Chapter 7 · 9 hours

Kinematic Analysis of Mechanisms

Practice questions

Practice questions and answers

7 exam-style questions on this chapter, written for this site from the official syllabus. We haven’t found past IOE papers for this subject yet; if you have some, share them in the community.

  • Practice · 8 marks

Define instantaneous centre of rotation. Write the formula for the number of instantaneous centres in a mechanism and classify them. State and prove Kennedy's theorem and use it to locate all instantaneous centres of a four-bar mechanism.

Answer

Instantaneous centre (IC)

For two bodies in relative plane motion, the instantaneous centre is the point (common to both) that has no relative velocity at that instant. Each body appears to rotate about it. It is found at the intersection of the perpendiculars to the velocity directions of two points.

Number of ICs

For a mechanism of nn links, each pair of links has one IC:

N=n(n−1)2N = \frac{n(n-1)}{2}

A four-bar mechanism (n=4n = 4) has N=6N = 6 ICs.

Types

  • Fixed IC: its location is fixed in space (for example, the pivot of a link with the frame).
  • Permanent IC: its location moves, but it is a pin joint between two moving links (for example, the pin between crank and coupler).
  • Neither fixed nor permanent: both its position and its type change with the configuration, for example the IC between coupler and frame.

Kennedy's theorem (three-centre theorem)

Any three bodies in relative plane motion have three instantaneous centres, and they lie on a straight line.

Proof. Let the three bodies be 1, 2, 3 with I12I_{12} and I13I_{13} known. Assume I23I_{23} is not on the line joining I12I_{12} and I13I_{13} and take it as the point PP (as a point of body 2 and body 3). The velocity of PP as a point of body 2 is perpendicular to I12PI_{12}P, and as a point of body 3 is perpendicular to I13PI_{13}P. These two directions are different (since the lines I12PI_{12}P and I13PI_{13}P are different), while at the IC I23I_{23} the velocities of the point of body 2 and body 3 must be identical in magnitude and direction. This is possible only if PP lies on the line through I12I_{12} and I13I_{13}, where the two perpendicular directions coincide. Hence all three ICs are collinear.

Four-bar mechanism ABCD (links: 1 = AD frame, 2 = AB, 3 = BC, 4 = CD)

Obvious ICs (pin joints): I12I_{12} at A, I23I_{23} at B, I34I_{34} at C, I14I_{14} at D.

Remaining two by Kennedy's theorem:

  • I13I_{13}: lies on the line I12I23I_{12}I_{23} (AB extended) and on I14I34I_{14}I_{34} (DC extended). It is the intersection of AB and DC produced.
  • I24I_{24}: lies on I23I34I_{23}I_{34} (BC extended) and on I12I14I_{12}I_{14} (AD extended). It is the intersection of BC and AD produced.
   I13 *
        \        .
         \   B---C
          \ /     \
        A-----------D  ---- * I24

Use: ω2⋅I12I24=ω4⋅I14I24\omega_2 \cdot I_{12}I_{24} = \omega_4 \cdot I_{14}I_{24} (both equal the speed of I24I_{24}), and ω2⋅I12I23=ω3⋅I13I23\omega_2 \cdot I_{12}I_{23} = \omega_3 \cdot I_{13}I_{23} (both equal the speed of the pin B).

  • Practice · 8 marks

In a slider crank mechanism the crank OA is 150 mm long and rotates at 300 rpm anticlockwise. The connecting rod AB is 600 mm long. When the crank has turned through 40 degrees from the inner dead centre, locate the instantaneous centre of the connecting rod and find, by the instantaneous centre method, (a) the velocity of the slider B, (b) the angular velocity of the connecting rod AB, and (c) the velocity of the midpoint G of the connecting rod.

Answer

Configuration

Take O as origin and the line of stroke along the xx-axis.

ωOA=2π×30060=31.416 rad/s,vA=ωOA⋅OA=31.416×0.150=4.712 m/s\omega_{OA} = \frac{2\pi \times 300}{60} = 31.416\ \text{rad/s}, \qquad v_A = \omega_{OA}\cdot OA = 31.416 \times 0.150 = 4.712\ \text{m/s}

vAv_A is perpendicular to OA. Obliquity of the rod: sin⁡ϕ=OAsin⁡40∘AB=0.1607⇒ϕ=9.25∘\sin\phi = \dfrac{OA\sin 40^\circ}{AB} = 0.1607 \Rightarrow \phi = 9.25^\circ.

Coordinates: A =(114.9, 96.4)= (114.9,\ 96.4) mm, B =(707.1, 0)= (707.1,\ 0) mm.

Locating the instantaneous centre I13I_{13} (connecting rod)

  • The velocity of A is perpendicular to OA, so II lies on the line OA produced.
  • The velocity of B is along the line of stroke, so II lies on the perpendicular to the line of stroke at B.

The intersection gives II at (707.1, 593.3)(707.1,\ 593.3) mm.

           I  (instantaneous centre)
          /|
        /  |
      A/   |        IA = 773.1 mm
     /\    |        IB = 593.3 mm
   O/__\___|__B ->
IA=(707.1−114.9)2+(593.3−96.4)2=773.1 mm,IB=593.3 mmIA = \sqrt{(707.1 - 114.9)^2 + (593.3 - 96.4)^2} = 773.1\ \text{mm}, \qquad IB = 593.3\ \text{mm}

(b) Angular velocity of the rod

The rod rotates about II, so vA=ωAB⋅IAv_A = \omega_{AB}\cdot IA:

ωAB=vAIA=4.712773.1/1000=6.096 rad/s\omega_{AB} = \frac{v_A}{IA} = \frac{4.712}{773.1/1000} = 6.096\ \text{rad/s}

(clockwise: A lies to the lower left of II and moves to the upper left.)

(a) Velocity of slider

vB=ωAB⋅IB=6.096×593.31000=3.617 m/sv_B = \omega_{AB}\cdot IB = 6.096 \times \frac{593.3}{1000} = 3.617\ \text{m/s}

(towards the crank end, towards O.)

Check with the analytic result vB=ωr[sin⁡θ+rsin⁡2θ2l2−r2sin⁡2θ]=3.617v_B = \omega r\left[\sin\theta + \dfrac{r\sin2\theta}{2\sqrt{l^2 - r^2\sin^2\theta}}\right] = 3.617 m/s. It agrees.

(c) Velocity of midpoint G

Distance from I to G (G is the midpoint of AB): IG=620.4IG = 620.4 mm.

vG=ωAB⋅IG=6.096×620.41000=3.781 m/sv_G = \omega_{AB}\cdot IG = 6.096 \times \frac{620.4}{1000} = 3.781\ \text{m/s}

perpendicular to IG.

Answer: vB=3.617v_B = 3.617 m/s, ωAB=6.096\omega_{AB} = 6.096 rad/s (clockwise), vG=3.781v_G = 3.781 m/s.

  • Practice · 6 marks

Explain the relative velocity method for finding velocities in a mechanism. Show, with the help of a four-bar mechanism ABCD (AD fixed), the steps for drawing the velocity polygon, finding the angular velocities of the coupler BC and follower CD, and obtaining the velocity of a point E on the coupler using the velocity image principle.

Answer

Principle

For two points A and B on the same rigid link, the velocity of B relative to A is perpendicular to AB, and its magnitude is ω⋅AB\omega \cdot AB:

v⃗B=v⃗A+v⃗BA,vBA=ωAB⋅AB  (⊥AB)\vec v_B = \vec v_A + \vec v_{BA}, \qquad v_{BA} = \omega_{AB}\cdot AB \ \ (\perp AB)

The vector equation is solved by drawing a velocity polygon: each vector has known direction, and the magnitude of at least one is known.

Four-bar mechanism ABCD (crank AB with ω2\omega_2, AD fixed)

  1. Draw the configuration diagram to scale (space diagram).
  2. Compute the velocity of B: vB=ω2⋅ABv_{B} = \omega_2 \cdot AB, perpendicular to AB. Choose a velocity scale (for example 1 cm = 0.5 m/s).
  3. Choose a pole oo (the zero velocity point for fixed A and D). Draw obob perpendicular to AB, of length proportional to vBv_B.
  4. Vector for C relative to B: from bb draw a line perpendicular to BC (direction of vCBv_{CB}).
  5. Vector for C relative to D: from oo (as D is fixed) draw a line perpendicular to CD (direction of vCv_C).
  6. The intersection of these two lines is point cc. Then ococ is the velocity of C, and bcbc is the velocity of C relative to B.
  7. Scale the lengths:
ω3=vCBBC=bcBC,ω4=vCCD=ocCD\omega_3 = \frac{v_{CB}}{BC} = \frac{bc}{BC}, \qquad \omega_4 = \frac{v_C}{CD} = \frac{oc}{CD}

Sense: ω3\omega_3 is found by placing the vector bcbc at C on the space diagram (viewed from B); ω4\omega_4 by placing ococ at C (about D).

 velocity polygon        space diagram
      b                  B-------C
     /|\                 |        \
    / | \                A         D
   o--+--c

Velocity of a point E on BC (velocity image)

The triangle bcebce in the polygon is similar to the triangle BCE on the link (the polygon of points on a rigid link is an image of the link, rotated by 90∘90^\circ). So:

  1. Draw bebe so that bebc=BEBC\dfrac{be}{bc} = \dfrac{BE}{BC} on the line bcbc (for E on BC).
  2. For E off the line BC, make triangle bcebce similar to BCE with the same letter order.
  3. Join oo to ee. Then oeoe gives the velocity of E.

Points to remember

  • Points of fixed pivots are at the pole oo.
  • Same letter order and same sense in the image as on the link.
  • The angular velocity of a link is the same for all its points: ω=relative velocity vectorlength of link\omega = \dfrac{\text{relative velocity vector}}{\text{length of link}}.
  • Practice · 3+3 marks

(a) A ladder AB, 4 m long, rests with its foot A on a horizontal floor and its top B against a vertical wall. The ladder makes 60 degrees with the floor and the foot A is pulled away from the wall at 2 m/s. Locate the instantaneous centre and find the angular velocity of the ladder, the velocity of B and the velocity of the midpoint of the ladder. (b) A wheel of radius 0.3 m rolls without slipping on a horizontal road with its centre moving at 6 m/s. Find the velocity of the topmost point of the rim and of the rim point at the same level as the centre.

Answer

(a) Ladder

Velocity of A is horizontal, velocity of B is vertical (along the wall). Draw perpendiculars to these velocities at A and B (a vertical line through A and a horizontal line through B). They meet at the instantaneous centre II, which is the corner of the rectangle formed by the floor, wall and the two perpendiculars.

   wall
   |  B
   |  |\
   I--+-\----  <- horizontal line through B
   |    \ \
   |     \ A --> 2 m/s
   +------------- floor

Distances from II: IA=Lsin⁡60∘=3.464IA = L\sin 60^\circ = 3.464 m (equal to the height of B), IB=Lcos⁡60∘=2.0IB = L\cos 60^\circ = 2.0 m (equal to the distance of A from the wall).

ωAB=vAIA=23.464=0.577 rad/s (anticlockwise)\omega_{AB} = \frac{v_A}{IA} = \frac{2}{3.464} = 0.577\ \text{rad/s (anticlockwise)} vB=ωAB⋅IB=0.577×2.0=1.155 m/s (downwards)v_B = \omega_{AB}\cdot IB = 0.577 \times 2.0 = 1.155\ \text{m/s (downwards)}

The midpoint M of the ladder is at the centre of the circle through A, B and I, so IM=L/2=2IM = L/2 = 2 m.

vM=ωAB⋅IM=0.577×2=1.155 m/sv_M = \omega_{AB}\cdot IM = 0.577 \times 2 = 1.155\ \text{m/s}

directed perpendicular to IMIM.

(b) Rolling wheel

For pure rolling, the point of contact with the road is the instantaneous centre. Angular velocity:

ω=vCr=60.3=20.0 rad/s\omega = \frac{v_C}{r} = \frac{6}{0.3} = 20.0\ \text{rad/s}
  • Topmost point (distance 2r=0.62r = 0.6 m from the IC): vtop=20×0.6=12.0v_{top} = 20 \times 0.6 = 12.0 m/s, horizontal, in the direction of travel.
  • Rim point at the level of the centre (distance r2r\sqrt{2} from IC): v=20×0.32=8.485v = 20 \times 0.3\sqrt{2} = 8.485 m/s, at 45∘45^\circ to the horizontal.

Answer: (a) ω=0.577\omega = 0.577 rad/s, vB=1.155v_B = 1.155 m/s, vM=1.155v_M = 1.155 m/s; (b) top =12.0= 12.0 m/s, side point =8.485= 8.485 m/s.

  • Practice · 6 marks

In a crank and slotted-lever quick return mechanism, the crank pivot O1 and the lever pivot O2 are 300 mm apart on a horizontal line, with O2 to the right of O1. The crank O1B is 120 mm long and rotates anticlockwise at 10 rad/s. A sliding block at B moves in the slot of the lever pivoted at O2. At the instant when the crank is vertical (B directly above O1), find the angular velocity of the slotted lever, the velocity of sliding of the block in the slot and the velocity of the point D on the lever, 500 mm from O2 on the side of O2 away from B.

Answer

Vector equation

Let B2_2 be the crank pin (block) and B3_3 the coincident point on the lever. The block slides along the lever, so

v⃗B2=v⃗B3+v⃗B2B3\vec v_{B_2} = \vec v_{B_3} + \vec v_{B_2B_3}
  • vB2v_{B_2}: magnitude ω⋅O1B=10×0.12=1.20\omega\cdot O_1B = 10 \times 0.12 = 1.20 m/s, perpendicular to O1BO_1B (horizontal, towards the left, since the crank is vertical and rotates anticlockwise).
  • vB3v_{B_3}: perpendicular to O2BO_2B (unknown magnitude).
  • vB2B3v_{B_2B_3}: along the slot O2BO_2B (unknown magnitude).

Geometry

O2B=3002+1202=323.1O_2B = \sqrt{300^2 + 120^2} = 323.1 mm. The slot makes an angle α=tan⁡−1(120/300)=21.80∘\alpha = \tan^{-1}(120/300) = 21.80^\circ with the horizontal, so cos⁡α=0.9285\cos\alpha = 0.9285, sin⁡α=0.3714\sin\alpha = 0.3714.

Velocity polygon (resolving vB2v_{B_2})

         b2 <---- o      o: pole
          \ ' |
  along    \ ' | perp. to O2B
  slot      \  |
             b3

Draw ob2o b_2 = 1.2 m/s horizontal. Through oo draw a line perpendicular to O2BO_2B (direction of vB3v_{B_3}) and through b2b_2 draw a line parallel to O2BO_2B (direction of vB2B3v_{B_2B_3}). They meet at b3b_3. Resolving vB2v_{B_2} in these two directions:

vB2B3=vB2cos⁡α=1.2×0.9285=1.114 m/sv_{B_2B_3} = v_{B_2}\cos\alpha = 1.2 \times 0.9285 = 1.114\ \text{m/s} vB3=vB2sin⁡α=1.2×0.3714=0.446 m/sv_{B_3} = v_{B_2}\sin\alpha = 1.2 \times 0.3714 = 0.446\ \text{m/s}

Angular velocity of lever

ωlever=vB3O2B=0.446323.1/1000=1.379 rad/s (anticlockwise)\omega_{lever} = \frac{v_{B_3}}{O_2B} = \frac{0.446}{323.1/1000} = 1.379\ \text{rad/s (anticlockwise)}

The sense: the block moves left and the lever is on its right side, so the lever turns anticlockwise about O2O_2.

Velocity of D

vD=ωlever⋅O2D=1.379×0.5=0.690 m/sv_D = \omega_{lever}\cdot O_2D = 1.379 \times 0.5 = 0.690\ \text{m/s}

perpendicular to the lever (D is on the opposite side of O2O_2, so it moves in the sense opposite to B3B_3).

Answer: ωlever=1.379\omega_{lever} = 1.379 rad/s anticlockwise, sliding velocity =1.114= 1.114 m/s, vD=0.690v_D = 0.690 m/s.

  • Practice · 5 marks

Differentiate between the relative velocity method and the instantaneous centre method of velocity analysis. Define centrode and state the three types of instantaneous centres with examples.

Answer

Comparison

PointRelative velocity methodInstantaneous centre method
Basisv⃗B=v⃗A+v⃗BA\vec v_B = \vec v_A + \vec v_{BA} (vector addition)Motion treated as pure rotation about the IC
OutputAll velocities (and angular velocities) of the mechanismVelocities of points of one link at a time
AccuracyGood; polygon is drawn onceDepends on locating ICs (may fall far away)
Complicated mechanismsSuitable; also extends to accelerationsBecomes long as the number of ICs grows
AccelerationSame method continues with an acceleration polygonNot applicable
SpeedNeeds a polygon for each positionQuick for a single link and position

Centrode

The locus of the instantaneous centre of a moving body is called its centrode. The path of the IC in the fixed body is the fixed centrode; the path in the moving body is the moving centrode. The motion of the body is equivalent to rolling of the moving centrode on the fixed centrode without slipping.

Example: a ladder sliding down a wall: the fixed centrode is a circular arc (of radius equal to ladder length), and the moving centrode is a semicircle on the ladder as diameter.

Types of instantaneous centres

  1. Fixed IC: remains in the same place for all positions of the mechanism, for example the IC of the crank and frame at the crank pivot.
  2. Permanent IC: changes its place as the mechanism moves, but joins two links by a pin joint, for example the crank-pin joint (crank and connecting rod).
  3. Neither fixed nor permanent: both position and type change with configuration, for example the IC of the connecting rod and the frame of a slider crank.
  • Practice · 8 marks

In a four-bar mechanism ABCD, AD = 300 mm is fixed, AB = 100 mm, BC = 250 mm and CD = 200 mm. The crank AB rotates at 10 rad/s anticlockwise and makes 60 degrees with AD. [Take A as origin and AD along the x-axis. In this position B is at (50.0, 86.6) mm, D at (300, 0) mm and C at (273.7, 198.3) mm.] Using Kennedy's theorem, locate the instantaneous centres I13 and I24 and hence find the angular velocities of the coupler BC and the rocker CD, and the linear velocity of C.

Answer

Instantaneous centres of the four links (1 = AD, 2 = AB, 3 = BC, 4 = CD)

Number of ICs =4×32=6= \dfrac{4 \times 3}{2} = 6. Four are pin joints:

I12=A (0,0)I_{12} = A\,(0, 0), I23=B (50.0,86.6)I_{23} = B\,(50.0, 86.6), I34=C (273.7,198.3)I_{34} = C\,(273.7, 198.3), I14=D (300,0)I_{14} = D\,(300, 0) mm.

By Kennedy's theorem the remaining two are:

  • I13I_{13} is the intersection of line AB (through I12I_{12}, I23I_{23}) and line DC (through I14I_{14}, I34I_{34}).
  • I24I_{24} is the intersection of line BC (through I23I_{23}, I34I_{34}) and line AD (through I12I_{12}, I14I_{14}).

Solving the line equations:

I13=(243.9, 422.5) mm,I24=(−123.5, 0) mmI_{13} = (243.9,\ 422.5)\ \text{mm}, \qquad I_{24} = (-123.5,\ 0)\ \text{mm}
   I13 *  (243.9, 422.5)
        \  .
         \    C
          B  /  \
         /      \
 I24 *--A---------D------

(Not to scale; I24I_{24} lies on AD produced beyond A.)

Angular velocity of rocker CD

I24I_{24} is a point common to links 2 and 4, so its velocity is the same whether taken on AB or on CD:

ω2⋅I12I24=ω4⋅I14I24\omega_2 \cdot I_{12}I_{24} = \omega_4 \cdot I_{14}I_{24} I12I24=123.5 mm,I14I24=300+123.5=423.5 mmI_{12}I_{24} = 123.5\ \text{mm}, \qquad I_{14}I_{24} = 300 + 123.5 = 423.5\ \text{mm} ω4=10×123.5423.5=2.916 rad/s\omega_4 = 10 \times \frac{123.5}{423.5} = 2.916\ \text{rad/s}

I24I_{24} lies outside A and D on the same side of both, so ω4\omega_4 has the same sense as ω2\omega_2: anticlockwise.

Angular velocity of coupler BC

I13I_{13} is the IC of links 1 and 3. The pin B is common to links 2 and 3:

vB=ω2⋅AB=10×0.100=1.0 m/sv_B = \omega_2 \cdot AB = 10 \times 0.100 = 1.0\ \text{m/s} ω3=vBI13B=1.0387.8/1000=2.578 rad/s\omega_3 = \frac{v_B}{I_{13}B} = \frac{1.0}{387.8/1000} = 2.578\ \text{rad/s}

B lies between I12I_{12} and I13I_{13} on the same line, so the senses of ω2\omega_2 and ω3\omega_3 are opposite: ω3\omega_3 is clockwise.

Velocity of C

vC=ω4⋅CD=2.916×0.200=0.583 m/sv_C = \omega_4 \cdot CD = 2.916 \times 0.200 = 0.583\ \text{m/s}

perpendicular to CD (check: vC=ω3⋅I13Cv_C = \omega_3 \cdot I_{13}C gives the same value).

Answer: ω3=2.578\omega_3 = 2.578 rad/s (clockwise), ω4=2.916\omega_4 = 2.916 rad/s (anticlockwise), vC=0.583v_C = 0.583 m/s.

Written from the official syllabus. Questions and answers are written for this site; check them against your class notes.
