
Show answerHide answer
Answer: B. 5
DC corresponds to z = 1: H(1) = 1/(1 − 0.8) = 5.
77. A filter has a single zero at z = −1 and a single pole at z = 0.9. It acts as a:
Show hintHide hint
z = 1 is ω = 0 and z = −1 is ω = π.
Show answerHide answer
Answer: B. Low-pass filter
The pole near z = 1 boosts low frequencies and the zero at z = −1 (ω = π) kills the highest frequency, giving a low-pass response.
78. If the DTFT of a finite sequence of length L is sampled at N equally spaced frequencies with N < L, the inverse DFT of those samples gives:
Show hintHide hint
Sampling in one domain causes periodic repetition in the other.
Show answerHide answer
Answer: B. A time-aliased version of x[n]
Frequency-domain sampling makes the time sequence periodic with period N; if N < L the periodic copies overlap (time aliasing).
79. The N-point DFT X[k] of a finite sequence is related to its z-transform by:
Show hintHide hint
The DFT samples lie on the unit circle.
Show answerHide answer
Answer: B. X[k] = X(z) evaluated at z = e^(j2πk/N)
The DFT samples the z-transform at N equally spaced points on the unit circle.
80. The 4-point DFT of x[n] = {1, 1, 1, 1} is:
Show hintHide hint
A constant has energy only at DC.
Show answerHide answer
Answer: D. {4, 0, 0, 0}
X[0] = sum of samples = 4; for k ≠ 0 the complex exponentials sum to zero.
81. For x[n] = {1, 2, 3, 4}, the 4-point DFT value X[1] is:
Show hintHide hint
For N = 4, W₄ = −j.
Show answerHide answer
Answer: C. −2 + 2j
X[1] = Σ x[n](−j)ⁿ = 1 − 2j − 3 + 4j = −2 + 2j.
82. A signal sampled at 8 kHz is analysed with a 256-point DFT. The frequency spacing between DFT bins is:
Show hintHide hint
Divide the sampling rate by the number of points.
Show answerHide answer
Answer: A. 31.25 Hz
Δf = fs/N = 8000/256 = 31.25 Hz.
83. The 2-point circular convolution of x[n] = {1, 2} and h[n] = {3, 4} is:
Show hintHide hint
Indices wrap modulo 2.
Show answerHide answer
Answer: C. {11, 10}
y[0] = 1·3 + 2·4 = 11 and y[1] = 1·4 + 2·3 = 10.
84. Two sequences of lengths 50 and 30 are to be linearly convolved using DFTs. The minimum DFT length that avoids wrap-around error is:
Show hintHide hint
Find the length of the linear convolution result.
Show answerHide answer
Answer: B. 79
Circular convolution equals linear convolution when N ≥ L + M − 1 = 50 + 30 − 1 = 79.
85. Multiplying the N-point DFTs of two sequences and taking the inverse DFT gives their:
Show hintHide hint
DFT treats sequences as one period of a periodic signal.
Show answerHide answer
Answer: A. N-point circular convolution
The DFT product property: X₁[k]X₂[k] ↔ x₁[n] ⊛ x₂[n] (circular convolution modulo N).
86. x[n] is real and its 8-point DFT has X[1] = 2 + 3j. Then X[7] equals:
Show hintHide hint
Real sequences have conjugate-symmetric DFTs.
Show answerHide answer
Answer: A. 2 − 3j
For real x[n], X[N − k] = X*[k], so X[7] = X*[1] = 2 − 3j.
87. A circular shift x[(n − m) mod N] in time corresponds in the DFT domain to:
Show hintHide hint
A shift in one domain is a phase factor in the other.
Show answerHide answer
Answer: C. Multiplying X[k] by e^(−j2πkm/N)
Circular time shift ↔ multiplication by the linear phase factor W_N^(km) = e^(−j2πkm/N).
88. For x[n] = {1, 2, 3, 4}, Σ|X[k]|² over its 4-point DFT equals:
Show hintHide hint
Mind the 1/N factor in the DFT form of Parseval's relation.
Show answerHide answer
Answer: C. 120
Parseval for the DFT: Σ|x[n]|² = (1/N)Σ|X[k]|², so Σ|X[k]|² = 4 × 30 = 120.
89. The N-point DFT of the unit impulse δ[n] is:
Show hintHide hint
Only the n = 0 term contributes.
Show answerHide answer
Answer: A. 1 for every k
X[k] = Σ δ[n]W^(kn) = W⁰ = 1 for all k.
90. The N-point DFT X[k], viewed as a function of the integer k, is:
Show hintHide hint
Replace k by k + N in the twiddle factor.
Show answerHide answer
Answer: D. Periodic with period N
W_N^((k+N)n) = W_N^(kn), so X[k + N] = X[k].
91. Compared with the DTFT, the DFT of a finite sequence of length L (N ≥ L) is:
Show hintHide hint
The DFT is discrete in frequency.
Show answerHide answer
Answer: D. N equally spaced samples of the DTFT over one period
X[k] = X(e^jω) at ω = 2πk/N, k = 0 … N − 1.
8.4 Implementation of discrete-time system
30 questions · AExE0804
92. An IIR filter has a numerator of order 4 and a denominator of order 4. How many delay elements are needed in Direct Form I and in Direct Form II respectively?
Show hintHide hint
Which form shares one delay line between the zeros and poles?
Show answerHide answer
Answer: C. 8 and 4
Direct Form I uses separate delay lines for input and output (M + N = 8); Direct Form II shares them (max(M, N) = 4).
93. Direct Form II realization of an IIR filter is called canonic because:
Show hintHide hint
Count the delays relative to the filter order.
Show answerHide answer
Answer: C. It uses the minimum possible number of delay elements
A structure is canonic when the number of delays equals the order of the difference equation, which Direct Form II achieves.
94. The transposed form of a structure is obtained by:
Show hintHide hint
It is a flow-graph manipulation that keeps H(z) the same.
Show answerHide answer
Answer: D. Reversing all branch directions, swapping input and output, and interchanging adders and branch nodes
By the transposition (flow-graph reversal) theorem, these operations leave the transfer function unchanged.
95. A direct-form FIR filter of length M = 21 has symmetric coefficients h[n] = h[20 − n]. Exploiting the symmetry, the number of multipliers needed is:
Show hintHide hint
Group equal coefficients together and count the unique values.
Show answerHide answer
Answer: D. 11
Pairs of equal coefficients share one multiplier: (M + 1)/2 = 11 for odd M (10 pairs plus the centre tap).
96. A 6th-order IIR filter is realised in cascade form using second-order sections. How many sections are needed?
Show hintHide hint
Each section handles a pair of poles.
Show answerHide answer
Answer: A. 3
Each biquad realises two poles (and two zeros), so 6/2 = 3 sections.
97. The parallel-form realization of an IIR filter is obtained from:
Show hintHide hint
Parallel means the outputs are added.
Show answerHide answer
Answer: C. A partial-fraction expansion of H(z)
Partial fractions express H(z) as a sum of first/second-order terms, which are realised in parallel; factoring gives the cascade form.
98. A two-stage FIR lattice has reflection coefficients K₁ = 0.5 and K₂ = 0.25. The direct-form polynomial is A₂(z) = 1 + a₁z⁻¹ + a₂z⁻². What are a₁ and a₂?
Show hintHide hint
The last coefficient always equals the last reflection coefficient.
Show answerHide answer
Answer: B. a₁ = 0.625, a₂ = 0.25
a₂ = K₂ = 0.25 and a₁ = K₁(1 + K₂) = 0.5 × 1.25 = 0.625.
99. An FIR filter is A₂(z) = 1 + 0.6z⁻¹ + 0.2z⁻². The lattice reflection coefficients are:
Show hintHide hint
Use the step-down (backward) recursion.
Show answerHide answer
Answer: B. K₂ = 0.2, K₁ = 0.5
K₂ = a₂ = 0.2; stepping down, K₁ = a₁/(1 + K₂) = 0.6/1.2 = 0.5.
100. For an all-pole IIR lattice filter, the system is stable if and only if:
Show hintHide hint
This is a quick stability check without finding roots.
Show answerHide answer
Answer: A. All reflection coefficients satisfy |Kₘ| < 1
|Kₘ| < 1 for all m is equivalent to all roots of A_N(z) lying inside the unit circle.
101. A filter H(z) = B(z)/A(z) having both poles and zeros is realised in lattice form by:
Show hintHide hint
One part handles the poles, another part the zeros.
Show answerHide answer
Answer: D. A lattice–ladder structure: the all-pole lattice for A(z) with ladder (tap) coefficients forming B(z)
The lattice part realises the poles; the ladder coefficients combine the backward signals to realise the numerator.
102. Which statement correctly compares FIR and IIR digital filters?
Show hintHide hint
Think about feedback and phase.
Show answerHide answer
Answer: D. FIR filters can have exactly linear phase and are always stable; IIR filters need fewer coefficients for a sharp response
FIR has no feedback (no poles except at the origin) and symmetric taps give linear phase; IIR uses feedback to achieve sharp responses with low order.
103. In 8-bit two's-complement integer representation, the range of numbers is:
Show hintHide hint
There is one more negative number than positive.
Show answerHide answer
Answer: C. −128 to +127
b-bit two's complement covers −2^(b−1) to 2^(b−1) − 1 = −128 to 127.
104. In the Q15 fixed-point format (1 sign bit, 15 fractional bits), the smallest step (resolution) is about:
Show hintHide hint
Count the fractional bits.
Show answerHide answer
Answer: B. 3.05 × 10⁻⁵
Resolution = 2⁻¹⁵ ≈ 3.05 × 10⁻⁵.
105. The decimal fraction 0.625 in binary fixed-point form is:
Show hintHide hint
Write it as a sum of powers of 1/2.
Show answerHide answer
Answer: A. 0.101
0.625 = 0.5 + 0.125 = 2⁻¹ + 2⁻³ = 0.101₂.
106. Using 4 bits (1 sign bit + 3 fractional bits) in two's complement, −0.375 is represented as:
Show hintHide hint
Invert the bits of +0.375 and add one LSB.
Show answerHide answer
Answer: A. 1.101
+0.375 = 0.011; inverting gives 1.100 and adding 1 LSB gives 1.101.
107. The main advantage of floating-point representation over fixed-point in a DSP system is:
Show hintHide hint
What does the exponent field provide?
Show answerHide answer
Answer: A. A much larger dynamic range for the same word length
The exponent lets floating-point represent very large and very small values; fixed-point hardware is simpler but has limited range.
108. In IEEE 754 single-precision floating point, the 32 bits are divided as:
Show hintHide hint
The double-precision format uses an 11-bit exponent.
Show answerHide answer
Answer: D. 1 sign, 8 exponent, 23 mantissa (fraction)
Single precision: 1 sign bit, 8-bit biased exponent, 23-bit fraction (double uses 1/11/52).
109. When a value is quantized by rounding with step Δ, the quantization error e lies in the range:
Show hintHide hint
Rounding picks the nearest level.
Show answerHide answer
Answer: B. −Δ/2 < e ≤ Δ/2
Rounding chooses the nearest level, so the error never exceeds half a step in magnitude.
110. For truncation of a two's-complement number with step Δ, the error e lies in:
Show hintHide hint
In two's complement, dropping bits never increases the value.
Show answerHide answer
Answer: B. −Δ < e ≤ 0
Two's-complement truncation always moves the value downward (toward −∞), so the error is between −Δ and 0 regardless of sign.
111. Rounding noise is modelled as uniformly distributed with step Δ = 2⁻⁷. Its variance is approximately:
Show hintHide hint
Use the variance of a uniform distribution of width Δ.
Show answerHide answer
Answer: C. 5.09 × 10⁻⁶
σ² = Δ²/12 = 2⁻¹⁴/12 ≈ 5.09 × 10⁻⁶.
112. For a full-scale sinusoid, the signal-to-quantization-noise ratio of a 12-bit quantizer is about:
Show hintHide hint
Each bit is worth about 6 dB.
Show answerHide answer
Answer: C. 74 dB
SQNR ≈ 6.02B + 1.76 = 6.02 × 12 + 1.76 ≈ 74 dB.
113. Multiplying two b-bit fixed-point fractions produces a result with:
Show hintHide hint
Think of multiplying two 3-digit decimals.
Show answerHide answer
Answer: C. About 2b bits, which must be rounded or truncated back to b bits
The product of two b-bit numbers needs about 2b bits; reducing it to the register length introduces product round-off noise.
114. The pole of H(z) = 1/(1 − 0.95z⁻¹) is implemented with the coefficient rounded to 3 fractional bits. The pole moves to:
Show hintHide hint
Multiply by 2³, round to the nearest integer, divide back.
Show answerHide answer
Answer: B. 1.0, making the filter marginally stable
0.95 × 8 = 7.6 rounds to 8, so the coefficient becomes 8/8 = 1.0 and the pole lies on the unit circle.
115. Why are high-order IIR filters usually implemented as cascades of second-order sections rather than in direct form?
Show hintHide hint
Think about how polynomial roots respond to small coefficient changes.
Show answerHide answer
Answer: A. Pole positions of a high-order direct form are very sensitive to coefficient quantization
Each root of a high-order polynomial depends on all coefficients, so small quantization errors can move clustered poles a lot, even outside the unit circle; second-order sections localise the effect.
116. Pole sensitivity to coefficient quantization in a direct-form IIR filter is greatest when:
Show hintHide hint
Look at the product of pole-distance terms in the sensitivity formula.
Show answerHide answer
Answer: A. The poles are tightly clustered, as in a narrow-band filter
Sensitivity is inversely proportional to the distances between poles, so closely spaced poles move most.
117. Zero-input limit cycles (sustained oscillations with no input) can occur in:
Show hintHide hint
Limit cycles need a feedback path.
Show answerHide answer
Answer: D. Recursive (IIR) filters implemented with finite-precision arithmetic
Rounding inside a feedback loop can keep the state from decaying; FIR filters have no feedback and cannot sustain limit cycles.
118. To prevent overflow in a fixed-point filter, a common technique is to:
Show hintHide hint
Keep the internal signals within the representable range.
Show answerHide answer
Answer: B. Scale the input (or internal signals) and/or use saturation arithmetic
Scaling keeps internal node values within range; saturation clips instead of wrapping around, avoiding large errors and overflow oscillations.
119. Quantizing the coefficients of an FIR filter can alter its frequency response, but it can never:
Show hintHide hint
Where are the poles of an FIR filter?
Show answerHide answer
Answer: A. Make the filter unstable
An FIR filter has no poles other than at z = 0, so quantized coefficients move only the zeros; the filter remains BIBO stable.
120. The number of multiplications per output sample for a second-order IIR section (biquad) in direct form II is:
Show hintHide hint
Count numerator and denominator coefficients (a₀ = 1).
Show answerHide answer
Answer: B. 5
A biquad has three numerator coefficients (b₀, b₁, b₂) and two denominator coefficients (a₁, a₂): 5 multiplications.
121. Which of the following is an advantage of lattice structures in digital filter implementation?
Show hintHide hint
Think about what the reflection coefficients reveal.
Show answerHide answer
Answer: D. Low sensitivity to coefficient quantization and an easy stability check through |Kₘ| < 1
Lattice structures are modular and robust to quantization; stability is checked directly from the reflection coefficients. They usually need more multipliers.
8.5 IIR filter design and FIR filter design
30 questions · AExE0805
122. In the classical approach to IIR filter design, a digital filter is obtained by:
Show hintHide hint
IIR design borrows from mature analog filter theory.
Show answerHide answer
Answer: D. Designing an analog prototype (e.g. Butterworth or Chebyshev) and mapping it to the z-domain
IIR design commonly converts a well-known analog filter to digital via impulse invariance or the bilinear transformation; the other options are FIR methods.
123. The magnitude response of a Butterworth low-pass filter is:
Show hintHide hint
No ripple anywhere.
Show answerHide answer
Answer: A. Maximally flat in the passband and monotonic everywhere
|H|² = 1/(1 + (Ω/Ωc)^(2N)) has all derivatives zero at Ω = 0 and decreases monotonically.
124. At its cutoff frequency Ωc, the gain of a Butterworth filter of any order is:
Show hintHide hint
Substitute Ω = Ωc in |H|².
Show answerHide answer
Answer: C. −3 dB
At Ω = Ωc, |H|² = 1/2, i.e. 10 log₁₀(0.5) ≈ −3 dB regardless of N.
125. A 4th-order Butterworth low-pass filter has an asymptotic stopband roll-off of:
Show hintHide hint
Each pole contributes 20 dB/decade.
Show answerHide answer
Answer: B. 80 dB/decade
Roll-off = 20N dB/decade = 20 × 4 = 80 dB/decade (≈ 24 dB/octave).
126. What is the minimum order of a Butterworth low-pass filter that gives at least 30 dB attenuation at twice the cutoff (3 dB) frequency?
Show hintHide hint
Set 10 log₁₀(1 + 2^(2N)) ≥ 30 and solve for N.
Show answerHide answer
Answer: A. 5
Need 1 + 2^(2N) ≥ 10³ ⇒ N ≥ log₁₀(999)/(2 log₁₀2) ≈ 4.98, so N = 5.
127. Which analog filter type gives the lowest order for a given set of passband ripple, stopband attenuation and transition width?
Show hintHide hint
The one with ripple in both bands.
Show answerHide answer
Answer: A. Elliptic (Cauer)
Elliptic filters have equiripple behaviour in both bands, giving the sharpest transition for a given order.
128. A Chebyshev Type I filter has ripple parameter ε = 0.5. The passband ripple is about:
Show hintHide hint
Passband gain oscillates between 1 and 1/√(1 + ε²).
Show answerHide answer
Answer: B. 0.97 dB
Ripple = 10 log₁₀(1 + ε²) = 10 log₁₀(1.25) ≈ 0.97 dB.
129. Which statement about Chebyshev filters is correct?
Show hintHide hint
Inverse Chebyshev moves the ripple to the other band.
Show answerHide answer
Answer: B. Type I has equiripple passband and monotonic stopband; Type II has monotonic passband and equiripple stopband
Type I (Chebyshev) ripples in the passband; Type II (inverse Chebyshev) ripples in the stopband.
130. In the impulse-invariance method, an analog pole at s = pₖ maps to a digital pole at:
Show hintHide hint
Sample the exponential e^(pₖt) at t = nT.
Show answerHide answer
Answer: B. z = e^(pₖT)
Sampling hₐ(t) = e^(pₖt) at t = nT gives (e^(pₖT))ⁿ, i.e. a pole at z = e^(pₖT).
131. Using impulse invariance with T = 0.1 s, the analog filter H(s) = 1/(s + 2) gives a digital pole at approximately:
Show hintHide hint
Use z = e^(pT) with p = −2.
Show answerHide answer
Answer: A. 0.819
z = e^(−2 × 0.1) = e^(−0.2) ≈ 0.819.
132. The impulse-invariance method is unsuitable for designing high-pass and band-stop filters because:
Show hintHide hint
Sampling a non-band-limited response causes what?
Show answerHide answer
Answer: A. The frequency response of the sampled impulse response suffers from aliasing
Impulse invariance samples hₐ(t); since high-pass responses are not band-limited, the spectral copies overlap (aliasing).
133. The bilinear transformation used in IIR design is:
Show hintHide hint
It comes from the trapezoidal rule of integration.
Show answerHide answer
Answer: A. s = (2/T)·(1 − z⁻¹)/(1 + z⁻¹)
The bilinear (Tustin) map is s = (2/T)(1 − z⁻¹)/(1 + z⁻¹); it maps the jΩ axis once onto the unit circle.
134. The main property of the bilinear transformation that impulse invariance lacks is:
Show hintHide hint
Think about how the whole analog frequency axis fits into −π to π.
Show answerHide answer
Answer: B. It avoids aliasing by mapping the entire jΩ axis exactly once onto the unit circle
The one-to-one mapping prevents aliasing, at the cost of non-linear frequency warping ω = 2 tan⁻¹(ΩT/2).
135. A digital low-pass filter with cutoff 2 kHz at fs = 8 kHz is to be designed by the bilinear transformation (T = 1/fs). The pre-warped analog cutoff is:
Show hintHide hint
Use Ω = (2/T) tan(ω/2).
Show answerHide answer
Answer: D. 16000 rad/s
ω = 2π(2000/8000) = π/2; Ω = (2/T)tan(ω/2) = 16000 × tan(π/4) = 16000 rad/s.
136. For a sampling frequency of 8 kHz, an analog frequency of 1 kHz corresponds to a normalised digital frequency of:
Show hintHide hint
fs corresponds to 2π rad/sample.
Show answerHide answer
Answer: B. π/4 rad/sample
ω = 2πf/fs = 2π × 1000/8000 = π/4 rad/sample.
137. Which statement about IIR and FIR filter design is correct?
Show hintHide hint
Weigh order against phase linearity.
Show answerHide answer
Answer: B. An IIR design generally meets a magnitude specification with a much lower order than an FIR design, but its phase is non-linear
Feedback poles let IIR filters achieve sharp responses with low order; FIR filters can be exactly linear phase and are always stable.
138. In FIR design by Fourier series (window) method, the ideal low-pass impulse response with cutoff ωc and delay α is hd[n] = sin(ωc(n − α))/(π(n − α)). For ωc = π/4, hd[α] equals:
Show hintHide hint
Use sin(x)/x → 1 as x → 0.
Show answerHide answer
Answer: D. 0.25
At n = α the limit is ωc/π = 0.25.
139. Truncating the ideal impulse response with a rectangular window causes:
Show hintHide hint
Abrupt truncation in time causes ripple in frequency.
Show answerHide answer
Answer: A. Gibbs oscillations, giving a minimum stopband attenuation of only about 21 dB
The rectangular window's large sidelobes produce ripple near the band edge; peak stopband attenuation is about 21 dB regardless of length.
140. Arrange the windows in increasing order of minimum stopband attenuation:
Show hintHide hint
The rectangular window is the worst.
Show answerHide answer
Answer: A. Rectangular, Hanning, Hamming, Blackman
Typical values: rectangular ≈ 21 dB, Hanning ≈ 44 dB, Hamming ≈ 53 dB, Blackman ≈ 74 dB.
141. The Hamming window w[n] = 0.54 − 0.46 cos(2πn/(M − 1)) has the value at its end points (n = 0 and n = M − 1) of:
Show hintHide hint
Put n = 0 into the formula.
Show answerHide answer
Answer: C. 0.08
At n = 0, cos(0) = 1 so w = 0.54 − 0.46 = 0.08 (unlike the Hanning window, which goes to zero).
142. Using the approximation that the transition width of a Hamming-window design equals its main-lobe width 8π/M, the length M needed for a transition width of 0.1π rad/sample is:
Show hintHide hint
Solve 8π/M = 0.1π for M.
Show answerHide answer
Answer: D. 80
M = 8π/Δω = 8π/(0.1π) = 80.
143. The Kaiser window is preferred in many FIR designs because:
Show hintHide hint
It has an adjustable parameter.
Show answerHide answer
Answer: C. Its shape parameter β allows a trade-off between main-lobe width and sidelobe level
Varying β adjusts sidelobe attenuation; together with M it meets a given ripple and transition width.
144. A linear-phase FIR filter of length M = 31 has a group delay of:
Show hintHide hint
The delay is to the centre of symmetry.
Show answerHide answer
Answer: D. 15 samples
Group delay = (M − 1)/2 = 30/2 = 15 samples.
145. A linear-phase FIR filter with symmetric impulse response of even length (Type II) cannot be used as a:
Show hintHide hint
Evaluate H(e^jω) at ω = π for an even-length symmetric filter.
Show answerHide answer
Answer: B. High-pass filter
Type II filters always have a zero at z = −1 (ω = π), forcing the gain to zero at the highest frequency.
146. In the frequency-sampling method of FIR filter design:
Show hintHide hint
The name says what is sampled.
Show answerHide answer
Answer: C. Desired frequency-response samples at ωₖ = 2πk/M are specified and h[n] is found by the inverse DFT
The filter is defined by its DFT samples; free transition-band samples can be optimised to improve stopband attenuation.
147. A length M = 5 linear-phase FIR filter is designed by frequency sampling with amplitude samples |H(k)| = 1, 1, 0, 0, 1 for k = 0 … 4. The centre tap h[2] is:
Show hintHide hint
At n = (M − 1)/2 the phase factors all become 1.
Show answerHide answer
Answer: D. 0.6
At the centre of symmetry the linear-phase terms cancel, so h[2] = (1/M)Σ|H(k)| = 3/5 = 0.6.
148. The Remez exchange algorithm (Parks–McClellan method) designs FIR filters that:
Show hintHide hint
Minimax means minimising the worst case.
Show answerHide answer
Answer: C. Minimise the maximum weighted approximation error, giving equiripple behaviour
It solves a Chebyshev (minimax) approximation problem, producing an optimal equiripple linear-phase filter.
149. The optimality of an equiripple linear-phase FIR filter is characterised by the alternation theorem, which requires the weighted error to have:
Show hintHide hint
The name of the theorem describes the shape of the error.
Show answerHide answer
Answer: D. At least L + 2 extremal frequencies with alternating sign and equal magnitude, where L is the degree of the cosine polynomial
The best minimax approximation by an L-th degree polynomial has an error curve alternating at least L + 2 times.
150. Compared with a window-designed FIR filter of the same length, an optimum equiripple (Parks–McClellan) design:
Show hintHide hint
Think about where the error is concentrated in window designs.
Show answerHide answer
Answer: C. Achieves a narrower transition band or smaller ripple, because the error is spread evenly over each band
Window designs concentrate the error near band edges; equiripple designs distribute it, making better use of the filter length.
151. A Bessel analog prototype is chosen when the main requirement is:
Show hintHide hint
It is about delay, not sharpness.
Show answerHide answer
Answer: C. A maximally flat group delay (nearly linear phase) in the passband
Bessel (Thomson) filters approximate a constant time delay, preserving pulse shape, at the cost of a slow roll-off.
8.6 Digital filter
30 questions · AExE0806
152. For N = 1024, the number of complex multiplications needed by a direct DFT and by a radix-2 FFT are respectively:
Show hintHide hint
FFT cost is (N/2)·log₂N multiplications.
Show answerHide answer
Answer: A. 1,048,576 and 5,120
Direct DFT needs N² = 1,048,576; radix-2 FFT needs (N/2)log₂N = 512 × 10 = 5,120.
153. The computational advantage of a 1024-point radix-2 FFT over a direct DFT, measured by complex multiplications, is about:
Show hintHide hint
Divide N² by (N/2)log₂N.
Show answerHide answer
Answer: C. 205 times
N²/((N/2)log₂N) = 2N/log₂N = 2048/10 ≈ 205.
154. A 256-point radix-2 FFT has how many stages, and how many butterflies per stage?
Show hintHide hint
Each butterfly handles two points.
Show answerHide answer
Answer: C. 8 stages, 128 butterflies per stage
Stages = log₂256 = 8; each stage has N/2 = 128 butterflies (1024 butterflies in total).
155. In a radix-2 decimation-in-time (DIT) FFT with in-place computation, the input and output orders are:
Show hintHide hint
DIT splits the time sequence.
Show answerHide answer
Answer: C. Input in bit-reversed order, output in natural order
DIT repeatedly splits the input into even and odd samples, which scrambles the input into bit-reversed order; the output emerges in natural order.
156. In a radix-2 decimation-in-frequency (DIF) FFT with in-place computation:
Show hintHide hint
DIF is the mirror image of DIT.
Show answerHide answer
Answer: A. The input is in natural order and the output is in bit-reversed order
DIF splits the output (frequency) samples into even and odd indices, so the output appears bit-reversed.
157. For an 8-point FFT, input sample x[3] is placed at which position after bit reversal?
Show hintHide hint
Write the index with log₂N bits and reverse them.
Show answerHide answer
Answer: B. x[6]
3 = 011₂; reversing the 3 bits gives 110₂ = 6.
158. For a 16-point FFT, the bit-reversed position of index 1 is:
Show hintHide hint
Use 4 bits because 16 = 2⁴.
Show answerHide answer
Answer: D. 8
1 = 0001₂ (4 bits); reversed it is 1000₂ = 8.
159. A radix-2 butterfly computes A = a + W·b and B = a − W·b. It requires:
Show hintHide hint
The product W·b is shared.
Show answerHide answer
Answer: B. One complex multiplication and two complex additions
W·b is computed once and then added to and subtracted from a.
160. The twiddle factor W₈² (where W_N = e^(−j2π/N)) equals:
Show hintHide hint
Compute the angle 2π·2/8.
Show answerHide answer
Answer: B. −j
W₈² = e^(−j2π·2/8) = e^(−jπ/2) = −j.
161. The symmetry property of the twiddle factor used to halve the multiplications in the FFT is:
Show hintHide hint
What is W_N^(N/2)?
Show answerHide answer
Answer: D. W_N^(k + N/2) = −W_N^k
W_N^(N/2) = e^(−jπ) = −1, so W_N^(k+N/2) = −W_N^k; periodicity gives W_N^(k+N) = W_N^k.
162. The term in-place computation in an FFT means:
Show hintHide hint
It is about memory.
Show answerHide answer
Answer: D. The outputs of each butterfly are stored in the same memory locations as its inputs
Since each butterfly's inputs are not needed again, the results overwrite them, so only N storage locations are required.
163. Appending zeros to a sequence before computing its DFT (zero padding):
Show hintHide hint
Does zero padding add any new information about the signal?
Show answerHide answer
Answer: A. Gives more closely spaced samples of the same DTFT but does not improve the true frequency resolution
Zero padding interpolates the spectrum; resolution depends on the actual data length (record duration).
164. A signal sampled at 10 kHz must be analysed with a frequency spacing of at most 5 Hz using a radix-2 FFT. The minimum FFT length is:
Show hintHide hint
Compute fs/Δf, then round up to a power of 2.
Show answerHide answer
Answer: D. 2048
N ≥ fs/Δf = 10000/5 = 2000; the next power of 2 is 2048.
165. In the overlap-save method with a 64-point FFT and an FIR filter of length 17, the number of new valid output samples obtained from each block is:
Show hintHide hint
M − 1 outputs per block are corrupted by circular wrap-around.
Show answerHide answer
Answer: C. 48
Each block yields N − M + 1 = 64 − 17 + 1 = 48 valid outputs; the first M − 1 = 16 are discarded.
166. In the overlap-add method, input blocks of L = 100 samples are filtered by an FIR filter of length M = 29 using a radix-2 FFT. The minimum FFT size is:
Show hintHide hint
Linear convolution of each block must fit in the FFT.
Show answerHide answer
Answer: B. 128
Each block convolution has length L + M − 1 = 128, which happens to be a power of 2.
167. In the overlap-save method of fast convolution, from each output block one must:
Show hintHide hint
Which samples are corrupted by circular convolution?
Show answerHide answer
Answer: C. Discard the first M − 1 samples, where M is the filter length
Overlap-save overlaps the inputs and discards the aliased outputs; overlap-add instead adds the overlapping output tails.
168. The Goertzel algorithm is preferred over the FFT when:
Show hintHide hint
Telephone keypad tone detection uses it.
Show answerHide answer
Answer: B. Only a few DFT values are needed, as in DTMF tone detection
Goertzel computes individual DFT bins with a second-order recursive filter; for a few bins it is cheaper than a full FFT.
169. The inverse DFT can be computed with a forward FFT routine by:
Show hintHide hint
The IDFT differs from the DFT only in the sign of the exponent and a 1/N factor.
Show answerHide answer
Answer: D. Conjugating X[k], applying the FFT, conjugating the result and dividing by N
x[n] = (1/N)[FFT{X*[k]}]*, so no separate IFFT routine is needed.
170. Two real N-point sequences can have their DFTs computed efficiently by:
Show hintHide hint
A complex sequence has two real parts to carry.
Show answerHide answer
Answer: A. Forming one complex sequence x₁[n] + j x₂[n] and computing a single N-point FFT
The DFTs are recovered using conjugate-symmetry: X₁[k] = (Y[k] + Y*[N−k])/2 and X₂[k] = (Y[k] − Y*[N−k])/(2j).
171. Spectral leakage in FFT-based spectrum analysis is caused by:
Show hintHide hint
Truncating a signal is the same as multiplying by a window.
Show answerHide answer
Answer: B. Analysing a finite record that does not contain an integer number of periods, and is reduced by windowing
Truncation is multiplication by a rectangular window, spreading energy into neighbouring bins; smoother windows lower the sidelobes.
172. The cross-correlation of two sequences can be computed using FFTs by:
Show hintHide hint
Correlation is like convolution with one signal reversed.
Show answerHide answer
Answer: A. Taking the inverse FFT of X[k]·Y*[k], with zero padding to avoid wrap-around
Correlation is convolution with a time-reversed (conjugated) sequence, i.e. multiplication by the conjugate spectrum.
173. Which of the following is NOT a typical application of FFT algorithms?
Show hintHide hint
Which option is not about discrete spectra or convolution?
Show answerHide answer
Answer: A. Exact computation of analog filter component values
FFTs are used for spectral analysis, fast convolution/correlation and OFDM; analog component values are found by filter synthesis, not by FFTs.
174. An FIR filter with 64 taps processes audio sampled at 48 kHz in real time. The required number of multiply-accumulate operations per second is:
Show hintHide hint
Taps × samples per second.
Show answerHide answer
Answer: C. 3.072 million
Each output needs 64 MACs, so 64 × 48,000 = 3,072,000 MAC/s.
175. A feature found in DSP processors specifically to speed up filtering is:
Show hintHide hint
Filtering consists of repeated sums of products.
Show answerHide answer
Answer: D. A single-cycle multiply-accumulate (MAC) unit
Filtering is a sum of products; a hardware MAC with Harvard architecture lets one tap be processed per cycle.
176. In software implementation of an FIR filter on a DSP, the delay line is usually managed with:
Show hintHide hint
Avoid shifting every sample on each new input.
Show answerHide answer
Answer: D. A circular buffer using modulo addressing
A circular buffer updates the delay line by moving a pointer instead of shifting all samples; bit-reversed addressing is for FFTs.
177. The filter y[n] = 0.5y[n − 1] + x[n] starts at rest and receives a unit step input. The output y[2] is:
Show hintHide hint
Iterate the difference equation from n = 0.
Show answerHide answer
Answer: C. 1.75
y[0] = 1, y[1] = 0.5 + 1 = 1.5, y[2] = 0.75 + 1 = 1.75.
178. For the same filter y[n] = 0.5y[n − 1] + x[n] at rest, the impulse response value h[3] is:
Show hintHide hint
Iterate with x[0] = 1 and zero input afterwards.
Show answerHide answer
Answer: B. 0.125
h[n] = (0.5)ⁿu[n], so h[3] = 0.125.
179. The number of complex additions required by an 8-point radix-2 FFT is:
Show hintHide hint
Count butterflies and additions per butterfly.
Show answerHide answer
Answer: A. 24
A radix-2 FFT needs N log₂N = 8 × 3 = 24 complex additions (two per butterfly, 12 butterflies).
180. A radix-4 FFT algorithm can be applied directly when the length N is:
Show hintHide hint
Each stage divides the length by the radix.
Show answerHide answer
Answer: A. A power of 4
Radix-4 decomposes the DFT into 4-point DFTs at each stage, requiring N = 4^v; mixed or split-radix handles other powers of 2.
181. When implementing a high-order IIR filter in fixed-point hardware, the preferred structure is usually:
Show hintHide hint
Break the filter into small sections.
Show answerHide answer
Answer: B. A cascade of second-order sections with proper scaling
Cascaded biquads limit coefficient sensitivity and round-off noise and allow scaling between sections.
