Chapter 3 · 8 hours

Simple Stress and Strain

IOE past exam questions

Past questions and answers

38 questions set from this chapter, 6 of them more than once; 4 are most repeated (set, or a close variant set, in 3 or more exams). Most repeated first.

  • Most repeated · 4 of 25 exams
  • Asked 4 times
  • 2078 Bhadra · 6 marks
  • 2071 Chaitra · 8 marks
  • 2069 Asar · 8 marks
  • 2066 Bhadra (old course) · 6 marks

Derive relationship between young's modulus and bulk modulus.

Answer

Result: E=3K(1−2μ)E = 3K(1 - 2\mu) where EE is Young's modulus, KK the bulk modulus and μ\mu Poisson's ratio.

Definitions

  • Bulk modulus: K=volumetric (hydrostatic) stressvolumetric strain=pεvK = \dfrac{\text{volumetric (hydrostatic) stress}}{\text{volumetric strain}} = \dfrac{p}{\varepsilon_v}
  • Volumetric strain εv=δVV\varepsilon_v = \dfrac{\delta V}{V}.

Derivation

Take a cube of side LL subjected to equal stress σ\sigma on all six faces (uniform hydrostatic compression/tension), so σx=σy=σz=σ\sigma_x = \sigma_y = \sigma_z = \sigma.

Strain in the x-direction due to all three stresses (Hooke's law with Poisson effect):

εx=σE−μσE−μσE=σE(1−2μ)\varepsilon_x = \frac{\sigma}{E} - \mu\frac{\sigma}{E} - \mu\frac{\sigma}{E} = \frac{\sigma}{E}(1 - 2\mu)

By symmetry εy=εz=εx\varepsilon_y = \varepsilon_z = \varepsilon_x.

Volume V=L3V = L^3; for small strains the volumetric strain is the sum of the linear strains:

εv=εx+εy+εz=3σE(1−2μ)\varepsilon_v = \varepsilon_x + \varepsilon_y + \varepsilon_z = \frac{3\sigma}{E}(1 - 2\mu)

(Check: V+δV=L3(1+ε)3≈L3(1+3ε)V + \delta V = L^3(1+\varepsilon)^3 \approx L^3(1 + 3\varepsilon).)

From the definition of bulk modulus, with p=σp = \sigma:

K=σεv=σ3σE(1−2μ)=E3(1−2μ)K = \frac{\sigma}{\varepsilon_v} = \frac{\sigma}{\dfrac{3\sigma}{E}(1 - 2\mu)} = \frac{E}{3(1 - 2\mu)} E=3K(1−2μ)\boxed{E = 3K(1 - 2\mu)}

Notes: since KK must be positive, 1−2μ>01 - 2\mu > 0, so μ<0.5\mu < 0.5. For an incompressible material, μ=0.5\mu = 0.5 and K→∞K \to \infty. For example, for steel with μ=0.3\mu = 0.3, K=E/(3×0.4)=0.833EK = E/(3\times0.4) = 0.833E.

  • Most repeated · 3 of 25 exams
  • Asked 3 times
  • 2081 Baisakh · 8 marks
  • 2067 Asar (old course) · 4 marks
  • 2066 Chaitra (old course) · 6 marks

Derive the relationship between Young's modulus of Elasticity, Modulus of rigidity and Poisson's ratio.

Answer

Result: E=2G(1+μ)E = 2G(1 + \mu), where GG is the modulus of rigidity.

Setting up

Consider a square element ABCD of side aa subjected to pure shear: shear stress τ\tau on its faces. Then the diagonals experience equal tensile and compressive stresses of magnitude τ\tau at 45∘45^\circ (principal stresses σ1=+τ\sigma_1 = +\tau and σ2=−τ\sigma_2 = -\tau).

   A────────────D       Shear τ on all faces
   │            │       shear strain φ = τ/G
   │    ╲       │       diagonal BD stretches
   B────────────C       diagonal AC shortens

Strain in the diagonal in terms of E and μ

The tensile principal stress along diagonal BD is τ\tau and the compressive one along AC is −τ-\tau. The strain of diagonal BD is

εBD=τE−μ(−τE)=τE(1+μ)(1)\varepsilon_{BD} = \frac{\tau}{E} - \mu\left(\frac{-\tau}{E}\right) = \frac{\tau}{E}(1 + \mu) \qquad (1)

Strain in the diagonal in terms of the shear strain

Under shear strain ϕ\phi, the face DC moves to DC' by δ=aϕ\delta = a\phi (the face CD shifts parallel to AB). The diagonal BD changes length by the component of this displacement along BD, i.e.

δBD=CC′cos⁡45∘=aϕcos⁡45∘\delta_{BD} = CC'\cos45^\circ = a\phi\cos45^\circ

and the original diagonal length is BD=a2=a/cos⁡45∘BD = a\sqrt{2} = a/\cos45^\circ. Therefore

εBD=aϕcos⁡45∘a/cos⁡45∘=ϕcos⁡245∘=ϕ2=τ2G(2)\varepsilon_{BD} = \frac{a\phi\cos45^\circ}{a/\cos45^\circ} = \phi\cos^245^\circ = \frac{\phi}{2} = \frac{\tau}{2G} \qquad (2)

(using ϕ=τ/G\phi = \tau/G).

Equating (1) and (2)

τ2G=τE(1+μ)  ⇒  E=2G(1+μ)\frac{\tau}{2G} = \frac{\tau}{E}(1 + \mu) \;\Rightarrow\; \boxed{E = 2G(1 + \mu)}

For steel with μ=0.3\mu = 0.3: G=E/2.6=0.385EG = E/2.6 = 0.385E.

  • Most repeated · 3 of 25 exams
  • Asked 3 times
  • 2080 Baisakh · 6 marks
  • 2078 Kartik · 6 marks
  • 2072 Chaitra · 8 marks

Derive the relations between the elastic constants (Young's modulus E, modulus of rigidity G, bulk modulus K) and Poisson's ratio.

Answer

The three elastic constants EE, GG, KK are connected with Poisson's ratio μ\mu by:

E=2G(1+μ),E=3K(1−2μ),E=9KG3K+G,μ=3K−2G2(3K+G)E = 2G(1 + \mu),\qquad E = 3K(1 - 2\mu),\qquad E = \frac{9KG}{3K + G},\qquad \mu = \frac{3K - 2G}{2(3K + G)}

(a) Relation between E, G and μ

Take a square element under pure shear τ\tau. The diagonals carry principal stresses +τ+\tau (tension) and −τ-\tau (compression).

Strain of the tension diagonal from Hooke's law:

ε=τE+μτE=τE(1+μ)\varepsilon = \frac{\tau}{E} + \mu\frac{\tau}{E} = \frac{\tau}{E}(1 + \mu)

Geometry: the shear strain ϕ=τ/G\phi = \tau/G stretches the diagonal by ε=ϕ/2=τ2G\varepsilon = \phi/2 = \dfrac{\tau}{2G}.

Equating:

τ2G=τE(1+μ)  ⇒  E=2G(1+μ)(1)\frac{\tau}{2G} = \frac{\tau}{E}(1 + \mu) \;\Rightarrow\; E = 2G(1 + \mu)\qquad (1)

(b) Relation between E, K and μ

A cube under equal stress σ\sigma on all faces has

εx=σE(1−2μ),εv=3εx=3σE(1−2μ)\varepsilon_x = \frac{\sigma}{E}(1 - 2\mu),\qquad \varepsilon_v = 3\varepsilon_x = \frac{3\sigma}{E}(1 - 2\mu)

and K=σ/εvK = \sigma/\varepsilon_v, so

K=E3(1−2μ)  ⇒  E=3K(1−2μ)(2)K = \frac{E}{3(1 - 2\mu)} \;\Rightarrow\; E = 3K(1 - 2\mu)\qquad (2)

(c) Eliminating μ to relate E, G and K

From (1): μ=E2G−1\mu = \dfrac{E}{2G} - 1. Substitute in (2):

E=3K[1−2(E2G−1)]=3K(3−EG)E = 3K\left[1 - 2\left(\frac{E}{2G} - 1\right)\right] = 3K\left(3 - \frac{E}{G}\right) E(1+3KG)=9K  ⇒  E=9KG3K+GE\left(1 + \frac{3K}{G}\right) = 9K \;\Rightarrow\; E = \frac{9KG}{3K + G}

Also, equating (1) and (2): 2G(1+μ)=3K(1−2μ)2G(1 + \mu) = 3K(1 - 2\mu), so

μ=3K−2G2(3K+G)\mu = \frac{3K - 2G}{2(3K + G)}

Example: for E=200E = 200 GPa and μ=0.3\mu = 0.3: G=2002.6=76.9G = \dfrac{200}{2.6} = 76.9 GPa and K=2003(0.4)=166.7K = \dfrac{200}{3(0.4)} = 166.7 GPa.

  • Most repeated · 3 of 25 exams
  • Asked 3 times
  • 2079 Bhadra · 6 marks
  • 2075 Chaitra · 6 marks
  • 2074 Chaitra · 6 marks

Derive the expression for the elongation of a circular bar of tapering section due to axial load.

Answer

Consider a circular bar of length LL whose diameter varies uniformly from d1d_1 at one end to d2d_2 at the other, subjected to an axial pull PP. Young's modulus is EE.

   d1                         d2
  ┌──┐                       ┌──┐
 P│  └───────────────────────┘  │P
 →│   ╲_____________________╱    │→
  └──┘            x           └──┘
        L

Derivation

Measure xx from the small end (diameter d1d_1, taking d2>d1d_2 > d_1). The diameter at distance xx is

dx=d1+d2−d1L x=d1+kx,k=d2−d1Ld_x = d_1 + \frac{d_2 - d_1}{L}\,x = d_1 + kx,\qquad k = \frac{d_2 - d_1}{L}

Cross-sectional area: Ax=π4dx2A_x = \dfrac{\pi}{4}d_x^2, so the stress is σx=4Pπdx2\sigma_x = \dfrac{4P}{\pi d_x^2}.

Elongation of a small length dxdx:

dδ=σxEdx=4PπEdx2dxd\delta = \frac{\sigma_x}{E}dx = \frac{4P}{\pi E d_x^2}dx

Total elongation:

δ=4PπE∫0Ldx(d1+kx)2=4PπE[−1k(d1+kx)]0L=4PπEk[1d1−1d2]\delta = \frac{4P}{\pi E}\int_0^L\frac{dx}{(d_1 + kx)^2} = \frac{4P}{\pi E}\left[-\frac{1}{k(d_1 + kx)}\right]_0^L = \frac{4P}{\pi E k}\left[\frac{1}{d_1} - \frac{1}{d_2}\right]

Since d1+kL=d2d_1 + kL = d_2, and 1d1−1d2=d2−d1d1d2=kLd1d2\dfrac{1}{d_1} - \dfrac{1}{d_2} = \dfrac{d_2 - d_1}{d_1d_2} = \dfrac{kL}{d_1d_2}:

δ=4PLπE d1 d2\boxed{\delta = \frac{4PL}{\pi E\,d_1\,d_2}}

Checks

  • If d1=d2=dd_1 = d_2 = d, then δ=4PLπEd2=PLAE\delta = \dfrac{4PL}{\pi Ed^2} = \dfrac{PL}{AE}, the formula for a prismatic bar.
  • The formula holds for a gradual taper only, away from the ends, where the stress is assumed uniform over each section (Saint-Venant's principle).

Example: P=50P = 50 kN, L=1000L = 1000 mm, d1=20d_1 = 20 mm, d2=40d_2 = 40 mm, E=200E = 200 GPa gives δ=4(50×103)(1000)π(200×103)(20)(40)=0.398\delta = \dfrac{4(50\times10^3)(1000)}{\pi(200\times10^3)(20)(40)} = 0.398 mm.

  • Asked 2 times
  • 2081 Bhadra · 8 marks
  • 2066 Bhadra (old course) · 8 marks

The gap between bar A of cross-sectional area 1000 mm21000\ \text{mm}^2 and bar B of cross-sectional area 800 mm2800\ \text{mm}^2 is 0.26 mm0.26\ \text{mm} at room temperature. What are the stresses induced in the bars if the temperature is raised to 40∘C40^\circ\text{C}? Given: EA=2×105 N/mm2E_A = 2\times10^5\ \text{N/mm}^2, αA=12×10−6/∘C\alpha_A = 12\times10^{-6}/^\circ\text{C} and EB=1×105 N/mm2E_B = 1\times10^5\ \text{N/mm}^2, αB=23×10−6/∘C\alpha_B = 23\times10^{-6}/^\circ\text{C}. [Figure: bar A (length 400 mm) fixed to the left wall and bar B (length 300 mm) fixed to the right wall, with a gap of 0.26 mm between them.]

Answer

Take bar A as the left bar and bar B as the right bar. The bars first expand freely; if the free expansion exceeds the gap, the walls prevent the excess and a compressive force PP (equal in both bars) develops.

Free thermal expansion

δA=αA ΔT LA=12×10−6×40×400=0.192 mmδB=αB ΔT LB=23×10−6×40×300=0.276 mmδtotal=0.468 mm>gap=0.26 mm\begin{aligned} \delta_A &= \alpha_A\,\Delta T\,L_A = 12\times10^{-6}\times40\times400 = 0.192\ \text{mm}\\ \delta_B &= \alpha_B\,\Delta T\,L_B = 23\times10^{-6}\times40\times300 = 0.276\ \text{mm}\\ \delta_{total} &= 0.468\ \text{mm} > \text{gap} = 0.26\ \text{mm} \end{aligned}

The expansion that is prevented is δprevented=0.468−0.26=0.208\delta_{prevented} = 0.468 - 0.26 = 0.208 mm, so the bars are in contact and stresses are induced.

Compatibility

The compressive force PP shortens the bars by exactly the prevented expansion:

PLAAAEA+PLBABEB=0.208\frac{P L_A}{A_A E_A} + \frac{P L_B}{A_B E_B} = 0.208 P(4001000×2×105+300800×1×105)=P (5.7500×10−6)=0.208P\left(\frac{400}{1000\times2\times10^5} + \frac{300}{800\times1\times10^5}\right) = P\,(5.7500\times10^{-6}) = 0.208 P=36173.9 N=36.17 kNP = 36173.9\ \text{N} = 36.17\ \text{kN}

Stresses

σA=PAA=36173.91000=36.17 N/mm2,σB=PAB=36173.9800=45.22 N/mm2\sigma_A = \frac{P}{A_A} = \frac{36173.9}{1000} = 36.17\ \text{N/mm}^2,\qquad \sigma_B = \frac{P}{A_B} = \frac{36173.9}{800} = 45.22\ \text{N/mm}^2

Answer: both bars are in compression: σA=36.17\sigma_A = 36.17 N/mm² (bar A) and σB=45.22\sigma_B = 45.22 N/mm² (bar B); common force P=36.17P = 36.17 kN.

  • Asked 2 times
  • 2075 Asoj · 5 marks
  • 2068 Baisakh (old course) · 4 marks

Derive the expression for the total elongation of a uniform bar of length L and cross section area A under its self weight.

Answer

Consider a uniform vertical bar of length LL, area AA, Young's modulus EE and unit weight (weight density) γ=ρg\gamma = \rho g, hanging from a fixed support at the top and carrying only its own weight.

 ═══════  fixed support
   │ ↑ x measured from the free (bottom) end
   │
   │  dx
   │
   ○  free end

Derivation

Take a section at distance xx from the free end. The load it carries is the weight of the bar below it:

Px=γAxP_x = \gamma A x

The stress at the section is σx=PxA=γx\sigma_x = \dfrac{P_x}{A} = \gamma x, which varies linearly from zero at the free end to γL\gamma L at the support.

The elongation of a small element of length dxdx:

dδ=σxEdx=γxEdxd\delta = \frac{\sigma_x}{E}dx = \frac{\gamma x}{E}dx

Total elongation:

δ=∫0LγxEdx=γL22E\delta = \int_0^L\frac{\gamma x}{E}dx = \frac{\gamma L^2}{2E}

With the total weight W=γALW = \gamma A L:

δ=γL22E=WL2AE\boxed{\delta = \frac{\gamma L^2}{2E} = \frac{WL}{2AE}}

Meaning: the elongation due to self-weight is half the elongation that the same weight WW would cause if it were applied as a point load at the free end (δ=WL/AE\delta = WL/AE). Maximum stress σmax=γL\sigma_{max} = \gamma L occurs at the support.

Example: a steel bar of L=100L = 100 m with γ=77\gamma = 77 kN/m³ and E=200E = 200 GPa: δ=77×10−6 N/mm3×(105)22×200×103=1.925\delta = \dfrac{77\times10^{-6}\ \text{N/mm}^3\times(10^5)^2}{2\times200\times10^3} = 1.925 mm, with σmax=7.7\sigma_{max} = 7.7 N/mm².

  • 2075 Asoj · 8 marks

Two copper rods and one steel rod are having diameter 4 cm, together support a load 3000 kg as shown in figure below. Determine the stresses in each rod. Take Es=2×106 kg/cm2E_s = 2\times10^6\ \text{kg/cm}^2, Ec=106 kg/cm2E_c = 10^6\ \text{kg/cm}^2. [Figure: a rigid plate carrying a 3000 kg load rests on two outer copper rods and a central steel rod standing on a base; the copper rods are 4 m long and the steel rod stands in a recess 1 m deeper.]

Similar questions: Two copper, one steel rod: 5000 kg (2074 Chaitra)

Answer

The load is carried by a rigid plate resting on the three rods, so all rods shorten equally. The steel rod stands in a recess 1 m deeper, so it is 5 m long (copper 4 m).

Compatibility

δc=δs⇒σcLcEc=σsLsEs⇒σc(400)106=σs(500)2×106⇒σs=1.60 σc\delta_c = \delta_s \Rightarrow \frac{\sigma_c L_c}{E_c} = \frac{\sigma_s L_s}{E_s} \Rightarrow \frac{\sigma_c(400)}{10^6} = \frac{\sigma_s(500)}{2\times10^6} \Rightarrow \sigma_s = 1.60\,\sigma_c

Equilibrium

Area of each rod A=π4(4)2=12.566A = \dfrac{\pi}{4}(4)^2 = 12.566 cm².

P=2σcA+σsA=σcA (2+1.60)P = 2\sigma_cA + \sigma_sA = \sigma_cA\,(2 + 1.60) 3000=σc(12.566)(3.60)⇒σc=66.315 kg/cm2,σs=106.103 kg/cm23000 = \sigma_c(12.566)(3.60) \Rightarrow \sigma_c = 66.315\ \text{kg/cm}^2,\quad \sigma_s = 106.103\ \text{kg/cm}^2

Check: 2(833.3)+1333.3=3000.02(833.3) + 1333.3 = 3000.0 kg.

Answer: stress in each copper rod = 66.31 kg/cm²; stress in the steel rod = 106.10 kg/cm² (compressive).

  • 2074 Chaitra · 6 marks

Two copper rods and one steel rod is of 3 cm diameter, together support a load of 5000 kg as shown in figure below. Find the stresses in each rod. Take 'E' for steel and copper as 2×106 kg/cm22\times10^6\ \text{kg/cm}^2 and 106 kg/cm210^6\ \text{kg/cm}^2. [Figure: a rigid plate carrying a 5000 kg load rests on two outer copper rods (3 m long) and a central steel rod standing in a recess 1 m deeper.]

Similar questions: Two copper, one steel rod: 3000 kg (2075 Asoj)

Answer

The rigid plate rests on three rods, so all rods shorten equally. The steel rod stands in a recess 1 m deeper: copper is 3 m long, steel 4 m.

Compatibility

σcLcEc=σsLsEs⇒σc(300)106=σs(400)2×106⇒σs=1.50 σc\frac{\sigma_c L_c}{E_c} = \frac{\sigma_s L_s}{E_s} \Rightarrow \frac{\sigma_c(300)}{10^6} = \frac{\sigma_s(400)}{2\times10^6} \Rightarrow \sigma_s = 1.50\,\sigma_c

Equilibrium

A=π4(3)2=7.069A = \dfrac{\pi}{4}(3)^2 = 7.069 cm² for each rod.

5000=σcA(2+1.50)⇒σc=50007.069×3.50=202.102 kg/cm25000 = \sigma_cA(2+1.50) \Rightarrow \sigma_c = \frac{5000}{7.069\times3.50} = 202.102\ \text{kg/cm}^2 σs=1.50×202.102=303.152 kg/cm2\sigma_s = 1.50\times202.102 = 303.152\ \text{kg/cm}^2

Answer: each copper rod 202.10 kg/cm²; steel rod 303.15 kg/cm² (compressive).

  • 2066 Jestha (old course) · 12 marks

A compound tube consists of steel tube 130mm internal diameter and 10mm thickness and outer brass tube 160mm internal diameter and 10mm thickness. The two tubes are of same length. The combined tube carries a compressive load of 750 kN. Find the stresses and load carried by each of the steel tube and the brass tube and the amount it shortens. Length of each tube is 250mm. Esteel=2×105 MPaE_{steel} = 2\times10^5\ \text{MPa} Ebrass=1×105 MPaE_{brass} = 1\times10^5\ \text{MPa}.

Similar questions: Compound tube: stresses and load share (1000 kN) (2066 Chaitra (old course))

Answer

Principle: both tubes have the same length and are loaded together, so they shorten equally: εs=εb\varepsilon_s = \varepsilon_b. The total load is shared: Ps+Pb=750P_s + P_b = 750 kN.

Areas

Steel: inner d=130d = 130 mm, outer D=150D = 150 mm. Brass: inner d=160d = 160 mm, outer D=180D = 180 mm.

As=π4(1502−1302)=4398.2 mm2,Ab=π4(1802−1602)=5340.7 mm2A_s = \frac{\pi}{4}(150^2 - 130^2) = 4398.2\ \text{mm}^2, \qquad A_b = \frac{\pi}{4}(180^2 - 160^2) = 5340.7\ \text{mm}^2

Stresses

Equal strain gives

σsEs=σbEb⇒σs=EsEbσb=2σb\frac{\sigma_s}{E_s} = \frac{\sigma_b}{E_b} \Rightarrow \sigma_s = \frac{E_s}{E_b}\sigma_b = 2\sigma_b P=σsAs+σbAb=σb(2As+Ab)⇒750 000=σb(2×4398.2+5340.7)P = \sigma_sA_s + \sigma_bA_b = \sigma_b(2A_s + A_b) \Rightarrow 750\,000 = \sigma_b(2\times4398.2 + 5340.7) σb=53.05 MPa,σs=106.10 MPa\sigma_b = 53.05\ \text{MPa}, \qquad \sigma_s = 106.10\ \text{MPa}

Loads carried

Ps=σsAs=466.67 kN,Pb=σbAb=283.33 kNP_s = \sigma_sA_s = 466.67\ \text{kN}, \qquad P_b = \sigma_bA_b = 283.33\ \text{kN}

Check: 466.67+283.33=750.00466.67 + 283.33 = 750.00 kN.

Shortening

δ=σsLEs=106.10×2502×105=0.1326 mm\delta = \frac{\sigma_s L}{E_s} = \frac{106.10\times250}{2\times10^5} = 0.1326\ \text{mm}

(Brass gives the same: 53.05×250/105=0.132653.05\times250/10^5 = 0.1326 mm.)

Answer: σs=106.10\sigma_s = 106.10 MPa, σb=53.05\sigma_b = 53.05 MPa; Ps=466.67P_s = 466.67 kN, Pb=283.33P_b = 283.33 kN; shortening =0.1326= 0.1326 mm.

  • 2066 Chaitra (old course) · 10 marks

A compound tube consists of a steel tube 15cm internal diameter and 1cm thickness and an outer brass tube of 17cm internal diameter and 1cm thickness. Two tubes are of the same length. The compound tube carries an axial load of 1000 kN. Find the stresses and the load carried by each tube. Take Esteel=2×107 N/cm2E_{steel} = 2\times10^7\ \text{N/cm}^2 and Ebrass=1×107 N/cm2E_{brass} = 1\times10^7\ \text{N/cm}^2

Similar questions: Compound tube: stresses, load share and shortening (750 kN) (2066 Jestha (old course))

Answer

Both tubes carry the load together and have the same length, so their strains are equal and Ps+Pb=1000P_s + P_b = 1000 kN =106= 10^6 N.

Areas

Steel: inner 15 cm, outer 17 cm. Brass: inner 17 cm, outer 19 cm.

As=π4(172−152)=50.27 cm2,Ab=π4(192−172)=56.55 cm2A_s = \frac{\pi}{4}(17^2 - 15^2) = 50.27\ \text{cm}^2, \qquad A_b = \frac{\pi}{4}(19^2 - 17^2) = 56.55\ \text{cm}^2

Stresses

σsEs=σbEb⇒σs=2×107107σb=2σb\frac{\sigma_s}{E_s} = \frac{\sigma_b}{E_b} \Rightarrow \sigma_s = \frac{2\times10^7}{10^7}\sigma_b = 2\sigma_b 106=σb(2As+Ab)=σb(2×50.27+56.55)⇒σb=6366.2 N/cm210^6 = \sigma_b(2A_s + A_b) = \sigma_b(2\times50.27 + 56.55) \Rightarrow \sigma_b = 6366.2\ \text{N/cm}^2 σs=12732.4 N/cm2\sigma_s = 12732.4\ \text{N/cm}^2

Loads

Ps=σsAs=640.00 kN,Pb=σbAb=360.00 kNP_s = \sigma_sA_s = 640.00\ \text{kN}, \qquad P_b = \sigma_bA_b = 360.00\ \text{kN}

Check: 640.00+360.00=1000.00640.00 + 360.00 = 1000.00 kN.

Answer: steel: 12732.4 N/cm212732.4\ \text{N/cm}^2 (127.32127.32 MPa), load 640.0640.0 kN; brass: 6366.2 N/cm26366.2\ \text{N/cm}^2 (63.6663.66 MPa), load 360.0360.0 kN.

  • 2081 Bhadra · 2+2+3 marks

Describe stress concentration and stress concentration factor. What information does Saint-Venant's principle provide on this? Why factor of safety is used in design?

Answer

Stress concentration and stress concentration factor

Stress concentration is the localised rise of stress near a sudden change in cross-section or geometry (holes, notches, grooves, keyways, fillets, sharp corners, threads), where the flow of internal force is disturbed. The stress at such a place is much higher than the average stress calculated from P/AP/A.

The stress concentration factor is

Kt=σmaxσnomK_t = \frac{\sigma_{max}}{\sigma_{nom}}

where σmax\sigma_{max} is the peak stress at the discontinuity and σnom\sigma_{nom} is the nominal stress based on the net area. Kt≥1K_t \ge 1 and depends on geometry (not on the material, as long as it is elastic). For a small circular hole in a wide plate in tension Kt=3K_t = 3.

 Stress flow lines crowd near a hole:
  ─────┐   ┌─────
  ─────┤ ○ ├─────   σ_max at the edge of the hole
  ─────┘   └─────

Effects are serious for brittle materials and for fatigue loading, whereas ductile materials under static loading yield locally and redistribute stress.

Saint-Venant's principle

It states that the stress and strain produced at points sufficiently far from the place of application of a load (or from a discontinuity) depend only on the resultant of the load, not on the exact way it is distributed; the differences between two statically equivalent loadings become negligible at a distance about equal to the largest cross-sectional dimension of the member.

With regard to stress concentration, it tells us that the disturbance is local: high stresses exist only in the neighbourhood of the hole, notch or point load, and at a distance of about one width from it the stress becomes uniform (P/AP/A). So the formula σ=P/A\sigma = P/A may be used away from these places and the concentration need be considered only locally.

Why a factor of safety is used

The factor of safety (FOS=ultimate or yield stresspermissible (working) stressFOS = \dfrac{\text{ultimate or yield stress}}{\text{permissible (working) stress}}) is used because of:

  1. Uncertainty in the actual loads (overloading, impact, dynamic effects).
  2. Variation in material properties, defects and non-uniformity.
  3. Approximations in analysis and stress concentrations, workmanship and fabrication errors.
  4. Deterioration with time (corrosion, fatigue, wear).
  5. The need for safety of life and property, and to keep stresses in the elastic range.

Typical values: 1.5 to 2 for steel (yield basis), 3 to 4 for brittle materials (ultimate basis), higher for dynamic loads.

  • 2081 Baisakh · 8 marks

A rigid bar ABCD pinned at B and connected to two vertical rods as shown in the figure below. Assuming that the bar was initially horizontal and the rods stress free, determine the stress in each rod after the load P=500 NP = 500\ \text{N} is applied. Esteel=200 GPaE_{steel} = 200\ \text{GPa} and Eal=100 GPaE_{al} = 100\ \text{GPa}. [Figure: horizontal rigid bar A-B-C-D with pin support at B; A to B 1.5 m, B to C 0.75 m, C to D 0.75 m; aluminium rod at A (area 300 mm2300\ \text{mm}^2, length 1.5 m) fixed to the ground below; steel rod at D (area 200 mm2200\ \text{mm}^2, length 0.9 m) hanging from the ceiling; load P=500 NP = 500\ \text{N} downward at C.]

Answer

The load PP at C rotates the rigid bar clockwise about the pin B: A moves up (stretching the aluminium rod fixed to the ground below) and D moves down (stretching the steel rod hung from the ceiling). Both rods are in tension; let the forces be FalF_{al} and FstF_{st}.

 F_al                    F_st
  |                        ^
  v                        |
  A---1.5m---B---0.75---C---0.75---D
   (Al, 1.5 m)  pin     P=500 N  (steel, 0.9 m)

Equilibrium (moments about B)

Aluminium pulls A down and steel pulls D up; both give anticlockwise moments about B, balancing the clockwise moment of PP:

Fal(1.5)+Fst(1.5)=P(0.75)=500×0.75F_{al}(1.5) + F_{st}(1.5) = P(0.75) = 500\times0.75 Fal+Fst=250 NF_{al} + F_{st} = 250\ \text{N}

Compatibility

The bar is rigid, and A and D are both 1.5 m from the pin, so the upward movement of A equals the downward movement of D: δal=δst\delta_{al} = \delta_{st}.

Fal(1500)300×100×103=Fst(900)200×200×103  ⇒  5×10−5Fal=2.25×10−5Fst  ⇒  Fal=0.450 Fst\frac{F_{al}(1500)}{300\times100\times10^3} = \frac{F_{st}(900)}{200\times200\times10^3} \;\Rightarrow\; 5\times10^{-5}F_{al} = 2.25\times10^{-5}F_{st} \;\Rightarrow\; F_{al} = 0.450\,F_{st}

Solution

Fst(1+0.450)=250⇒Fst=172.41 NFal=77.59 Nσst=172.41200=0.862 N/mm2σal=77.59300=0.259 N/mm2\begin{aligned} F_{st}(1+0.450) &= 250 \Rightarrow F_{st} = 172.41\ \text{N}\\ F_{al} &= 77.59\ \text{N}\\ \sigma_{st} &= \frac{172.41}{200} = 0.862\ \text{N/mm}^2\\ \sigma_{al} &= \frac{77.59}{300} = 0.259\ \text{N/mm}^2 \end{aligned}

Answer: σsteel=0.862\sigma_{steel} = 0.862 N/mm² (tension) and σaluminium=0.259\sigma_{aluminium} = 0.259 N/mm² (tension).

  • 2080 Bhadra · 8 marks

The rigid bars PQ and RS shown in figure are supported by pins at P and R and the two rods. Determine the maximum force W that can be applied, if its vertical movement is limited to 5 mm under load. [Figure: two horizontal rigid bars; upper bar PQ pinned at P (3 m + 3 m), lower bar RS pinned at R (3 m + 3 m); an aluminium rod (L = 2 m, A=500 mm2A = 500\ \text{mm}^2, E=70 GPaE = 70\ \text{GPa}) hangs from the ceiling and connects to the upper bar at Q; a steel rod (L = 2 m, A=300 mm2A = 300\ \text{mm}^2, E=200 GPaE = 200\ \text{GPa}) connects Q to S; load W acts at the middle of the lower bar RS, 3 m from R and 3 m from S.]

Answer

Assumed arrangement: both bars are 6 m long (3 m + 3 m) and pinned at P and R. The aluminium rod hangs from the ceiling to Q (upper bar), the steel rod joins Q to S (lower bar), and WW acts at the middle of RS.

Equilibrium

  • Lower bar RS (moments about R): the steel rod pulls S up with FstF_{st}, so Fst(6)=W(3)F_{st}(6) = W(3) and Fst=W/2F_{st} = W/2.
  • Upper bar PQ (moments about P): the steel rod pulls Q down with FstF_{st} and the aluminium rod pulls Q up with FalF_{al}, so Fal(6)=Fst(6)F_{al}(6) = F_{st}(6) and Fal=Fst=W/2F_{al} = F_{st} = W/2.

Let F=W/2F = W/2. Both rods are in tension.

Deformations

δal=FLAE=F(2000)500×70×103=5.7143e−05 F mmδst=F(2000)300×200×103=3.3333e−05 F mm\begin{aligned} \delta_{al} &= \frac{F L}{AE} = \frac{F(2000)}{500\times70\times10^3} = 5.7143e-05\,F\ \text{mm}\\ \delta_{st} &= \frac{F(2000)}{300\times200\times10^3} = 3.3333e-05\,F\ \text{mm} \end{aligned}

Geometry of movement

  • Q moves down by δal\delta_{al} (bar PQ rotates about P).
  • S moves down by δQ+δst=δal+δst\delta_Q + \delta_{st} = \delta_{al} + \delta_{st} (bar RS rotates about R).
  • The load point is at the middle of RS, so it moves 12(δal+δst)\tfrac12(\delta_{al}+\delta_{st}).

Limiting the movement of W to 5 mm:

12(δal+δst)=5⇒(5.7143e−05+3.3333e−05)F=10\tfrac12(\delta_{al}+\delta_{st}) = 5 \Rightarrow (5.7143e-05+3.3333e-05)F = 10 F=110526.3 N,W=2F=221052.6 N=221.05 kNF = 110526.3\ \text{N},\qquad W = 2F = 221052.6\ \text{N} = 221.05\ \text{kN}

Answer: Wmax=221.05W_{max} = 221.05 kN (rod force 110.53 kN in each rod).

  • 2080 Bhadra · 6 marks

A reinforced concrete column of size 230 mm×400 mm230\ \text{mm}\times400\ \text{mm} has 8 steel bars of 12 mm diameter and subjected to an axial compression of 600 kN, find the stresses developed in steel and concrete, take modular ratio as 18.67.

Answer

The steel and concrete shorten by the same amount, so the strain is equal and σs=m σc\sigma_s = m\,\sigma_c with the modular ratio m=Es/Ec=18.67m = E_s/E_c = 18.67.

Areas

As=8×π4(12)2=904.78 mm2Ag=230×400=92000 mm2Ac=Ag−As=91095.22 mm2\begin{aligned} A_s &= 8\times\frac{\pi}{4}(12)^2 = 904.78\ \text{mm}^2\\ A_g &= 230\times400 = 92000\ \text{mm}^2\\ A_c &= A_g - A_s = 91095.22\ \text{mm}^2 \end{aligned}

Equilibrium

P=σcAc+σsAs=σc (Ac+mAs)P = \sigma_c A_c + \sigma_s A_s = \sigma_c\,(A_c + mA_s) 600×103=σc (91095.22+18.67×904.78)=σc (107987.44)600\times10^3 = \sigma_c\,(91095.22 + 18.67\times904.78) = \sigma_c\,(107987.44) σc=5.556 N/mm2,σs=mσc=18.67×5.556=103.73 N/mm2\sigma_c = 5.556\ \text{N/mm}^2,\qquad \sigma_s = m\sigma_c = 18.67\times5.556 = 103.73\ \text{N/mm}^2

Check: load carried by concrete 506.14 kN + steel 93.86 kN = 600.00 kN.

Answer: stress in concrete = 5.56 N/mm² and stress in steel = 103.73 N/mm² (both compressive).

  • 2080 Baisakh · 8 marks

The composite section of aluminum, copper and steel bar is rigidly held by supports on left end. Find the total change in length and stresses in each bar, if the composite bar is subjected to loads at section as shown in figure. Take Ecopper=100 kN/mm2E_{copper} = 100\ \text{kN/mm}^2, Ealuminum=70 kN/mm2E_{aluminum} = 70\ \text{kN/mm}^2 and Esteel=200 kN/mm2E_{steel} = 200\ \text{kN/mm}^2. [Figure: bar fixed at the left end; aluminium bar 105 mm ϕ105\ \text{mm}\ \phi, length 300 mm, with a 50 kN load acting to the left at its right end; copper bar 85 mm ϕ85\ \text{mm}\ \phi, length 250 mm, with a 25 kN load acting to the left at its right end; steel bar 50 mm ϕ50\ \text{mm}\ \phi, length 100 mm, with a 100 kN load acting to the right at its free end.]

Answer

Order from the fixed wall: aluminium (300 mm), copper (250 mm), steel (100 mm). Loads: 50 kN (←) at the aluminium/copper junction, 25 kN (←) at the copper/steel junction and 100 kN (→) at the free end. Check: 100 kN to the right balances 50 + 25 = 75 kN to the left plus the wall reaction of 25 kN (←), so the wall pulls on the bar with 25 kN.

Axial force in each part (tension +ve, from the free end)

|=== Al ===|=== Cu ===|== St ==>  100 kN
Wall   <-50 kN     <-25 kN
  • Steel: Ns=+100N_s = +100 kN (tension)
  • Copper: Nc=100−25=+75N_c = 100 - 25 = +75 kN (tension)
  • Aluminium: Na=100−25−50=+25N_a = 100 - 25 - 50 = +25 kN (tension)

Areas

Aa=π4(105)2=8659.0,Ac=π4(85)2=5674.5,As=π4(50)2=1963.5 mm2A_a = \frac{\pi}{4}(105)^2 = 8659.0,\quad A_c = \frac{\pi}{4}(85)^2 = 5674.5,\quad A_s = \frac{\pi}{4}(50)^2 = 1963.5\ \text{mm}^2

Stresses

σa=25×1038659.0=2.887 N/mm2σc=75×1035674.5=13.217 N/mm2σs=100×1031963.5=50.930 N/mm2\begin{aligned} \sigma_a &= \frac{25\times10^3}{8659.0} = 2.887\ \text{N/mm}^2\\ \sigma_c &= \frac{75\times10^3}{5674.5} = 13.217\ \text{N/mm}^2\\ \sigma_s &= \frac{100\times10^3}{1963.5} = 50.930\ \text{N/mm}^2 \end{aligned}

Change in length (δ=NL/AE\delta = NL/AE)

δa=25×103×3008659.0×70×103=0.0124 mmδc=75×103×2505674.5×100×103=0.0330 mmδs=100×103×1001963.5×200×103=0.0255 mmδtotal=0.0709 mm\begin{aligned} \delta_a &= \frac{25\times10^3\times300}{8659.0\times70\times10^3} = 0.0124\ \text{mm}\\ \delta_c &= \frac{75\times10^3\times250}{5674.5\times100\times10^3} = 0.0330\ \text{mm}\\ \delta_s &= \frac{100\times10^3\times100}{1963.5\times200\times10^3} = 0.0255\ \text{mm}\\ \delta_{total} &= 0.0709\ \text{mm} \end{aligned}

Answer: σAl=2.89\sigma_{Al} = 2.89, σCu=13.22\sigma_{Cu} = 13.22, σSt=50.93\sigma_{St} = 50.93 N/mm² (all tensile); total elongation = 0.0709 mm.

  • 2079 Bhadra · 8 marks

A rigid bar 'ABCD' is supported at 'A' and connected with a brass rod BE and a steel rod CF at 'B' and 'C' respectively as shown in the figure. A load of 15 kN is applied at 'D'. Find the magnitude of stress in the brass rod and for the steel rod. Take Ab=1000 mm2A_b = 1000\ \text{mm}^2, As=600 mm2A_s = 600\ \text{mm}^2, Eb=100 kN/mm2E_b = 100\ \text{kN/mm}^2 and Es=200 kN/mm2E_s = 200\ \text{kN/mm}^2. [Figure: horizontal rigid bar A-B-C-D with pin at A; A to B 2 m, B to C 2 m, C to D 1 m; brass rod BE of length 2 m hung from the ceiling at B; steel rod CF of length 3 m connecting C down to the ground at F; 15 kN downward load at D.]

Answer

The load at D turns the bar clockwise about the pin A: B moves down and stretches the brass rod BE (tension, hung from the ceiling); C moves down and compresses the steel rod CF (standing on the ground). Let the forces be FbF_b (tension) and FsF_s (compression); the distances from A are B = 2 m, C = 4 m, D = 5 m.

 ceiling
   |E
   |            brass (2 m)
 A-+--2m--B--2m--C--1m--D
 pin      |      |      | 15 kN
          E      |      v
                 | steel (3 m) F on ground

Equilibrium (moments about A)

Both rods resist the load (brass pulls B up, steel pushes C up):

Fb(2)+Fs(4)=15×5=75 kN⋅mF_b(2) + F_s(4) = 15\times5 = 75\ \text{kN·m}

Compatibility

The bar is rigid, so the deflection is proportional to the distance from A: δC=2δB\delta_C = 2\delta_B.

Fs(3000)600×200=2 Fb(2000)1000×100  ⇒  25 Fs=40 Fb  ⇒  Fs=1.60 Fb\frac{F_s(3000)}{600\times200} = 2\,\frac{F_b(2000)}{1000\times100} \;\Rightarrow\; 25\,F_s = 40\,F_b \;\Rightarrow\; F_s = 1.60\,F_b

(forces in kN with E in kN/mm²).

Solution

2Fb+4(1.6Fb)=75⇒Fb=8.929 kN,Fs=14.286 kNσb=8928.61000=8.93 N/mm2σs=14285.7600=23.81 N/mm2\begin{aligned} 2F_b + 4(1.6F_b) &= 75 \Rightarrow F_b = 8.929\ \text{kN},\quad F_s = 14.286\ \text{kN}\\ \sigma_b &= \frac{8928.6}{1000} = 8.93\ \text{N/mm}^2\\ \sigma_s &= \frac{14285.7}{600} = 23.81\ \text{N/mm}^2 \end{aligned}

Answer: σbrass=8.93\sigma_{brass} = 8.93 N/mm² (tension) and σsteel=23.81\sigma_{steel} = 23.81 N/mm² (compression).

  • 2078 Bhadra · 8 marks

At what distance 'x' from the fixed end of the uniform bar should the '2t' force be applied in order that the net overall change in length of the bar will be zero? [Figure: bar fixed at the left end, length 5 m in total split into 1 m, 2 m and 2 m; forces of 1.5 t acting to the right at 1 m and at 3 m from the fixed end, and a force of 1.5 t acting to the left at the free end.]

Answer

Let the bar have uniform area AA and modulus EE. The bar is fixed at the left end, and the loads are (positions from the fixed end): 1.5 t (→) at 1 m, 1.5 t (→) at 3 m, 1.5 t (←) at the free end (5 m). The 2 t force is applied at distance xx from the fixed end; to cancel a net shortening it must act away from the wall (→).

Force in each portion (tension +ve) without the 2 t force

Take the sum of the forces to the right of the section:

PortionLength (m)Axial force (t)
0 – 1 m11.5+1.5−1.5=+1.51.5 + 1.5 - 1.5 = +1.5
1 – 3 m21.5−1.5=01.5 - 1.5 = 0
3 – 5 m2−1.5-1.5
δwithout=1AE[1.5(1)+0(2)+(−1.5)(2)]=−1.5AE (t⋅m)\delta_{without} = \frac{1}{AE}\left[1.5(1) + 0(2) + (-1.5)(2)\right] = \frac{-1.5}{AE}\ \text{(t·m)}

The bar is net shortened, so a tensile 2 t force must lengthen it by 1.5/AE1.5/AE.

Effect of the 2 t force at distance xx

It adds +2+2 t of tension in every portion between the wall and xx, so it adds 2x/AE2x/AE to the length:

−1.5+2x=0⇒x=0.75 m-1.5 + 2x = 0 \Rightarrow x = 0.75\ \text{m}

Since x=0.75<1x = 0.75 < 1 m, the force lies in the first portion, as assumed.

Check: portions become 0 – 0.75 m: +3.5+3.5 t; 0.75 – 1 m: +1.5+1.5 t; 1 – 3 m: 0; 3 – 5 m: −1.5-1.5 t. Sum =3.5(0.75)+1.5(0.25)+0−1.5(2)=2.625+0.375−3=0= 3.5(0.75) + 1.5(0.25) + 0 - 1.5(2) = 2.625 + 0.375 - 3 = 0.

Answer: x=0.75x = 0.75 m from the fixed end, with the 2 t force acting away from the fixed end.

  • 2078 Kartik · 8 marks

Two 150 mm×75 mm×4 m150\ \text{mm}\times75\ \text{mm}\times4\ \text{m} long timber members are reinforced with a steel plate 150 mm×6 mm×4 m150\ \text{mm}\times6\ \text{mm}\times4\ \text{m} long as shown in figure. The three members are adequately bolted together. The permissible stresses for the timber and the steel members are 6 N/mm26\ \text{N/mm}^2 and 130 N/mm2130\ \text{N/mm}^2 respectively. E for timber is 8.4 GN/m28.4\ \text{GN/m}^2 and for steel is 210 GN/m2210\ \text{GN/m}^2. Calculate the permissible tensile load for the composite member and the amount of elongation due to this load. [Figure: cross-section 150 mm deep: timber 75 mm, steel plate 6 mm, timber 75 mm side by side.]

Answer

The members are bolted together, so they extend equally: εt=εs\varepsilon_t = \varepsilon_s and σs/Es=σt/Et\sigma_s/E_s = \sigma_t/E_t.

m=EsEt=2108.4=25.0,σs=m σtm = \frac{E_s}{E_t} = \frac{210}{8.4} = 25.0,\qquad \sigma_s = m\,\sigma_t

Areas

At=2×(150×75)=22500 mm2,As=150×6=900 mm2A_t = 2\times(150\times75) = 22500\ \text{mm}^2,\qquad A_s = 150\times6 = 900\ \text{mm}^2

Which material governs?

  • If timber reaches 6 N/mm², steel would be at 25×6=15025\times6 = 150 N/mm² >130> 130 N/mm² (not permitted).
  • If steel reaches 130 N/mm², timber is at 130/25=5.2130/25 = 5.2 N/mm² <6< 6 N/mm² (safe).

Hence the steel plate governs: σs=130\sigma_s = 130 N/mm² and σt=5.2\sigma_t = 5.2 N/mm².

Permissible load

P=σsAs+σtAt=130×900+5.2×22500=117000+117000=234000 N=234.0 kNP = \sigma_s A_s + \sigma_t A_t = 130\times900 + 5.2\times22500 = 117000 + 117000 = 234000\ \text{N} = 234.0\ \text{kN}

Elongation (L = 4 m = 4000 mm)

δ=σsEsL=130210×103×4000=2.476 mm\delta = \frac{\sigma_s}{E_s}L = \frac{130}{210\times10^3}\times4000 = 2.476\ \text{mm}

Answer: permissible tensile load = 234.0 kN; elongation = 2.476 mm.

  • 2076 Asoj · 6 marks

In an experiment, a bar of 30 mm diameter is subjected to a pull of 60 kN. The measured extension on guage length of 200 mm is 0.09 mm and the change in diameter is 0.0039 mm. Calculate the values of Poisson's ratio and three elastic moduli.

Answer

Longitudinal quantities

A=π4(30)2=706.86 mm2σ=PA=60×103706.86=84.883 N/mm2εlong=δLL=0.09200=0.000450E=σε=84.8830.000450=188628 N/mm2=188.6 kN/mm2\begin{aligned} A &= \frac{\pi}{4}(30)^2 = 706.86\ \text{mm}^2\\ \sigma &= \frac{P}{A} = \frac{60\times10^3}{706.86} = 84.883\ \text{N/mm}^2\\ \varepsilon_{long} &= \frac{\delta L}{L} = \frac{0.09}{200} = 0.000450\\ E &= \frac{\sigma}{\varepsilon} = \frac{84.883}{0.000450} = 188628\ \text{N/mm}^2 = 188.6\ \text{kN/mm}^2 \end{aligned}

Poisson's ratio

εlat=δdd=0.003930=0.000130,μ=εlatεlong=0.0001300.000450=0.2889\varepsilon_{lat} = \frac{\delta d}{d} = \frac{0.0039}{30} = 0.000130,\qquad \mu = \frac{\varepsilon_{lat}}{\varepsilon_{long}} = \frac{0.000130}{0.000450} = 0.2889

Other moduli

G=E2(1+μ)=1886282(1+0.2889)=73175 N/mm2K=E3(1−2μ)=1886283(1−2×0.2889)=148917 N/mm2\begin{aligned} G &= \frac{E}{2(1+\mu)} = \frac{188628}{2(1+0.2889)} = 73175\ \text{N/mm}^2\\ K &= \frac{E}{3(1-2\mu)} = \frac{188628}{3(1-2\times0.2889)} = 148917\ \text{N/mm}^2 \end{aligned}

Answer: μ=0.289\mu = 0.289; E=188.6E = 188.6 kN/mm²; G=73.2G = 73.2 kN/mm²; K=148.9K = 148.9 kN/mm².

  • 2076 Asoj · 10 marks

A composite bar made up of steel and aluminum is rigidly fixed between two supports as shown in figure. The two bars are free of stress at initial temperature of 25∘C25^\circ\text{C}. Find the stresses in the two bars when the temperature increases to 50∘C50^\circ\text{C} if, i) The support are unyielding ii) The supports move away from each other by 0.1 mm. [Given: Es=200 GPaE_s = 200\ \text{GPa}, EA=70 GPaE_A = 70\ \text{GPa}, αs=13×10−6/∘C\alpha_s = 13\times10^{-6}/^\circ\text{C}, αA=23.1×10−6/∘C\alpha_A = 23.1\times10^{-6}/^\circ\text{C}] [Figure: steel bar of 4 cm4\ \text{cm} diameter and length 50 cm, joined to an aluminium bar of 6 cm6\ \text{cm} diameter and length 70 cm, both fixed between rigid supports at the ends.]

Answer

The bars are joined in series between rigid supports. On heating, both expand; the supports resist and the same compressive force PP acts in both bars.

Data

As=π4(40)2=1256.64 mm2,Aa=π4(60)2=2827.43 mm2,ΔT=50−25=25∘CA_s = \frac{\pi}{4}(40)^2 = 1256.64\ \text{mm}^2,\qquad A_a = \frac{\pi}{4}(60)^2 = 2827.43\ \text{mm}^2,\qquad \Delta T = 50-25 = 25^\circ\text{C}

Free thermal expansion

δT,s=13×10−6×25×500=0.1625 mmδT,a=23.1×10−6×25×700=0.4042 mmδT=0.5667 mm\begin{aligned} \delta_{T,s} &= 13\times10^{-6}\times25\times500 = 0.1625\ \text{mm}\\ \delta_{T,a} &= 23.1\times10^{-6}\times25\times700 = 0.4042\ \text{mm}\\ \delta_T &= 0.5667\ \text{mm} \end{aligned}

Flexibility of the two bars in series:

LsAsEs+LaAaEa=5001256.64×200×103+7002827.43×70×103=5.52621e−06 mm/N\frac{L_s}{A_sE_s}+\frac{L_a}{A_aE_a} = \frac{500}{1256.64\times200\times10^3}+\frac{700}{2827.43\times70\times10^3} = 5.52621e-06\ \text{mm/N}

(i) Unyielding supports

P×5.52621e−06=0.5667⇒P=102556.7 N=102.56 kNP\times5.52621e-06 = 0.5667 \Rightarrow P = 102556.7\ \text{N} = 102.56\ \text{kN} σs=102556.71256.64=81.61 N/mm2,σa=102556.72827.43=36.27 N/mm2 (both compressive)\sigma_s = \frac{102556.7}{1256.64} = 81.61\ \text{N/mm}^2,\qquad \sigma_a = \frac{102556.7}{2827.43} = 36.27\ \text{N/mm}^2\ \text{(both compressive)}

(ii) Supports move apart by 0.1 mm

Only the expansion not accommodated by the yielding is prevented: δ=0.5667−0.1=0.4667\delta = 0.5667 - 0.1 = 0.4667 mm.

P=0.46675.52621e−06=84461.1 N=84.46 kNP = \frac{0.4667}{5.52621e-06} = 84461.1\ \text{N} = 84.46\ \text{kN} σs=67.21 N/mm2,σa=29.87 N/mm2 (compressive)\sigma_s = 67.21\ \text{N/mm}^2,\qquad \sigma_a = 29.87\ \text{N/mm}^2\ \text{(compressive)}

Answer: (i) steel 81.61 N/mm², aluminium 36.27 N/mm²; (ii) steel 67.21 N/mm², aluminium 29.87 N/mm² (all compressive).

  • 2076 Chaitra · 6 marks

Find the total elongation in the bar. Take E for the material as the 200 GPa. A Steel bar of 600 mm2600\ \text{mm}^2 cross-sectional area is carrying loads as shown in the figure given below. [Figure: bar A-B-C-D; 90 kN acting to the left at A, 20 kN acting to the right at B, 30 kN acting to the right at C, 40 kN acting to the right at D; A-B 750 mm, B-C 1000 mm, C-D 750 mm.]

Answer

Loads: 90 kN (←) at A, 20 kN (→) at B, 30 kN (→) at C, 40 kN (→) at D. Check: 20 + 30 + 40 = 90 kN, so the bar is in equilibrium.

Axial force in each portion (tension +ve)

 90 kN <--A-----750-----B--------1000--------C----750----D--> 40 kN
                        |                    |
                      20 kN                30 kN
                        v (to the right)

Using the section method from the left end:

PortionLength (mm)Axial force
AB750+90+90 kN (tension)
BC100090−20=+7090 - 20 = +70 kN (tension)
CD75070−30=+4070 - 30 = +40 kN (tension)

Elongation

δ=1AE∑NiLi=90×103(750)+70×103(1000)+40×103(750)600×200×103=167500000120000000δAB=0.5625 mm,δBC=0.5833 mm,δCD=0.2500 mmδtotal=1.3958 mm\begin{aligned} \delta &= \frac{1}{AE}\sum N_iL_i = \frac{90\times10^3(750)+70\times10^3(1000)+40\times10^3(750)}{600\times200\times10^3}\\ &= \frac{167500000}{120000000}\\ \delta_{AB} &= 0.5625\ \text{mm},\quad \delta_{BC} = 0.5833\ \text{mm},\quad \delta_{CD} = 0.2500\ \text{mm}\\ \delta_{total} &= 1.3958\ \text{mm} \end{aligned}

Answer: total elongation = 1.396 mm.

  • 2076 Chaitra · 10 marks

A Circular bar ABCD, rigidly fixed at A and D is subjected to axial loads of 50 KN and 100 KN at B and C as shown in the figure. Find the loads shared by each part of the bar and displacements of the points B and C. Take E for the steel as 200GPa. [Figure: bar fixed at A and D; segment AB diameter 25 mm length 300 mm; segment BC diameter 50 mm length 400 mm; segment CD diameter 75 mm length 500 mm; 50 kN load at B and 100 kN load at C in opposite directions.]

Answer

Assumed loading: the 50 kN load at B acts towards D (→) and the 100 kN load at C acts towards A (←). Let the axial force in AB be xx (tension +ve).

Equilibrium of joints

NAB=x,NBC=x−50,NCD=NBC+100=x+50  (kN)N_{AB} = x,\qquad N_{BC} = x - 50,\qquad N_{CD} = N_{BC} + 100 = x + 50\ \ (\text{kN})

Compatibility

A and D are fixed, so the total change in length is zero:

∑NiLiAiE=0\sum \frac{N_iL_i}{A_iE} = 0
Partd (mm)A (mm²)L (mm)L/AL/A (mm⁻¹)
AB25490.873000.6112
BC501963.504000.2037
CD754417.865000.1132
x (0.6112+0.2037+0.1132)−50(0.2037)+50(0.1132)=0  ⇒  0.9281 x=4.525x\,(0.6112+0.2037+0.1132) - 50(0.2037) + 50(0.1132) = 0 \;\Rightarrow\; 0.9281\,x = 4.525

so x=NAB=4.878x = N_{AB} = 4.878 kN (the common factor 1/E1/E cancels).

Loads shared by each part

NAB=4.88 kN,NBC=−45.12 kN,NCD=54.88 kNN_{AB} = 4.88\ \text{kN},\quad N_{BC} = -45.12\ \text{kN},\quad N_{CD} = 54.88\ \text{kN}

Positive is tension, negative is compression.

Displacements (E=200×103E = 200\times10^3 N/mm²)

δB=NABLABAABE=0.0149 mm (towards D if +ve)δC=δB+NBCLBCABCE=−0.0311 mm\begin{aligned} \delta_B &= \frac{N_{AB}L_{AB}}{A_{AB}E} = 0.0149\ \text{mm}\ (\text{towards D if +ve})\\ \delta_C &= \delta_B + \frac{N_{BC}L_{BC}}{A_{BC}E} = -0.0311\ \text{mm} \end{aligned}

Check: δD=δC+NCDLCD/(ACDE)=0.000000≈0\delta_D = \delta_C + N_{CD}L_{CD}/(A_{CD}E) = 0.000000\approx0.

Answer: NAB=4.88N_{AB} = 4.88 kN, NBC=−45.12N_{BC} = -45.12 kN, NCD=54.88N_{CD} = 54.88 kN; δB=0.0149\delta_B = 0.0149 mm, δC=−0.0311\delta_C = -0.0311 mm (positive towards D).

  • 2075 Chaitra · 10 marks

A steel rod of cross sectional area 1000 mm21000\ \text{mm}^2 and two brass rod each of cross sectional area 800 mm2800\ \text{mm}^2 together support the load of 50KN. Calculate the stresses in the rod. Take E for steel as 200GPa and E for brass as 100 GPa. [Figure: a rigid plate carrying the load (marked 60 kN in the figure, 50 kN in the text) is supported by a central steel rod and two brass rods; the steel rod is 200 mm long and the brass rods are 250 mm long, standing on a common base.]

Answer

The rigid plate rests on all three rods, so each rod shortens by the same amount: δs=δb\delta_s = \delta_b. The problem states 50 kN in the text (the figure shows 60 kN); the solution is worked for 50 kN, and the 60 kN values follow in proportion.

Compatibility

σsLsEs=σbLbEb⇒σs(200)200×103=σb(250)100×103⇒σb=0.40 σs\frac{\sigma_s L_s}{E_s} = \frac{\sigma_b L_b}{E_b} \Rightarrow \frac{\sigma_s(200)}{200\times10^3} = \frac{\sigma_b(250)}{100\times10^3} \Rightarrow \sigma_b = 0.40\,\sigma_s

Equilibrium

P=σsAs+2σbAb=σs[1000+2(800)(0.40)]=σs (1640)P = \sigma_sA_s + 2\sigma_bA_b = \sigma_s\left[1000 + 2(800)(0.40)\right] = \sigma_s\,(1640) 50×103=1640 σs⇒σs=30.488 N/mm2,σb=12.195 N/mm250\times10^3 = 1640\,\sigma_s \Rightarrow \sigma_s = 30.488\ \text{N/mm}^2,\quad \sigma_b = 12.195\ \text{N/mm}^2

Load carried: steel 30.49 kN, each brass rod 9.76 kN (total 50.00 kN).

Answer: for 50 kN, σsteel=30.49\sigma_{steel} = 30.49 N/mm² and σbrass=12.20\sigma_{brass} = 12.20 N/mm² (compressive). If the load is 60 kN, the stresses become 36.59 N/mm² and 14.63 N/mm².

  • 2074 Asoj · 8 marks

A block of steel 300 mm×150 mm×100 mm300\ \text{mm}\times150\ \text{mm}\times100\ \text{mm} is subjected to axial loads as shown in figure below. Find the change in the dimensions of the bar and change in volume for the material of the block. Take Es=200 GN/m2E_s = 200\ \text{GN/m}^2 and poisson's ratio (σ\sigma) = 0.30. [Figure: block with dimensions 300 mm (along Z), 150 mm (along Y) and 100 mm (along X); forces: 500 kN along Z (pulling at the top and bottom), 700 kN along X (tensile at both ends), 900 kN along Y (compressive).]

Answer

Take x = 100 mm, y = 150 mm, z = 300 mm. Tension is positive. E=200×103E = 200\times10^3 N/mm², μ=0.30\mu = 0.30.

Stresses (load ÷ area of the loaded face)

σz=500×103100×150=33.333 N/mm2 (tension)σx=700×103150×300=15.556 N/mm2 (tension)σy=−900×103100×300=−30.000 N/mm2 (compression)\begin{aligned} \sigma_z &= \frac{500\times10^3}{100\times150} = 33.333\ \text{N/mm}^2\ (\text{tension})\\ \sigma_x &= \frac{700\times10^3}{150\times300} = 15.556\ \text{N/mm}^2\ (\text{tension})\\ \sigma_y &= -\frac{900\times10^3}{100\times300} = -30.000\ \text{N/mm}^2\ (\text{compression}) \end{aligned}

Strains (generalised Hooke's law)

εx=1E[σx−μ(σy+σz)]=1200×103[15.556−0.3(−30.000+33.333)]=7.2778e−05εy=1E[σy−μ(σx+σz)]=−2.2333e−04εz=1E[σz−μ(σx+σy)]=1.8833e−04\begin{aligned} \varepsilon_x &= \frac{1}{E}\left[\sigma_x - \mu(\sigma_y+\sigma_z)\right] = \frac{1}{200\times10^3}\left[15.556 - 0.3(-30.000+33.333)\right] = 7.2778e-05\\ \varepsilon_y &= \frac{1}{E}\left[\sigma_y - \mu(\sigma_x+\sigma_z)\right] = -2.2333e-04\\ \varepsilon_z &= \frac{1}{E}\left[\sigma_z - \mu(\sigma_x+\sigma_y)\right] = 1.8833e-04 \end{aligned}

Change in dimensions

δx=εx (100)=+0.00728 mmδy=εy (150)=−0.03350 mmδz=εz (300)=+0.05650 mm\begin{aligned} \delta_x &= \varepsilon_x\,(100) = +0.00728\ \text{mm}\\ \delta_y &= \varepsilon_y\,(150) = -0.03350\ \text{mm}\\ \delta_z &= \varepsilon_z\,(300) = +0.05650\ \text{mm} \end{aligned}

Change in volume

εv=εx+εy+εz=3.7778e−05,δV=εvV=3.7778e−05×(100×150×300)=+170.00 mm3\varepsilon_v = \varepsilon_x+\varepsilon_y+\varepsilon_z = 3.7778e-05,\qquad \delta V = \varepsilon_v V = 3.7778e-05\times(100\times150\times300) = +170.00\ \text{mm}^3

Check with εv=(1−2μ)E(σx+σy+σz)=0.4200×103(18.889)=3.7778e−05\varepsilon_v = \dfrac{(1-2\mu)}{E}(\sigma_x+\sigma_y+\sigma_z) = \dfrac{0.4}{200\times10^3}(18.889) = 3.7778e-05.

Answer: δx=+0.0073\delta_x = +0.0073 mm, δy=−0.0335\delta_y = -0.0335 mm, δz=+0.0565\delta_z = +0.0565 mm; δV=+170.0\delta V = +170.0 mm³ (an increase).

  • 2074 Asoj · 4 marks

What is the stress concentration? What effect is produced in brittle material due to stress concentration?

Answer

Stress concentration is the sudden rise of local stress near a geometric discontinuity (hole, notch, keyway, fillet, sharp change of section, crack) in a loaded member. Away from the discontinuity the stress is uniform (nominal), but at the discontinuity the stress flow lines crowd together and the peak stress becomes much higher.

The severity is measured by the stress concentration factor:

Kt=σmaxσnominalK_t = \frac{\sigma_{max}}{\sigma_{nominal}}

KtK_t depends only on the geometry (for example, for a small circular hole in a wide plate under tension Kt≈3K_t \approx 3). It is larger for sharper corners and smaller radii.

Effect in brittle material

  • A brittle material (cast iron, glass, concrete, ceramics) has no yield region, so it cannot redistribute the high local stress by plastic flow.
  • When σmax\sigma_{max} reaches the ultimate strength at the notch, a crack starts there and spreads suddenly across the section. The member fails at an average (nominal) stress much lower than its strength, with no warning and very little deformation.
  • Hence the full theoretical KtK_t must be used in the design of brittle members.
  • In a ductile material (mild steel), the material at the notch yields locally, the peak stress is shared with neighbouring fibres, and the effect on static strength is small. For repeated (fatigue) loading, however, stress concentration is dangerous for both.

Reducing stress concentration

Provide generous fillet radii, avoid sudden changes of section, use gradual tapers, and drill relief holes at crack tips.

  • 2073 Shrawan · 8 marks

Find the forces in each members of the bar system shown in figure below. Take cross sectional area of each bar as 6 cm26\ \text{cm}^2 and modulus of elasticity E as 2×105 N/mm22\times10^5\ \text{N/mm}^2. [Figure: three bars AD, BD and CD hinged to the ceiling at A, B and C and meeting at joint D; the bar BD is vertical with length 3 m, AD makes 50∘50^\circ and CD makes 40∘40^\circ with the vertical (angles as marked); a 30 kN load hangs at D.]

Answer

The three bars are hinged to the ceiling at A, B, C (on one level) and meet at D, so there are 3 unknown forces but only 2 equilibrium equations. One compatibility equation (from the displacement of D) is needed.

Data: A=600 mm2A = 600\ \text{mm}^2, E=2×105 N/mm2E = 2\times10^5\ \text{N/mm}^2, AE=1.2×108 NAE = 1.2\times10^8\ \text{N}, P=30 kNP = 30\ \text{kN}. Bar BD is vertical: LBD=3000L_{BD} = 3000 mm. AD is at 50∘50^\circ and CD at 40∘40^\circ to the vertical. Assume A and C lie on opposite sides of B.

LAD=3000cos⁡50∘=4667.2 mm,LCD=3000cos⁡40∘=3916.2 mmL_{AD} = \frac{3000}{\cos 50^\circ} = 4667.2\ \text{mm}, \qquad L_{CD} = \frac{3000}{\cos 40^\circ} = 3916.2\ \text{mm}

Equilibrium of joint D

ΣH=0:FADsin⁡50∘=FCDsin⁡40∘ΣV=0:FBD+FADcos⁡50∘+FCDcos⁡40∘=30 000\begin{aligned} \Sigma H = 0:&\quad F_{AD}\sin 50^\circ = F_{CD}\sin 40^\circ \\ \Sigma V = 0:&\quad F_{BD} + F_{AD}\cos 50^\circ + F_{CD}\cos 40^\circ = 30\,000 \end{aligned}

Compatibility

Let D move down by vv and sideways (away from A) by uu. Small-displacement elongations are:

δBD=v,δAD=vcos⁡50∘+usin⁡50∘,δCD=vcos⁡40∘−usin⁡40∘\delta_{BD} = v, \qquad \delta_{AD} = v\cos 50^\circ + u\sin 50^\circ, \qquad \delta_{CD} = v\cos 40^\circ - u\sin 40^\circ

and each force is F=AEL δF = \dfrac{AE}{L}\,\delta. Substituting into the two equilibrium equations gives two equations in uu and vv:

u=0.0384 mm,v=0.4386 mmu = 0.0384\ \text{mm}, \qquad v = 0.4386\ \text{mm}

Forces (all tensile)

BarElongation (mm)Force (kN)Stress (N/mm²)
AD0.31148.0113.34
BD0.438617.5529.24
CD0.31149.5415.90

Check: ΣH=6.13−6.13=0\Sigma H = 6.13 - 6.13 = 0 and ΣV=17.55+5.15+7.31=30.00 kN\Sigma V = 17.55 + 5.15 + 7.31 = 30.00\ \text{kN}.

Answer: FAD=8.01 kNF_{AD} = 8.01\ \text{kN}, FBD=17.55 kNF_{BD} = 17.55\ \text{kN}, FCD=9.54 kNF_{CD} = 9.54\ \text{kN} (all tension).

  • 2072 Chaitra · 8 marks

ABC is a rigid bar, wire BD is made of aluminum and EC is made of steel. Determine the stresses in rods and reactions at A. Take Aal=4 mm2A_{al} = 4\ \text{mm}^2, Ast=2 mm2A_{st} = 2\ \text{mm}^2, Eal=72 KN/m2E_{al} = 72\ \text{KN/m}^2, Est=210 KN/m2E_{st} = 210\ \text{KN/m}^2. [Figure: rigid bar A-B-C hinged at A, horizontal; aluminium wire BD from B up to the ceiling at D; steel bar EC from the ceiling at E to C, length 1 m; 30 kN load hangs at 1 m beyond C; A to B 2 m, B to C 1 m, C to load 1 m.]

Answer

Assumptions: the figure gives only the length of the steel bar (1 m). The aluminium wire BD is taken as 1 m long as well. Eal=72 GPaE_{al} = 72\ \text{GPa} and Est=210 GPaE_{st} = 210\ \text{GPa} (the units in the question are a misprint). The bar ABC is rigid and hinged at A; both rods are in tension, holding the bar against the 30 kN load.

Let FBF_B = force in aluminium wire (at 2 m from A), FCF_C = force in steel bar (at 3 m from A), load 30 kN30\ \text{kN} at 4 m from A.

Equilibrium

Taking moments about the hinge A:

2FB+3FC=30×4=120 kN⋅m2F_B + 3F_C = 30\times 4 = 120\ \text{kN·m}

Compatibility

The rigid bar rotates about A, so deflection is proportional to the distance from A:

δCδB=32\frac{\delta_C}{\delta_B} = \frac{3}{2} δB=FBLAalEal=FB(1000)4(72 000)=0.003472 FB,δC=FCLAstEst=FC(1000)2(210 000)=0.002381 FC\delta_B = \frac{F_B L}{A_{al}E_{al}} = \frac{F_B(1000)}{4(72\,000)} = 0.003472\,F_B, \qquad \delta_C = \frac{F_C L}{A_{st}E_{st}} = \frac{F_C(1000)}{2(210\,000)} = 0.002381\,F_C

(FF in N, δ\delta in mm). Hence

0.002381 FC=1.5(0.003472)FB⇒FC=2.1875 FB0.002381\,F_C = 1.5(0.003472)F_B \Rightarrow F_C = 2.1875\,F_B

Substituting in the moment equation: 2FB+3(2.1875)FB=1202F_B + 3(2.1875)F_B = 120 kN, so

FB=14.01 kN,FC=30.66 kNF_B = 14.01\ \text{kN}, \qquad F_C = 30.66\ \text{kN}

Stresses

σal=140154=3503.6 N/mm2,σst=306572=15328.5 N/mm2\sigma_{al} = \frac{14015}{4} = 3503.6\ \text{N/mm}^2, \qquad \sigma_{st} = \frac{30657}{2} = 15328.5\ \text{N/mm}^2

These are very large because the given areas are very small (if the areas were in cm², the stresses would be 100 times smaller: 35.0 and 153.3 N/mm²).

Reaction at A

ΣV=0\Sigma V = 0: RA+FB+FC=30R_A + F_B + F_C = 30 (upward positive for rods), so

RA=30−14.01−30.66=−14.67 kNR_A = 30 - 14.01 - 30.66 = -14.67\ \text{kN}

The negative sign means RA=14.67 kNR_A = 14.67\ \text{kN} acts downward.

Answer: σal=3503.6 N/mm2\sigma_{al} = 3503.6\ \text{N/mm}^2, σst=15328.5 N/mm2\sigma_{st} = 15328.5\ \text{N/mm}^2, RA=14.67 kNR_A = 14.67\ \text{kN} downward.

  • 2069 Asar · 8 marks

Determine vertical displacement of point F, if AB is a rigid bar and remains horizontal, AC and BD are rods made of steel and aluminium having diameter 20mm and 40mm respectively. E for steel and aluminium are 200GPa and 70GPa respectively. [Figure: rigid horizontal bar AB with a 90 kN load applied at F, 200 m from A (as marked), rods AC and BD vertical, 300 m high, fixed at C and D at the base; AB spans 400 m.]

Answer

Assumptions: the dimensions marked "m" in the figure are read as millimetres (rod length 300 mm, AB = 400 mm, AF = 200 mm), so F is the mid-point of AB. The rods AC (steel, 20 mm dia.) and BD (aluminium, 40 mm dia.) are vertical posts under the rigid bar (compression).

Forces in the rods

F is at the middle of AB, so the 90 kN load divides equally:

PA=PB=902=45 kNP_A = P_B = \frac{90}{2} = 45\ \text{kN}

Check by moments about B: PA×400=90×200⇒PA=45P_A \times 400 = 90\times 200 \Rightarrow P_A = 45 kN.

Shortening of each rod

Ast=π4(20)2=314.16 mm2,Aal=π4(40)2=1256.64 mm2A_{st} = \frac{\pi}{4}(20)^2 = 314.16\ \text{mm}^2, \qquad A_{al} = \frac{\pi}{4}(40)^2 = 1256.64\ \text{mm}^2 δA=PALAstEst=45 000×300314.16×200 000=0.2149 mm\delta_A = \frac{P_A L}{A_{st}E_{st}} = \frac{45\,000\times 300}{314.16\times 200\,000} = 0.2149\ \text{mm} δB=PBLAalEal=45 000×3001256.64×70 000=0.1535 mm\delta_B = \frac{P_B L}{A_{al}E_{al}} = \frac{45\,000\times 300}{1256.64\times 70\,000} = 0.1535\ \text{mm}

Displacement of F

The bar is rigid, so its vertical movement varies linearly from A to B. F is at the mid-point:

δF=δA+δB2=0.2149+0.15352=0.1842 mm\delta_F = \frac{\delta_A + \delta_B}{2} = \frac{0.2149+0.1535}{2} = 0.1842\ \text{mm}

The two rods shorten by slightly different amounts, so the bar tilts very slightly (by 0.0614400\frac{0.0614}{400} rad, negligible); for practical purposes it remains horizontal.

Answer: vertical displacement of F ≈0.184 mm\approx 0.184\ \text{mm} downward.

  • 2069 Chaitra · 2 marks

How is offset method defined in drawing stress-strain relationship? Where is it required?

Answer

Offset method: many materials (aluminium, high-strength steel, copper, cast iron) show no clear yield point, so their stress–strain curve bends gradually. In the offset method a straight line is drawn parallel to the initial straight (elastic) portion of the curve, starting from a chosen permanent strain on the strain axis (usually 0.2% offset, i.e. ε=0.002\varepsilon = 0.002). The stress at which this line cuts the curve is taken as the proof stress (offset yield strength).

 stress
   |            ___------  curve
   |        _--'
   |      ,'  .  <- yield (proof) point
   |    ,' . /
   |   / . /   parallel to OA
   |  / /
   | //
   |/_/____________________ strain
   O  0.002

Where it is required: for materials without a definite yield point, to define a practical yield strength for design (permissible stress = proof stress divided by factor of safety).

  • 2069 Chaitra · 6 marks

A vertical rod of length 3m tapers uniformly from a diameter of 80mm at the top to 40mm at the bottom. If it is rigidly fixed at the upper end and is subjected to an axial load of 45KN, determine the total extension in the bar. Take density of material = 2×105 kg/m32\times10^5\ \text{kg/m}^3 and young's modulus = 210 GN/m2210\ \text{GN/m}^2.

Answer

The rod is a frustum of a cone, fixed at the top (d₁ = 80 mm) with the 45 kN load at the bottom (d₂ = 40 mm). The extension has two parts: that due to the axial load and that due to the rod's own weight.

Data: L=3000L = 3000 mm, E=210×103 N/mm2E = 210\times10^3\ \text{N/mm}^2, P=45 000P = 45\,000 N, ρ=2×105 kg/m3\rho = 2\times10^5\ \text{kg/m}^3 (as given), g=9.81 m/s2g = 9.81\ \text{m/s}^2.

Extension due to the load

For a uniformly tapering circular bar:

δP=4PLπEd1d2=4(45 000)(3000)π(210 000)(80)(40)=0.2558 mm\delta_P = \frac{4PL}{\pi E d_1 d_2} = \frac{4(45\,000)(3000)}{\pi(210\,000)(80)(40)} = 0.2558\ \text{mm}

Extension due to self weight

Volume of the frustum V=πL12(d12+d1d2+d22)=0.008796 m3V = \dfrac{\pi L}{12}(d_1^2 + d_1d_2 + d_2^2) = 0.008796\ \text{m}^3, so the weight is

W=ρgV=2×105(9.81)(0.008796)=17.26 kNW = \rho g V = 2\times10^5(9.81)(0.008796) = 17.26\ \text{kN}

Let yy be measured up from the bottom, with diameter d=d2+kyd = d_2 + ky where k=d1−d2L=0.01333k = \dfrac{d_1-d_2}{L} = 0.01333. The weight below that section is ρgπ12k(d3−d23)\dfrac{\rho g\pi}{12k}(d^3-d_2^3), and the self-weight extension is

δw=∫0L(weight below)E π4d2 dy=ρg3k2E[d12−d222+d23(1d1−1d2)]=0.0280 mm\delta_w = \int_0^L \frac{\text{(weight below)}}{E\,\frac{\pi}{4}d^2}\,dy = \frac{\rho g}{3k^2E}\left[\frac{d_1^2-d_2^2}{2} + d_2^3\left(\frac{1}{d_1}-\frac{1}{d_2}\right)\right] = 0.0280\ \text{mm}

Total extension

δ=δP+δw=0.2558+0.0280=0.2838 mm\delta = \delta_P + \delta_w = 0.2558 + 0.0280 = 0.2838\ \text{mm}

Answer: total extension ≈0.284 mm\approx 0.284\ \text{mm}.

  • 2069 Chaitra · 8 marks

A rigid bar AB is hinged at A and supported by a 2m long copper rod and a 1m long steel rod. It carries a load of 100 KN at the free end B as shown in figure below. If the area of cross-section of the steel and copper rods be 10 cm210\ \text{cm}^2 and 8 cm28\ \text{cm}^2 respectively and their respective values of E be 200 GN/m2200\ \text{GN/m}^2 and 100 GN/m2100\ \text{GN/m}^2, find stresses in each rod and reaction at A (assume no bending in steel and copper rods). [Figure: horizontal rigid bar B-A with hinge at A (right end); a copper rod (2 m long) and a steel rod (1 m long) connect the bar to the ceiling, spaced 1 m, 2 m and 1 m along the bar from B; 100 kN load at B.]

Answer

Assumptions (from the figure): measured from B the supports are at 1 m (copper rod, 2 m long), then 3 m (steel rod, 1 m long), and the hinge A is at 4 m. So the lever arms from A are: steel 1 m, copper 3 m, load 4 m. Both rods are in tension and the bar is rigid.

Data: As=1000 mm2A_s = 1000\ \text{mm}^2, Ac=800 mm2A_c = 800\ \text{mm}^2, Es=200 GPaE_s = 200\ \text{GPa}, Ec=100 GPaE_c = 100\ \text{GPa}, Ls=1L_s = 1 m, Lc=2L_c = 2 m.

Equilibrium (moments about A)

Fs(1)+Fc(3)=100(4)=400 kN⋅mF_s(1) + F_c(3) = 100(4) = 400\ \text{kN·m}

Compatibility

The rigid bar rotates about A, so δc=3δs\delta_c = 3\delta_s:

FcLcAcEc=3 FsLsAsEs⇒Fc(2)800×10−6(100×109)=3 Fs(1)1000×10−6(200×109)\frac{F_c L_c}{A_cE_c} = 3\,\frac{F_s L_s}{A_sE_s} \Rightarrow \frac{F_c(2)}{800\times10^{-6}(100\times10^9)} = 3\,\frac{F_s(1)}{1000\times10^{-6}(200\times10^9)} Fc=0.6 FsF_c = 0.6\,F_s

Forces and stresses

Fs+3(0.6Fs)=400⇒2.8Fs=400F_s + 3(0.6F_s) = 400 \Rightarrow 2.8F_s = 400

Fs=142.86 kN,Fc=85.71 kNF_s = 142.86\ \text{kN}, \qquad F_c = 85.71\ \text{kN} σs=1428571000=142.86 MPa,σc=85714800=107.14 MPa\sigma_s = \frac{142857}{1000} = 142.86\ \text{MPa}, \qquad \sigma_c = \frac{85714}{800} = 107.14\ \text{MPa}

Reaction at A

ΣV=0:RA=Fs+Fc−100=142.86+85.71−100=128.57 kN\Sigma V = 0: \quad R_A = F_s + F_c - 100 = 142.86 + 85.71 - 100 = 128.57\ \text{kN}

The rods pull the bar up with more than the 100 kN load, so RAR_A acts downward.

Answer: σs=142.86 MPa\sigma_s = 142.86\ \text{MPa}, σc=107.14 MPa\sigma_c = 107.14\ \text{MPa} (both tensile), RA=128.57 kNR_A = 128.57\ \text{kN} downward.

  • 2069 Chaitra · 6 marks

A steel bar of 2.5 cm diameter when subjected to a torque of 300N produces an angle of twist of 1.35 degrees in the length of 25cm. The same bar when subjected to tension elongates 0.01cm in length of 15cm under a load of 70KN. Deduce the value of poisson's ratio for the material.

Answer

Poisson's ratio follows from E=2G(1+ν)E = 2G(1+\nu). Find GG from the torsion test and EE from the tension test. The torque is taken as 300 N·m (=3×105= 3\times10^5 N·mm).

Modulus of rigidity (torsion test)

J=πd432=π(25)432=38349.5 mm4,θ=1.35∘=0.02356 radJ = \frac{\pi d^4}{32} = \frac{\pi (25)^4}{32} = 38349.5\ \text{mm}^4, \qquad \theta = 1.35^\circ = 0.02356\ \text{rad} TJ=GθL⇒G=TLJθ=3×105×25038349.5×0.02356=83002 N/mm2\frac{T}{J} = \frac{G\theta}{L} \Rightarrow G = \frac{TL}{J\theta} = \frac{3\times10^5 \times 250}{38349.5\times 0.02356} = 83002\ \text{N/mm}^2

Modulus of elasticity (tension test)

A=π4(25)2=490.87 mm2A = \dfrac{\pi}{4}(25)^2 = 490.87\ \text{mm}^2, δ=0.01 cm=0.1 mm\delta = 0.01\ \text{cm} = 0.1\ \text{mm}, L=150L = 150 mm.

E=PLAδ=70 000×150490.87×0.1=213904 N/mm2E = \frac{PL}{A\delta} = \frac{70\,000\times150}{490.87\times0.1} = 213904\ \text{N/mm}^2

Poisson's ratio

ν=E2G−1=2139042(83002)−1=0.289\nu = \frac{E}{2G} - 1 = \frac{213904}{2(83002)} - 1 = 0.289

Answer: ν≈0.289\nu \approx 0.289.

  • 2068 Chaitra · 8 marks

Two vertical rods of steel and copper are rigidly fixed with the ceiling at their ends at 100cm apart. Each rod is 3m long and 25mm diameter. A horizontal cross piece connects the lower ends of the rods. Where should a load of 3.5 tonnes be placed on the cross piece so that it remains horizontal after being loaded. Take Es=2×106 kg/cm2E_s = 2\times10^6\ \text{kg/cm}^2, Ec=1.0×106 kg/cm2E_c = 1.0\times10^6\ \text{kg/cm}^2.

Answer

Idea: the cross piece stays horizontal only if both rods stretch equally. The rods have the same area and length, so the load carried by each rod must be proportional to its EE.

Let the steel rod carry PsP_s and the copper rod carry PcP_c, with Ps+Pc=3500P_s + P_c = 3500 kgf. Equal extension:

PsLAEs=PcLAEc⇒PsPc=EsEc=2×1061×106=2\frac{P_sL}{AE_s} = \frac{P_cL}{AE_c} \Rightarrow \frac{P_s}{P_c} = \frac{E_s}{E_c} = \frac{2\times10^6}{1\times10^6} = 2 Ps=23(3500)=2333.3 kgf,Pc=13(3500)=1166.7 kgfP_s = \frac{2}{3}(3500) = 2333.3\ \text{kgf}, \qquad P_c = \frac{1}{3}(3500) = 1166.7\ \text{kgf}

(Extension of each rod =2333.3×300490.87×2×106=0.0007= \dfrac{2333.3\times300}{490.87\times2\times10^6} = 0.0007 cm, the same for both rods.)

Position of the load

Let the load act at distance xx from the steel rod. Taking moments about the steel rod (rods 100 cm apart):

3500 x=Pc(100)=1166.7×100⇒x=33.33 cm3500\,x = P_c(100) = 1166.7\times100 \Rightarrow x = 33.33\ \text{cm}
   steel            copper
    |<----- 100 cm ---->|
    |                    |
  ==|====================|==  cross piece
    |  ^                 |
    |<-x->  3.5 t load   |

Answer: the load should be placed 33.33 cm from the steel rod (66.67 cm from the copper rod).

  • 2068 Chaitra · 8 marks

A rigid bar 'AB' is hinged at 'C' and connected with a steel rod and a copper rod at 'A' and 'B' respectively as shown in figure. Both the rods are rigidly fixed with the ceiling at the upper ends. A load of 40KN is applied at 'B'. Find the magnitude of stresses in the steel rod and the copper rod. Cross sectional area of steel is 400 mm2400\ \text{mm}^2 and copper is 600 mm2600\ \text{mm}^2. Take Es=200 KN/mm2E_s = 200\ \text{KN/mm}^2 and Ec=110 KN/mm2E_c = 110\ \text{KN/mm}^2. [Figure: horizontal rigid bar A-C-B with the hinge at C; A to C 4 m, C to B 2 m; steel rod at A and copper rod at B, both 1 m long, fixed to the ceiling; 40 kN load W at B.]

Answer

Assumptions: the bar is rigid and hinged at C; A is 4 m and B is 2 m from C on opposite sides. The load at B pulls B down, so the copper rod at B is in tension and the bar lifts at A, so the steel rod at A is in compression (pushing the bar down at A). Both rods are 1 m long.

Data: As=400 mm2A_s = 400\ \text{mm}^2, Es=200 kN/mm2E_s = 200\ \text{kN/mm}^2, Ac=600 mm2A_c = 600\ \text{mm}^2, Ec=110 kN/mm2E_c = 110\ \text{kN/mm}^2.

Equilibrium (moments about hinge C)

Fc(2)+Fs(4)=40(2)⇒Fc+2Fs=40 kNF_c(2) + F_s(4) = 40(2) \Rightarrow F_c + 2F_s = 40\ \text{kN}

Compatibility

If the bar rotates by a small angle ϕ\phi, then δB=2ϕ\delta_B = 2\phi (copper elongation) and δA=4ϕ\delta_A = 4\phi (steel shortening) (lengths in m, so δA=2δB\delta_A = 2\delta_B):

FsLAsEs=2 FcLAcEc⇒Fs400(200)=2Fc600(110)\frac{F_sL}{A_sE_s} = 2\,\frac{F_cL}{A_cE_c} \Rightarrow \frac{F_s}{400(200)} = \frac{2F_c}{600(110)} Fs=2×400×200600×110Fc=2.4242 FcF_s = \frac{2\times 400\times200}{600\times110}F_c = 2.4242\,F_c

Substituting: Fc+2(2.4242Fc)=40F_c + 2(2.4242F_c) = 40, which gives

Fc=6.839 kN,Fs=16.580 kNF_c = 6.839\ \text{kN}, \qquad F_s = 16.580\ \text{kN}

Stresses

σs=16580400=41.45 N/mm2 (compressive),σc=6839600=11.40 N/mm2 (tensile)\sigma_s = \frac{16580}{400} = 41.45\ \text{N/mm}^2\ \text{(compressive)}, \qquad \sigma_c = \frac{6839}{600} = 11.40\ \text{N/mm}^2\ \text{(tensile)}

Answer: steel ≈41.45 N/mm2\approx 41.45\ \text{N/mm}^2, copper ≈11.40 N/mm2\approx 11.40\ \text{N/mm}^2.

  • 2068 Baisakh (old course) · 8 marks

The modulus of rigidity for a material is 0.5×105 N/mm20.5\times10^5\ \text{N/mm}^2. A 10mm diameter rod of the material was subjected to an axial pull of 10kN and the change in diameter was observed to be 3×10−3 mm3\times10^{-3}\ \text{mm}. Calculate the Poisson's ratio and the modulus of elasticity.

Answer

Method: use the lateral strain from the change in diameter, the axial stress, and the relation E=2G(1+ν)E = 2G(1+\nu).

Stress and lateral strain

σ=PA=10 000π4(10)2=127.32 N/mm2,εlat=Δdd=3×10−310=3×10−4 (contraction)\sigma = \frac{P}{A} = \frac{10\,000}{\frac{\pi}{4}(10)^2} = 127.32\ \text{N/mm}^2, \qquad \varepsilon_{lat} = \frac{\Delta d}{d} = \frac{3\times10^{-3}}{10} = 3\times10^{-4}\ \text{(contraction)}

Poisson's ratio

Lateral strain =ν σE= \nu\,\dfrac{\sigma}{E} and E=2G(1+ν)E = 2G(1+\nu), so

εlat=νσ2G(1+ν)⇒3×10−4=ν(127.32)2(0.5×105)(1+ν)\varepsilon_{lat} = \frac{\nu\sigma}{2G(1+\nu)} \Rightarrow 3\times10^{-4} = \frac{\nu(127.32)}{2(0.5\times10^5)(1+\nu)} 127.32 ν=30(1+ν)⇒ν=30127.32−30=0.3082127.32\,\nu = 30(1+\nu) \Rightarrow \nu = \frac{30}{127.32-30} = 0.3082

Modulus of elasticity

E=2G(1+ν)=2(0.5×105)(1+0.3082)=130825 N/mm2E = 2G(1+\nu) = 2(0.5\times10^5)(1+0.3082) = 130825\ \text{N/mm}^2

Answer: ν=0.308\nu = 0.308 and E≈1.308×105 N/mm2E \approx 1.308\times10^5\ \text{N/mm}^2.

  • 2067 Asar (old course) · 4 marks

Neatly sketch stress-strain diagram for mild-steel showing salient points.

Answer

The diagram is obtained from a tension test on a mild steel specimen (nominal stress =P/A0= P/A_0 against strain =ΔL/L0= \Delta L/L_0).

 stress
   |            D (ultimate)
   |           ,-'''-.
   |       B C/       '.  E (fracture)
   |      ,-'''           x
   |     /  yield
   |    /  plateau
   |   /
   |  /  elastic
   | /A  (Hooke's law)
   |/__________________________ strain
   O
 A=proportional limit, B=upper yield, C=lower yield
 D=ultimate stress, E=breaking point

Salient points

  1. O to A, proportional limit: stress is proportional to strain (Hooke's law); the slope is EE.
  2. Elastic limit: just beyond A; material returns to its original length on unloading.
  3. Upper yield point (B) and lower yield point (C): the stress drops slightly and the specimen elongates considerably at nearly constant stress (yield plateau). Mild steel has σy≈250 N/mm2\sigma_y \approx 250\ \text{N/mm}^2.
  4. Strain hardening (C to D): the material regains strength and the curve rises to the maximum.
  5. Ultimate stress (D): the maximum nominal stress; after this, necking starts.
  6. Breaking (fracture) point (E): the nominal stress falls as the section necks, and the specimen breaks. The true stress, based on the reduced area, actually keeps rising to fracture.
  • 2066 Jestha (old course) · 8 marks

Prove that the volumetric strain is three times the longitudinal strain for a cube subjected to equal stresses in the three mutually perpendicular directions.

Answer

Statement: for a cube under equal stress σ\sigma in three mutually perpendicular directions (the same type of stress on all faces), the volumetric strain εv=3ε\varepsilon_v = 3\varepsilon, where ε\varepsilon is the linear strain along any edge.

Proof. Let the cube have side LL, so V=L3V = L^3. Under the stress, every edge changes by the same amount to L+δLL + \delta L, giving the linear strain

ε=δLL\varepsilon = \frac{\delta L}{L}

New volume:

V′=(L+δL)3=L3(1+ε)3=V(1+3ε+3ε2+ε3)V' = (L+\delta L)^3 = L^3\left(1+\varepsilon\right)^3 = V\left(1 + 3\varepsilon + 3\varepsilon^2 + \varepsilon^3\right)

Change in volume:

δV=V′−V=V(3ε+3ε2+ε3)\delta V = V' - V = V\left(3\varepsilon + 3\varepsilon^2 + \varepsilon^3\right)

As the strains are very small, ε2\varepsilon^2 and ε3\varepsilon^3 are negligible compared with ε\varepsilon:

εv=δVV≈3ε\varepsilon_v = \frac{\delta V}{V} \approx 3\varepsilon

Alternative (differentiation): from V=L3V = L^3, dV=3L2 dLdV = 3L^2\,dL, so dVV=3dLL\dfrac{dV}{V} = 3\dfrac{dL}{L}, which gives the same result.

Note (with Poisson's effect): the strain along one edge caused by the three equal stresses is ε=σE−νσE−νσE=σE(1−2ν)\varepsilon = \dfrac{\sigma}{E} - \dfrac{\nu\sigma}{E} - \dfrac{\nu\sigma}{E} = \dfrac{\sigma}{E}(1-2\nu), so

εv=3ε=3σE(1−2ν)=σK\varepsilon_v = 3\varepsilon = \frac{3\sigma}{E}(1-2\nu) = \frac{\sigma}{K}

since K=E3(1−2ν)K = \dfrac{E}{3(1-2\nu)}. Hence εv=3ε\varepsilon_v = 3\varepsilon is proved.

  • 2066 Jestha (old course) · 4 marks

Define the modulus of elasticity, modulus of rigidity, bulk modulus and Poisson's ratio.

Answer

Modulus of elasticity (Young's modulus, EE)

The ratio of normal (tensile or compressive) stress to the corresponding linear strain, within the elastic limit:

E=normal stresslinear strain=σεE = \frac{\text{normal stress}}{\text{linear strain}} = \frac{\sigma}{\varepsilon}

For mild steel, E≈2×105 N/mm2E \approx 2\times10^5\ \text{N/mm}^2.

Modulus of rigidity (shear modulus, GG)

The ratio of shear stress to shear strain within the elastic limit:

G=τϕG = \frac{\tau}{\phi}

where ϕ\phi is the shear strain (angular distortion in radians).

Bulk modulus (KK)

The ratio of the uniform (hydrostatic) stress applied on all faces to the resulting volumetric strain, within the elastic limit:

K=pδV/VK = \frac{p}{\delta V/V}

Poisson's ratio (ν\nu or 1/m1/m)

The ratio of lateral strain to longitudinal (axial) strain within the elastic limit:

ν=∣lateral strainlongitudinal strain∣\nu = \left|\frac{\text{lateral strain}}{\text{longitudinal strain}}\right|

It is about 0.25 to 0.33 for most metals. The constants are related by E=2G(1+ν)=3K(1−2ν)E = 2G(1+\nu) = 3K(1-2\nu).

Questions from Old Question Collection (CE 502) (IOE BCE Strength of Materials exam papers, 2066 to 2081 (25 papers)). Answers are written for this site; check them against your class notes.

Chapter titles and hours from the IOE syllabus ↗
