Nepal Engineering Council · Electrical Engineering · Chapter 5
Power Electronics and Control
Tap an option to check it. Wrong picks show the right answer and the hint.
182 questions in 6 syllabus topics.
5.1 Control system fundamentals
30 questions · AElE0501
1. Which of the following is an example of an open-loop control system?
Show hintHide hint
Ask which device never checks its own output.
Show answerHide answer
Answer: B. An electric toaster that browns bread for a preset time
A timer-based toaster does not measure the output (degree of browning) and has no feedback, so it is open loop; the others measure and correct their output.
2. The basic feature that distinguishes a closed-loop control system from an open-loop system is
Show hintHide hint
Think of what the loop is made of.
Show answerHide answer
Answer: C. Feedback of the output to compare with the reference input
In a closed-loop system the output is measured and fed back so that the error between reference and output drives the controller.
3. Which is a main advantage of an open-loop control system over a closed-loop one?
Show hintHide hint
The other three are benefits of feedback.
Show answerHide answer
Answer: B. It is simple, cheap and cannot become unstable due to feedback
With no feedback path an open-loop system is simple and economical and cannot oscillate because of loop gain, but it does not correct errors.
4. Negative feedback in a control system generally
Show hintHide hint
Gain-bandwidth trade-off.
Show answerHide answer
Answer: B. Reduces overall gain but increases bandwidth
Negative feedback divides the gain by (1 + GH) and, as a trade-off, widens the bandwidth.
5. Which of the following is NOT an effect of introducing negative feedback?
Show hintHide hint
Recall what can happen with excessive loop gain.
Show answerHide answer
Answer: A. It always guarantees stability of the system
Feedback can make an otherwise stable system unstable if the loop gain is too high, so it does not guarantee stability; the other three are standard effects.
6. The transfer function of a system is defined as the ratio of
Show hintHide hint
Which way round, and what about initial conditions?
Show answerHide answer
Answer: C. Laplace transform of output to Laplace transform of input, with all initial conditions zero
By definition T(s) = C(s)/R(s) evaluated with zero initial conditions.
7. The transfer function concept is applicable to
Show hintHide hint
It needs superposition and constant coefficients.
Show answerHide answer
Answer: C. Linear time-invariant systems
Transfer functions rely on the Laplace transform and superposition, so they apply to linear time-invariant (LTI) systems.
8. The inverse Laplace transform of a system's transfer function gives its
Show hintHide hint
What input has a Laplace transform equal to 1?
Show answerHide answer
Answer: C. Impulse response
For a unit impulse R(s) = 1, so C(s) = T(s) and its inverse Laplace transform is the impulse response.
9. The poles of a transfer function are the values of s at which
Show hintHide hint
Where does T(s) blow up?
Show answerHide answer
Answer: C. The denominator becomes zero
Poles are the roots of the denominator (characteristic) polynomial, where T(s) becomes infinite.
10. For a closed-loop system with forward path G(s) and feedback path H(s), the characteristic equation is
Show hintHide hint
Set the closed-loop denominator to zero.
Show answerHide answer
Answer: A. 1 + G(s)H(s) = 0
For negative feedback T(s) = G/(1 + GH); setting the denominator to zero gives 1 + G(s)H(s) = 0.
11. In a closed-loop system, the signal obtained by subtracting the feedback signal from the reference input is called the
Show hintHide hint
It is the comparator's output.
Show answerHide answer
Answer: B. Actuating (error) signal
The comparator output e = r − b is the actuating or error signal that drives the controller.
12. A feedback control system in which the output is a mechanical position, velocity or acceleration is called a
Show hintHide hint
Think of a servo motor.
Show answerHide answer
Answer: A. Servomechanism
Servomechanisms are feedback systems whose controlled output is mechanical position or its derivatives.
13. A system has forward gain G = 10 and feedback gain H = 0.4 with negative feedback. Its closed-loop gain is
Show hintHide hint
Use G/(1 + GH).
Show answerHide answer
Answer: D. 2
T = G/(1 + GH) = 10/(1 + 4) = 2.
14. A system with forward gain G = 5 has positive feedback of H = 0.1. The closed-loop gain is
Show hintHide hint
The sign in the denominator changes for positive feedback.
Show answerHide answer
Answer: D. 10
For positive feedback T = G/(1 − GH) = 5/(1 − 0.5) = 10.
15. For a closed-loop system with G = 100 and H = 0.09, the sensitivity of the closed-loop gain to changes in G is
Show hintHide hint
Sensitivity to G is 1/(1 + GH).
Show answerHide answer
Answer: C. 0.1
S = 1/(1 + GH) = 1/(1 + 9) = 0.1.
16. A unity-feedback amplifier has open-loop gain 99. If the open-loop gain changes by 10 %, the closed-loop gain changes by about
Show hintHide hint
Multiply the change by the sensitivity.
Show answerHide answer
Answer: D. 0.1 %
Percentage change in T ≈ (1/(1 + GH)) × 10 % = (1/100) × 10 % = 0.1 %.
17. The DC (steady-state) gain of G(s) = 10/(s + 2) is
Show hintHide hint
Put s = 0.
Show answerHide answer
Answer: D. 5
DC gain is G(0) = 10/2 = 5.
18. The transfer function (s + 1)/(s² + 5s + 6) has poles at
Show hintHide hint
Factor the denominator.
Show answerHide answer
Answer: B. s = −2 and s = −3
s² + 5s + 6 = (s + 2)(s + 3), so the poles are at s = −2 and s = −3 (the zero is at s = −1).
19. The order of a system with transfer function (s + 1)/(s³ + 2s² + s + 5) is
Show hintHide hint
Look at the denominator only.
Show answerHide answer
Answer: A. 3
The order equals the highest power of s in the denominator, which is 3.
20. For an RC low-pass network with R = 10 kΩ and C = 10 µF, the transfer function Vo(s)/Vi(s) is
Show hintHide hint
Find the time constant RC first.
Show answerHide answer
Answer: D. 1/(0.1s + 1)
Vo/Vi = 1/(RCs + 1) with RC = 10 000 × 10 × 10⁻⁶ = 0.1 s.
21. Two blocks G1 = 2/(s + 1) and G2 = 3/(s + 2) are connected in cascade. The equivalent transfer function is
Show hintHide hint
Series blocks multiply, parallel blocks add.
Show answerHide answer
Answer: A. 6/((s + 1)(s + 2))
Blocks in series multiply: (2 × 3)/((s + 1)(s + 2)).
22. Two blocks G1 = 2/(s + 1) and G2 = 3/(s + 2) are connected in parallel with their outputs added. The equivalent transfer function is
Show hintHide hint
Add over a common denominator.
Show answerHide answer
Answer: B. (5s + 7)/((s + 1)(s + 2))
G1 + G2 = [2(s + 2) + 3(s + 1)]/((s + 1)(s + 2)) = (5s + 7)/((s + 1)(s + 2)).
23. A unity-feedback system has G(s) = K/(s(s + 4)). Its closed-loop transfer function is
Show hintHide hint
Use G/(1 + G) and clear the fraction.
Show answerHide answer
Answer: D. K/(s² + 4s + K)
T = G/(1 + G) = K/(s(s + 4) + K) = K/(s² + 4s + K).
24. In block-diagram reduction, when a take-off point is moved from after a block G to before it, the branch must be multiplied by
Show hintHide hint
Keep the signal in the branch unchanged.
Show answerHide answer
Answer: B. G
Before the move the branch carried G×input; after moving the take-off point ahead of G it carries only the input, so a block G must be inserted in the branch.
25. The 'type' of a feedback control system refers to
Show hintHide hint
Count the integrators.
Show answerHide answer
Answer: A. The number of open-loop poles at the origin
System type is the number of pure integrators (poles at s = 0) in the open-loop transfer function G(s)H(s).
26. In Mason's gain formula, Δ is equal to
Show hintHide hint
It is built only from loop gains.
Show answerHide answer
Answer: A. 1 − (sum of individual loop gains) + (sum of products of gains of all pairs of non-touching loops) − …
Δ = 1 − ΣL1 + ΣL2 − ΣL3 + …, where L2, L3 are products of non-touching loop pairs, triples, etc.
27. A signal flow graph has one forward path of gain 20 and a single loop of gain −4 touching that path. The overall gain is
Show hintHide hint
Δ = 1 − (loop gain); Δ1 = 1 since the loop touches the path.
Show answerHide answer
Answer: D. 4
By Mason's rule, T = P1Δ1/Δ = 20 × 1/(1 − (−4)) = 20/5 = 4.
28. A unity-feedback type-0 system has position error constant Kp = 9. The steady-state error for a unit-step input is
Show hintHide hint
For a step, ess = 1/(1 + Kp).
Show answerHide answer
Answer: B. 0.1
ess = 1/(1 + Kp) = 1/(1 + 9) = 0.1.
29. A transfer function in which the degree of the numerator is less than the degree of the denominator is called
Show hintHide hint
Compare the degrees of numerator and denominator.
Show answerHide answer
Answer: A. Strictly proper
A strictly proper transfer function has numerator degree lower than denominator degree, as in most physical systems.
30. Which statement about the transfer function of an LTI system is correct?
Show hintHide hint
It is a property of the system, not of the signal.
Show answerHide answer
Answer: C. It does not depend on the magnitude or type of the input
The transfer function is a property of the system alone; it is independent of input and gives no unique physical structure (different systems can share one TF).
5.2 Time domain analysis
30 questions · AElE0502
31. The time constant of a first-order system is the time taken by its unit-step response to reach
Show hintHide hint
Evaluate 1 − e⁻¹.
Show answerHide answer
Answer: B. 63.2 % of its final value
For c(t) = 1 − e^(−t/τ), at t = τ the response is 1 − e⁻¹ = 0.632 of the final value.
32. For the first-order system G(s) = 10/(s + 5), the time constant and the steady-state value of the unit-step response are
Show hintHide hint
Put it in the form K/(τs + 1).
Show answerHide answer
Answer: D. 0.2 s and 2
Write G = 2/(0.2s + 1): τ = 0.2 s and the final value is G(0) = 10/5 = 2.
33. Using the 2 % criterion, the settling time of a first-order system with time constant τ is approximately
Show hintHide hint
When does e^(−t/τ) drop to 0.02?
Show answerHide answer
Answer: A. 4τ
e^(−t/τ) falls to 2 % at t ≈ 3.9τ, commonly taken as 4τ.
34. The 10 %–90 % rise time of a first-order system with time constant τ is about
Show hintHide hint
Subtract the times at which the response reaches 10 % and 90 %.
Show answerHide answer
Answer: B. 2.2τ
The response reaches 10 % at t = τ ln(1/0.9) ≈ 0.105τ and 90 % at t = τ ln 10 ≈ 2.303τ, so tr = τ ln 9 ≈ 2.2τ.
35. For a second-order system with characteristic equation s² + 4s + 16 = 0, the natural frequency and damping ratio are
Show hintHide hint
Match with s² + 2ζωn s + ωn².
Show answerHide answer
Answer: D. 4 rad/s and 0.5
Compare with s² + 2ζωn s + ωn²: ωn² = 16 → ωn = 4; 2ζωn = 4 → ζ = 0.5.
36. A second-order system has ζ = 0.5. The peak percentage overshoot of its unit-step response is about
Show hintHide hint
Overshoot depends only on ζ.
Show answerHide answer
Answer: D. 16.3 %
Mp = exp(−ζπ/√(1 − ζ²)) = exp(−0.5π/0.866) ≈ 0.163, i.e. 16.3 %.
37. A second-order system has ωn = 4 rad/s and ζ = 0.5. Its peak time is about
Show hintHide hint
Use the damped frequency, not ωn.
Show answerHide answer
Answer: A. 0.91 s
tp = π/ωd, with ωd = ωn√(1 − ζ²) = 4 × 0.866 = 3.46 rad/s, so tp ≈ 0.91 s.
38. For a second-order system with ζ = 0.6 and ωn = 5 rad/s, the 2 % settling time is approximately
Show hintHide hint
Use 4/(ζωn).
Show answerHide answer
Answer: B. 1.33 s
ts ≈ 4/(ζωn) = 4/(0.6 × 5) = 1.33 s.
39. A second-order system whose damping ratio lies between 0 and 1 is
Show hintHide hint
Complex poles with negative real part.
Show answerHide answer
Answer: B. Underdamped, with oscillatory decaying step response
For 0 < ζ < 1 the poles are complex conjugate in the left half plane, giving a decaying oscillation.
40. When the damping ratio of a second-order system is zero, its step response is
Show hintHide hint
Where are the poles when ζ = 0?
Show answerHide answer
Answer: A. A sustained oscillation at the natural frequency
With ζ = 0 the poles are at ±jωn on the imaginary axis, so the response oscillates undamped at ωn.
41. Which change increases the percentage overshoot of a standard second-order system?
Show hintHide hint
Overshoot is a function of one parameter only.
Show answerHide answer
Answer: B. Decreasing the damping ratio
Overshoot depends only on ζ and rises as ζ decreases; ωn affects speed, not overshoot.
42. A linear time-invariant system is stable if all the closed-loop poles
Show hintHide hint
Negative real parts mean decaying terms.
Show answerHide answer
Answer: C. Lie in the left half of the s-plane
Poles with negative real parts give decaying exponential terms, so the response is bounded.
43. A system with a non-repeated pair of closed-loop poles on the imaginary axis and all other poles in the left half plane is
Show hintHide hint
Neither decaying nor growing.
Show answerHide answer
Answer: A. Marginally stable
Simple poles on the jω axis produce constant-amplitude oscillation, which is marginal stability.
44. In the Routh-Hurwitz criterion, the number of sign changes in the first column of the Routh array equals the number of
Show hintHide hint
Sign changes signal instability.
Show answerHide answer
Answer: D. Roots in the right half of the s-plane
Each sign change in the first column corresponds to one characteristic root with a positive real part.
45. Using the Routh array, the number of roots of s³ + s² + 2s + 8 = 0 in the right half plane is
Show hintHide hint
Build the first column: 1, 1, ?, 8.
Show answerHide answer
Answer: A. 2
First column: 1, 1, (1×2 − 1×8)/1 = −6, 8. Two sign changes, so two right-half-plane roots.
46. For the characteristic equation s³ + 2s² + 3s + K = 0, the closed-loop system is stable for
Show hintHide hint
Require (2×3 − K)/2 > 0 and K > 0.
Show answerHide answer
Answer: C. 0 < K < 6
Routh: s¹ row = (2×3 − K)/2 must be positive, so K < 6; s⁰ row K > 0. Hence 0 < K < 6.
47. A necessary (but not sufficient) condition for stability is that all coefficients of the characteristic polynomial
Show hintHide hint
Look at the coefficients before building the array.
Show answerHide answer
Answer: C. Are present and have the same sign
A missing term or a sign change among coefficients guarantees at least one root not in the open left half plane.
48. In a pole-zero plot, poles and zeros are conventionally marked respectively by
Show hintHide hint
Standard s-plane notation.
Show answerHide answer
Answer: A. Crosses (×) and small circles (o)
By convention × marks a pole and o marks a zero on the s-plane.
49. A pole located at s = −10, far to the left of a dominant pole pair at −1 ± j2, has the effect that
Show hintHide hint
Compare e^(−10t) with e^(−t).
Show answerHide answer
Answer: A. Its effect dies out quickly, so the dominant pair governs the response
The term e^(−10t) dies out much faster than e^(−t), so the poles nearest the jω axis dominate.
50. The root locus of a system starts (K = 0) at the
Show hintHide hint
Set K = 0 in 1 + KG(s)H(s) = 0.
Show answerHide answer
Answer: B. Open-loop poles
At K = 0 the characteristic equation reduces to the open-loop denominator, so the branches start at the open-loop poles.
51. The number of branches of the root locus equals
Show hintHide hint
Each branch starts somewhere.
Show answerHide answer
Answer: D. The number of open-loop poles (when poles ≥ zeros)
One branch starts from each open-loop pole, so the number of branches equals the number of poles when P ≥ Z.
52. A point on the real axis lies on the root locus if the total number of open-loop poles and zeros to its right is
Show hintHide hint
Angle condition: 180° from real poles and zeros to the right.
Show answerHide answer
Answer: D. Odd
The angle condition is satisfied on real-axis segments that have an odd number of real poles plus zeros to their right.
53. For G(s)H(s) = K/(s(s + 2)(s + 4)), the root-locus asymptotes meet the real axis (centroid) at
Show hintHide hint
Sum of poles divided by (P − Z).
Show answerHide answer
Answer: C. −2
Centroid = (Σpoles − Σzeros)/(P − Z) = (0 − 2 − 4)/3 = −2.
54. For G(s)H(s) = K/(s(s + 2)(s + 4)), the angles of the root-locus asymptotes are
Show hintHide hint
Use (2q + 1)180°/(P − Z).
Show answerHide answer
Answer: B. 60°, 180° and 300°
Angles = (2q + 1)180°/(P − Z) with P − Z = 3, giving 60°, 180°, 300°.
55. For the unity-feedback system G(s) = K/(s(s + 2)(s + 4)), the value of K at which the root locus crosses the imaginary axis, and the crossing frequency, are
Show hintHide hint
Make the s¹ row of the Routh array zero.
Show answerHide answer
Answer: C. K = 48 and ω ≈ 2.83 rad/s
Characteristic equation s³ + 6s² + 8s + K = 0. Routh s¹ row zero gives K = 6 × 8 = 48; auxiliary 6s² + 48 = 0 → ω = √8 ≈ 2.83 rad/s.
56. For G(s)H(s) = K/(s(s + 2)), the breakaway point of the root locus is at
Show hintHide hint
Set dK/ds = 0.
Show answerHide answer
Answer: D. s = −1
K = −s(s + 2) = −s² − 2s; dK/ds = −2s − 2 = 0 gives s = −1.
57. Adding integral action to a proportional controller mainly
Show hintHide hint
It adds a pole at s = 0.
Show answerHide answer
Answer: B. Eliminates steady-state error for a step input
Integral action adds a pole at the origin, raising the system type and driving step steady-state error to zero.
58. Derivative action in a PID controller
Show hintHide hint
Derivative gain grows with frequency.
Show answerHide answer
Answer: C. Improves damping by reacting to the rate of change of error, but amplifies high-frequency noise
The D term anticipates error changes, adding damping and reducing overshoot, but its gain rises with frequency so it amplifies noise.
59. The transfer function of an ideal PID controller is
Show hintHide hint
Integration is 1/s; differentiation is s.
Show answerHide answer
Answer: C. Kp + Ki/s + Kd·s
Proportional, integral (1/s) and derivative (s) terms are added: Gc(s) = Kp + Ki/s + Kd·s.
60. A unity-feedback system has G(s) = 10/(s(s + 2)). The steady-state error for a unit-ramp input is
Show hintHide hint
Find the velocity error constant Kv.
Show answerHide answer
Answer: A. 0.2
Type 1 system: Kv = lim s·G(s) = 10/2 = 5, so ess = 1/Kv = 0.2.
5.3 Frequency domain analysis
30 questions · AElE0503
61. A Bode plot consists of
Show hintHide hint
Two separate graphs on semi-log axes.
Show answerHide answer
Answer: D. Magnitude in dB and phase angle, each plotted against log of frequency
Bode plots are two separate graphs, 20 log|G(jω)| and ∠G(jω), versus frequency on a logarithmic scale.
62. A gain of 100 expressed in decibels (20 log10) is
Show hintHide hint
log10(100) = 2.
Show answerHide answer
Answer: C. 40 dB
20 log10(100) = 20 × 2 = 40 dB.
63. The asymptotic Bode magnitude plot of a simple pole factor 1/(1 + sT) has a slope above its corner frequency of
Show hintHide hint
One first-order pole.
Show answerHide answer
Answer: B. −20 dB/decade
Above ω = 1/T the factor behaves like 1/(ωT), falling 20 dB for every tenfold increase in frequency.
64. A slope of −20 dB/decade is equivalent to approximately
Show hintHide hint
An octave is a doubling of frequency.
Show answerHide answer
Answer: A. −6 dB/octave
An octave is a factor of 2 in frequency; 20 log10(2) ≈ 6 dB.
65. The corner frequency of the factor 1/(1 + 0.1s) is
Show hintHide hint
ωc = 1/T.
Show answerHide answer
Answer: A. 10 rad/s
Corner frequency ωc = 1/T = 1/0.1 = 10 rad/s.
66. At the corner frequency of a simple pole 1/(1 + sT), the error between the actual and asymptotic magnitude, and the phase angle, are
Show hintHide hint
Put ωT = 1 into the exact expressions.
Show answerHide answer
Answer: C. −3 dB and −45°
At ωT = 1, |G| = 1/√2 (−3 dB) and ∠G = −tan⁻¹(1) = −45°, while the asymptote gives 0 dB.
67. For the factor 1/s (an integrator), the Bode magnitude plot is a straight line of slope
Show hintHide hint
Evaluate 1/(jω) at ω = 1.
Show answerHide answer
Answer: A. −20 dB/decade passing through 0 dB at ω = 1 rad/s, with constant phase −90°
|1/jω| = 1/ω gives −20 dB/decade crossing 0 dB at ω = 1, and ∠(1/jω) = −90° at all frequencies.
68. The Bode magnitude plot of G(s) = 10/s crosses 0 dB at
Show hintHide hint
Set 10/ω = 1.
Show answerHide answer
Answer: A. ω = 10 rad/s
|G(jω)| = 10/ω = 1 when ω = 10 rad/s.
69. For G(s) = 100/(s(1 + 0.1s)), the low-frequency asymptote has a magnitude at ω = 1 rad/s and the slope after ω = 10 rad/s of
Show hintHide hint
Integrator plus one corner.
Show answerHide answer
Answer: B. 40 dB and −40 dB/decade
The low-frequency asymptote 100/ω gives 20 log 100 = 40 dB at ω = 1; after the pole at 10 rad/s the slope becomes −20 − 20 = −40 dB/decade.
70. The phase angle of G(s) = 1/(s(s + 1)) at ω = 1 rad/s is
Show hintHide hint
Add the phase of each factor.
Show answerHide answer
Answer: D. −135°
Phase = −90° (from 1/s) − tan⁻¹(1) = −90° − 45° = −135°.
71. Increasing only the gain K of an open-loop transfer function shifts the Bode plot by
Show hintHide hint
What is the phase of a positive constant?
Show answerHide answer
Answer: A. Moving the magnitude curve up, leaving the phase curve unchanged
A positive constant K adds 20 log K dB at all frequencies and contributes 0° phase.
72. The gain crossover frequency is the frequency at which
Show hintHide hint
Magnitude crosses a particular line.
Show answerHide answer
Answer: A. |G(jω)H(jω)| = 1 (0 dB)
Gain crossover is where the open-loop magnitude equals unity; phase margin is measured there.
73. The phase margin of a system is defined as
Show hintHide hint
Measured where |GH| = 1.
Show answerHide answer
Answer: B. 180° plus the phase angle of G(jω)H(jω) at the gain crossover frequency
PM = 180° + ∠G(jωgc)H(jωgc): the additional phase lag needed to bring the system to the verge of instability.
74. At the gain crossover frequency, the open-loop phase angle of a system is −150°. Its phase margin is
Show hintHide hint
PM = 180° + ∠GH.
Show answerHide answer
Answer: C. 30°
PM = 180° + (−150°) = 30°.
75. At the phase crossover frequency, the open-loop magnitude |G(jω)H(jω)| is 0.25. The gain margin is about
Show hintHide hint
GM = 20 log(1/|GH|) at phase crossover.
Show answerHide answer
Answer: D. 12 dB
GM = 20 log10(1/0.25) = 20 log10(4) ≈ 12.04 dB.
76. For the unity-feedback system G(s) = 3/(s(s + 1)(s + 2)), the gain margin is approximately
Show hintHide hint
Phase crossover of this system is at ω = √2 rad/s.
Show answerHide answer
Answer: C. 6 dB
Phase is −180° at ω = √2 rad/s where |G| = 3/6 = 0.5, so GM = 20 log 2 ≈ 6 dB.
77. For a minimum-phase system, which combination indicates a stable closed loop?
Show hintHide hint
Both margins measure distance from instability.
Show answerHide answer
Answer: C. Positive gain margin and positive phase margin
For minimum-phase systems both margins must be positive for closed-loop stability; zero margins mean marginal stability.
78. A minimum-phase transfer function is one that has
Show hintHide hint
Think about where the zeros sit.
Show answerHide answer
Answer: B. No poles or zeros in the right half of the s-plane
Minimum-phase systems have all poles and zeros in the left half plane (no time delay), so magnitude uniquely fixes phase.
79. A pure time delay e^(−sT) in the open loop affects the Bode plot by
Show hintHide hint
What is the magnitude of e^(−jθ)?
Show answerHide answer
Answer: D. Adding phase lag ωT radians without changing the magnitude
|e^(−jωT)| = 1 for all ω, while its phase is −ωT, which grows linearly with frequency.
80. For a second-order system with ζ = 0.5 and ωn = 10 rad/s, the resonant peak Mr of the closed-loop frequency response is about
Show hintHide hint
Use Mr = 1/(2ζ√(1 − ζ²)).
Show answerHide answer
Answer: D. 1.15
Mr = 1/(2ζ√(1 − ζ²)) = 1/(2 × 0.5 × 0.866) ≈ 1.15.
81. For a second-order system with ζ = 0.5 and ωn = 10 rad/s, the resonant frequency is about
Show hintHide hint
ωr = ωn√(1 − 2ζ²), not the damped frequency.
Show answerHide answer
Answer: D. 7.07 rad/s
ωr = ωn√(1 − 2ζ²) = 10√0.5 ≈ 7.07 rad/s.
82. The bandwidth of a closed-loop control system is the frequency at which the closed-loop magnitude
Show hintHide hint
Half-power point.
Show answerHide answer
Answer: C. Falls to 0.707 (−3 dB) of its zero-frequency value
Bandwidth is the range up to the frequency where |T(jω)| drops 3 dB below |T(0)|.
83. The Nyquist stability criterion is based on
Show hintHide hint
A theorem from complex variable theory.
Show answerHide answer
Answer: B. Cauchy's principle of the argument (conformal mapping)
Nyquist maps the s-plane contour through G(s)H(s) and counts encirclements using Cauchy's argument principle.
84. In the Nyquist criterion Z = N + P (N = clockwise encirclements of −1 + j0, P = open-loop right-half-plane poles), Z represents the number of
Show hintHide hint
Zeros of 1 + G(s)H(s).
Show answerHide answer
Answer: B. Closed-loop poles in the right half of the s-plane
Z is the number of zeros of 1 + GH in the right half plane, i.e. closed-loop poles there; stability needs Z = 0.
85. An open-loop transfer function has no poles in the right half plane. Its Nyquist plot encircles −1 + j0 twice in the clockwise direction. The closed-loop system has
Show hintHide hint
Apply Z = N + P.
Show answerHide answer
Answer: B. Two poles in the right half plane, so it is unstable
Z = N + P = 2 + 0 = 2 closed-loop poles in the right half plane, so the system is unstable.
86. An open-loop system has one pole in the right half plane. Its Nyquist plot encircles −1 + j0 once counter-clockwise. The closed-loop system is
Show hintHide hint
Counter-clockwise encirclements count as negative N.
Show answerHide answer
Answer: A. Stable
Counter-clockwise encirclement gives N = −1, so Z = N + P = −1 + 1 = 0: no closed-loop right-half-plane poles.
87. The Nyquist plot of an open-loop transfer function crosses the negative real axis at −0.5. The gain margin is
Show hintHide hint
How much can the gain rise before the plot passes through −1?
Show answerHide answer
Answer: A. 2 (about 6 dB)
GM = 1/|crossing| = 1/0.5 = 2, i.e. 20 log 2 ≈ 6 dB.
88. If the Nyquist plot of G(jω)H(jω) passes exactly through the point −1 + j0, the closed-loop system is
Show hintHide hint
1 + GH = 0 on the jω axis.
Show answerHide answer
Answer: D. Marginally stable
Passing through −1 means 1 + GH = 0 at some jω, i.e. closed-loop poles on the imaginary axis.
89. The polar plot of G(jω) = 1/(1 + jωT) for ω from 0 to ∞ is
Show hintHide hint
Check the points ω = 0, 1/T and ∞.
Show answerHide answer
Answer: B. A semicircle in the fourth quadrant from 1 to the origin
At ω = 0 it is 1∠0°, at ω = 1/T it is 0.707∠−45°, and it approaches 0∠−90° as ω → ∞, tracing a semicircle of diameter 1 below the real axis.
90. As ω → ∞, the polar plot of G(s) = K/(s(s + 1)(s + 2)) approaches the origin tangent to the direction of
Show hintHide hint
Each excess pole contributes −90° at high frequency.
Show answerHide answer
Answer: C. −270°
With three more poles than zeros, the phase at high frequency tends to 3 × (−90°) = −270°.
5.4 Power semiconductor switches
32 questions · AElE0504
91. A power diode differs from a low-power signal diode mainly by having
Show hintHide hint
Where is the high blocking voltage dropped?
Show answerHide answer
Answer: B. A lightly doped n⁻ drift region between the p and n⁺ layers to block high reverse voltage
The lightly doped drift layer supports a wide depletion region and hence a high reverse breakdown voltage.
92. The reverse recovery time trr of a power diode is the time
Show hintHide hint
Stored minority carriers must go somewhere.
Show answerHide answer
Answer: D. During which reverse current flows after the forward current falls to zero, while stored charge is removed
After forward conduction, stored minority charge must be swept out, so the diode conducts in reverse for trr before blocking.
93. A power diode has reverse recovery time 2 µs and peak reverse recovery current 30 A. Assuming a triangular recovery current, the stored (recovered) charge is about
Show hintHide hint
Area of a triangle.
Show answerHide answer
Answer: C. 30 µC
Qrr ≈ ½ × trr × IRR = 0.5 × 2 µs × 30 A = 30 µC.
94. Compared with a p-n power diode, a Schottky power diode has
Show hintHide hint
It is a majority-carrier device.
Show answerHide answer
Answer: A. Lower forward voltage drop and negligible reverse recovery, but a lower reverse voltage rating
A Schottky diode is a majority-carrier metal-semiconductor device: low forward drop and almost no recovery, but limited blocking voltage and higher leakage.
95. A thyristor (SCR) has
Show hintHide hint
Count layers, then junctions between them.
Show answerHide answer
Answer: B. Four layers (p-n-p-n), three junctions and three terminals
The SCR is a p-n-p-n structure with junctions J1, J2, J3 and terminals anode, cathode and gate.
96. For a thyristor, the latching current is
Show hintHide hint
Staying on just after turn-on needs more current than staying on later.
Show answerHide answer
Answer: B. Larger than the holding current
Latching current (minimum anode current to stay on just after the gate pulse is removed) is typically two to three times the holding current.
97. Once a thyristor is conducting, it can be turned off by
Show hintHide hint
The gate cannot help once it latches.
Show answerHide answer
Answer: D. Reducing its anode current below the holding current
The gate loses control after latching; the SCR turns off only when anode current falls below the holding current (natural or forced commutation).
98. Which of the following is NOT a method of turning on a thyristor?
Show hintHide hint
Gate triggering needs current in a particular direction.
Show answerHide answer
Answer: A. Applying a negative gate current
Thyristors can be turned on by gate current, breakover voltage, dv/dt, temperature or light; a negative gate current does not turn it on.
99. In the two-transistor model of a thyristor, α1 = 0.4, α2 = 0.5 and the gate current is 50 mA. Neglecting leakage currents, the anode current is
Show hintHide hint
Ia = α2Ig/(1 − α1 − α2).
Show answerHide answer
Answer: A. 0.25 A
Ia = α2·Ig/(1 − (α1 + α2)) = 0.5 × 0.05/(1 − 0.9) = 0.25 A.
100. For a thyristor to turn off reliably by commutation, the circuit turn-off time must be
Show hintHide hint
Give the device enough time to recover.
Show answerHide answer
Answer: A. Greater than the device turn-off time tq
The device must stay reverse biased (or at zero current) longer than tq so the junction J2 recovers its blocking ability.
101. A gate turn-off thyristor (GTO) is turned off by
Show hintHide hint
It is in the name.
Show answerHide answer
Answer: D. Applying a large negative gate current
Unlike an SCR, a GTO can be turned off from the gate by extracting a large negative gate current.
102. A GTO carries 600 A and has a turn-off gain of 4. The negative gate current needed to turn it off is
Show hintHide hint
Turn-off gain = anode current / gate turn-off current.
Show answerHide answer
Answer: B. 150 A
Turn-off gain = Ia/Ig(off), so Ig(off) = 600/4 = 150 A.
103. A TRIAC is equivalent to
Show hintHide hint
It conducts in both half-cycles.
Show answerHide answer
Answer: A. Two SCRs connected in inverse parallel with a common gate
A TRIAC conducts in both directions and can be triggered for either polarity from one gate, like two anti-parallel SCRs.
104. A typical application of a TRIAC is
Show hintHide hint
It handles both half-cycles of mains AC.
Show answerHide answer
Answer: D. AC phase-control such as light dimmers and fan regulators
TRIACs are low-cost bidirectional switches for 50 Hz AC power control; their dv/dt and frequency capability are limited.
105. A TRIAC is most sensitive (needs the least gate current) when triggered with
Show hintHide hint
The mode that behaves most like a normal SCR.
Show answerHide answer
Answer: C. MT2 positive and gate positive with respect to MT1
Mode I+ (MT2 and gate both positive relative to MT1) has the highest gate sensitivity; mode III+ is the least sensitive.
106. The device commonly used to trigger a TRIAC in a simple AC lamp dimmer is a
Show hintHide hint
A bidirectional breakover device.
Show answerHide answer
Answer: D. DIAC
A DIAC breaks over symmetrically in both directions and delivers a trigger pulse to the TRIAC gate in each half-cycle.
107. An IGBT combines
Show hintHide hint
Input like one device, output like another.
Show answerHide answer
Answer: B. The high-impedance voltage-controlled gate of a MOSFET with the low conduction drop of a BJT
The IGBT has a MOS gate (voltage drive, low gate power) and bipolar conductivity modulation in the drift region (low on-state drop).
108. The three terminals of an IGBT are
Show hintHide hint
A mix of MOSFET and BJT terminal names.
Show answerHide answer
Answer: B. Gate, collector and emitter
IGBT terminals are named gate, collector and emitter, reflecting its MOS input and bipolar output.
109. Latch-up in an IGBT is caused by
Show hintHide hint
Count the layers in an IGBT.
Show answerHide answer
Answer: C. Turn-on of the parasitic p-n-p-n thyristor structure inside the device
The four-layer IGBT contains a parasitic thyristor; if it latches, the gate loses control of the collector current.
110. A power MOSFET is a
Show hintHide hint
No minority carrier storage.
Show answerHide answer
Answer: A. Majority-carrier, voltage-controlled device with very fast switching
Conduction is by majority carriers only, so there is no stored charge, and the gate is voltage controlled.
111. Power MOSFETs can be paralleled easily because their on-state resistance
Show hintHide hint
Hotter device should take less current.
Show answerHide answer
Answer: A. Has a positive temperature coefficient
If one device heats up, its RDS(on) rises and it takes less current, so current sharing is self-balancing.
112. Arranged in order of decreasing maximum switching frequency, typical power devices are
Show hintHide hint
Majority-carrier devices are fastest.
Show answerHide answer
Answer: B. MOSFET, IGBT, GTO, SCR
MOSFETs switch at hundreds of kHz, IGBTs at tens of kHz, while GTOs and SCRs are limited to around 1 kHz or line frequency.
113. A power MOSFET with RDS(on) = 0.1 Ω carries an RMS current of 10 A. Its conduction loss is
Show hintHide hint
A MOSFET behaves as a resistor when on.
Show answerHide answer
Answer: C. 10 W
Pcond = I²rms × RDS(on) = 10² × 0.1 = 10 W.
114. A switch turns on and off 400 V, 20 A at 20 kHz with rise time 0.1 µs and fall time 0.2 µs. With linear transitions, the switching loss is about
Show hintHide hint
Psw = ½ V I (tr + tf) f.
Show answerHide answer
Answer: D. 24 W
Psw = ½ V I (tr + tf) f = 0.5 × 400 × 20 × 0.3 µs × 20 000 = 24 W.
115. A switch dissipates 24 W of switching loss when operated at 20 kHz. If the switching frequency is raised to 50 kHz with the same voltage, current and transition times, the switching loss becomes
Show hintHide hint
Energy per transition times transitions per second.
Show answerHide answer
Answer: A. 60 W
Switching energy per cycle is fixed, so loss scales with frequency: 24 × 50/20 = 60 W.
116. A thyristor with an on-state drop of 1.2 V (assumed constant) carries an average current of 50 A. Its average conduction loss is about
Show hintHide hint
Constant voltage drop times average current.
Show answerHide answer
Answer: C. 60 W
With a constant on-state drop, Pcond = VT × Iavg = 1.2 × 50 = 60 W.
117. A device dissipates 50 W. The junction-to-ambient thermal resistance including heat sink is 1.5 °C/W and ambient temperature is 40 °C. The junction temperature is
Show hintHide hint
Temperature rise = power × thermal resistance.
Show answerHide answer
Answer: C. 115 °C
Tj = Ta + P × Rθja = 40 + 50 × 1.5 = 115 °C.
118. An RC snubber connected across a thyristor is used mainly to
Show hintHide hint
The capacitor resists sudden voltage change.
Show answerHide answer
Answer: C. Limit the rate of rise of forward voltage (dv/dt)
The capacitor slows the rise of voltage across the device, preventing false dv/dt turn-on; the resistor limits discharge current at turn-on.
119. A thyristor has a maximum di/dt rating of 50 A/µs and is supplied from 300 V. The minimum series inductance needed for di/dt protection is
Show hintHide hint
di/dt = V/L at switch-on.
Show answerHide answer
Answer: C. 6 µH
L ≥ V/(di/dt) = 300/(50 × 10⁶) = 6 µH.
120. For protection of a thyristor by a fast-acting fuse, the fuse should be chosen so that its
Show hintHide hint
The fuse must blow before the device fails.
Show answerHide answer
Answer: D. Total clearing I²t is less than the I²t rating of the thyristor
The fuse must clear a fault before the device's sub-cycle surge (I²t) withstand is exceeded.
121. Four thyristors, each rated 3 kV, are connected in series to block a total of 10 kV. The string derating factor is about
Show hintHide hint
DRF = 1 − string efficiency.
Show answerHide answer
Answer: B. 0.17
Derating factor = 1 − Vstring/(n × Vdevice) = 1 − 10/(4 × 3) ≈ 0.17.
122. When thyristors are connected in series, static voltage sharing is achieved by connecting
Show hintHide hint
Unequal leakage currents need a parallel path.
Show answerHide answer
Answer: D. Equal resistors across each thyristor
Shunt resistors equalize off-state voltages despite unequal leakage currents; RC networks handle dynamic (transient) sharing.
5.5 Power converters
30 questions · AElE0505
123. A single-phase half-wave diode rectifier with a resistive load is fed from 230 V (rms), 50 Hz. The average output voltage is about
Show hintHide hint
Vdc = Vm/π for half-wave.
Show answerHide answer
Answer: C. 103.5 V
Vdc = Vm/π = (√2 × 230)/π = 325.3/π ≈ 103.5 V.
124. A single-phase full-wave diode bridge rectifier with a resistive load is fed from 230 V (rms). The average output voltage is about
Show hintHide hint
Full-wave gives twice the half-wave average.
Show answerHide answer
Answer: C. 207.1 V
Vdc = 2Vm/π = 2 × 325.3/π ≈ 207.1 V.
125. The ripple factor of a single-phase half-wave rectifier with resistive load is about
Show hintHide hint
RF = √(FF² − 1).
Show answerHide answer
Answer: A. 1.21
With Vrms = Vm/2 and Vdc = Vm/π, form factor = π/2 = 1.57 and RF = √(1.57² − 1) ≈ 1.21.
126. The maximum rectification efficiency (DC output power / AC input power to the load) of a single-phase full-wave rectifier with resistive load is about
Show hintHide hint
Ratio of (Vdc)² to (Vrms)².
Show answerHide answer
Answer: B. 81.2 %
η = (2Vm/π)²/(Vm/√2)² = 8/π² ≈ 0.812.
127. In a single-phase centre-tapped full-wave rectifier, the peak inverse voltage across each diode is
Show hintHide hint
The non-conducting diode sees both halves of the winding.
Show answerHide answer
Answer: D. 2Vm
When one diode conducts, the other sees the full secondary voltage of both halves, i.e. 2Vm.
128. A single-phase fully controlled bridge with a highly inductive (continuous current) load is fed from 230 V (rms). At a firing angle of 60°, the average output voltage is about
Show hintHide hint
Vdc = (2Vm/π) cos α for continuous conduction.
Show answerHide answer
Answer: A. 103.5 V
Vdc = (2Vm/π) cos α = 207.1 × cos 60° ≈ 103.5 V.
129. A single-phase half-controlled (semi-converter) bridge is fed from 230 V (rms). At a firing angle of 60°, the average output voltage is about
Show hintHide hint
Semi-converter: (Vm/π)(1 + cos α).
Show answerHide answer
Answer: B. 155.3 V
Vdc = (Vm/π)(1 + cos α) = 103.5 × 1.5 ≈ 155.3 V.
130. A single-phase fully controlled bridge with a highly inductive load can operate in the inverting mode (power flow from DC to AC side) when
Show hintHide hint
When does cos α become negative?
Show answerHide answer
Answer: A. The firing angle exceeds 90° and a suitable DC source is present on the load side
For α > 90° the average voltage cos α is negative; with a DC source driving current the converter returns power to the AC supply.
131. Connecting a freewheeling diode across the inductive load of a controlled rectifier
Show hintHide hint
It removes the negative part of the output.
Show answerHide answer
Answer: D. Prevents negative output voltage and improves input power factor
The freewheeling diode clamps the output at zero during the negative portions, so energy is not returned to the supply and the input power factor improves.
132. A three-phase fully controlled bridge rectifier is fed from 400 V (line, rms). With continuous current and a firing angle of 30°, the average output voltage is about
Show hintHide hint
Vdc = 1.35 VL cos α.
Show answerHide answer
Answer: C. 468 V
Vdc = (3√2/π) VL cos α = 1.35 × 400 × cos 30° ≈ 468 V.
133. The ripple frequency in the output of a three-phase fully controlled bridge (six-pulse) rectifier fed from a 50 Hz supply is
Show hintHide hint
Count pulses per cycle.
Show answerHide answer
Answer: B. 300 Hz
A six-pulse converter has six output pulses per supply cycle: 6 × 50 = 300 Hz.
134. The characteristic AC-side current harmonics of a six-pulse converter are of order
Show hintHide hint
Pulse number p gives harmonics pk ± 1.
Show answerHide answer
Answer: B. 6k ± 1 (5, 7, 11, 13, …)
Six-pulse converters produce harmonics of order 6k ± 1 on the AC side and 6k on the DC side.
135. The input power factor of a rectifier is equal to
Show hintHide hint
Non-sinusoidal current affects PF in two ways.
Show answerHide answer
Answer: B. Distortion factor × displacement factor
PF = (I1/Irms) × cos φ1, i.e. distortion factor multiplied by displacement (fundamental) power factor.
136. A single-phase fully controlled bridge with a ripple-free DC load current is operated at α = 30°. Its input power factor is about
Show hintHide hint
Multiply the square-wave distortion factor by cos α.
Show answerHide answer
Answer: C. 0.78
The input current is a square wave: distortion factor = 2√2/π ≈ 0.9; displacement factor = cos 30° = 0.866; PF ≈ 0.9 × 0.866 = 0.78.
137. The total harmonic distortion of an ideal square-wave current (equal positive and negative halves of 180°) is about
Show hintHide hint
THD = √(Irms² − I1²)/I1.
Show answerHide answer
Answer: A. 48.3 %
I1 = 0.9 Irms, so THD = √(Irms² − I1²)/I1 = √(1 − 0.81)/0.9 ≈ 0.483.
138. Which of the following is NOT a method of improving the input power factor of a phase-controlled converter?
Show hintHide hint
Displacement factor is roughly cos α.
Show answerHide answer
Answer: C. Increasing the firing angle
Increasing α increases the displacement angle and worsens power factor; the other three are forced-commutation PF improvement methods.
139. A voltage source inverter (VSI) is characterized by
Show hintHide hint
Stiff voltage versus stiff current.
Show answerHide answer
Answer: A. A stiff DC voltage source (large capacitor) at its input and an output voltage waveform independent of load
A VSI is fed from a stiff DC voltage, so its output voltage waveform is fixed by switching while the current depends on load; a CSI uses a large series inductor.
140. The output voltage of a single-phase square-wave inverter contains
Show hintHide hint
Fourier series of a square wave.
Show answerHide answer
Answer: A. Only odd harmonics, with the nth harmonic amplitude equal to 1/n of the fundamental
A square wave with half-wave symmetry has only odd harmonics with amplitudes (4V/nπ).
141. A single-phase full-bridge inverter operating in square-wave mode is supplied from 220 V DC. The rms value of the fundamental output voltage is about
Show hintHide hint
Fundamental peak of a square wave is 4/π times its height.
Show answerHide answer
Answer: D. 198 V
V1(rms) = (4Vdc/π)/√2 = 0.9 Vdc = 0.9 × 220 ≈ 198 V.
142. A three-phase bridge inverter in 180° conduction mode is fed from 600 V DC. The rms line-to-line output voltage is about
Show hintHide hint
VL = 0.816 Vdc for 180° conduction.
Show answerHide answer
Answer: B. 490 V
VL(rms) = √(2/3) Vdc = 0.816 × 600 ≈ 490 V.
143. In a single-phase full-bridge inverter, making the output a quasi-square wave with each pulse 120° wide
Show hintHide hint
Harmonic n is proportional to sin(n × half pulse width).
Show answerHide answer
Answer: D. Eliminates the third harmonic
For a pulse width 2d, harmonic n ∝ sin(nd); with 2d = 120°, sin(3 × 60°) = 0, so the third and all triplen harmonics vanish.
144. In sinusoidal PWM, the amplitude modulation index is defined as the ratio of
Show hintHide hint
It compares the two amplitudes.
Show answerHide answer
Answer: C. Peak of the sinusoidal reference to peak of the triangular carrier
ma = Vref(peak)/Vcarrier(peak); the frequency modulation ratio mf = fcarrier/fref.
145. A single-phase half-bridge inverter with sinusoidal PWM is fed from 400 V DC (total). With an amplitude modulation index of 0.8 in the linear range, the peak fundamental output voltage is
Show hintHide hint
The half bridge swings ±Vdc/2.
Show answerHide answer
Answer: B. 160 V
For a half bridge, V1(peak) = ma × Vdc/2 = 0.8 × 200 = 160 V.
146. In a sinusoidal PWM inverter with a 2550 Hz carrier and a 50 Hz reference, the dominant output harmonics are located around the
Show hintHide hint
Compute mf = fcarrier/freference.
Show answerHide answer
Answer: B. 51st harmonic (2550 Hz) and its sidebands
mf = 2550/50 = 51; SPWM pushes harmonics to sidebands around mf and its multiples, which are easy to filter.
147. A 'dead time' (blanking time) is provided between turning off one switch and turning on the other switch of the same inverter leg to
Show hintHide hint
Two switches in one leg must never be on together.
Show answerHide answer
Answer: D. Prevent shoot-through short circuit of the DC supply
Since switches take finite time to turn off, both switches of a leg could briefly conduct and short the DC link; dead time prevents this.
148. A DC-DC chopper is supplied from 200 V. Its switch is on for 2 ms and off for 3 ms in each period. The average output voltage of this step-down chopper is
Show hintHide hint
The period is Ton + Toff.
Show answerHide answer
Answer: D. 80 V
D = Ton/T = 2/5 = 0.4, so Vo = D × Vs = 0.4 × 200 = 80 V.
149. An ideal buck converter has an input of 24 V and a duty ratio of 0.4. Its output voltage is
Show hintHide hint
Buck: Vo = D·Vin.
Show answerHide answer
Answer: A. 9.6 V
Vo = D × Vin = 0.4 × 24 = 9.6 V.
150. An ideal boost converter operating in continuous conduction has an input of 24 V and a duty ratio of 0.4. Its output voltage is
Show hintHide hint
Boost: Vo = Vin/(1 − D).
Show answerHide answer
Answer: A. 40 V
Vo = Vin/(1 − D) = 24/0.6 = 40 V.
151. An ideal buck-boost converter in continuous conduction has 24 V input and duty ratio 0.4. The magnitude of its output voltage is
Show hintHide hint
Buck-boost: D/(1 − D).
Show answerHide answer
Answer: D. 16 V
|Vo| = Vin × D/(1 − D) = 24 × 0.4/0.6 = 16 V (with reversed polarity).
152. A buck converter has Vin = 48 V, D = 0.5, L = 1 mH and switching frequency 20 kHz. The peak-to-peak inductor current ripple is
Show hintHide hint
During on-time the inductor sees Vin − Vo.
Show answerHide answer
Answer: C. 0.6 A
ΔI = (Vin − Vo)·D/(L·f) = (48 − 24) × 0.5/(1 × 10⁻³ × 20 000) = 0.6 A.
5.6 Applications of power electronics
30 questions · AElE0506
153. In an on-line (double-conversion) UPS, under normal mains conditions the load is supplied
Show hintHide hint
Double conversion means the power always takes the same path.
Show answerHide answer
Answer: B. Continuously through the rectifier and inverter
In an on-line UPS the mains is rectified and inverted all the time, so the load always runs from the inverter and sees no transfer when mains fails.
154. In an off-line (standby) UPS, the inverter
Show hintHide hint
Standby means waiting.
Show answerHide answer
Answer: C. Supplies the load only after the mains fails, after a short transfer time
The load normally runs from the mains; on failure a transfer switch connects the inverter, causing a transfer time of a few milliseconds.
155. Which UPS type provides zero transfer time to the load when the mains supply fails?
Show hintHide hint
Which one already runs from the inverter?
Show answerHide answer
Answer: D. On-line double-conversion UPS
Since the inverter already feeds the load, a mains failure only changes the source of the DC link (rectifier to battery), with no switching at the output.
156. A line-interactive UPS differs from a simple standby UPS mainly because it
Show hintHide hint
It interacts with the line voltage level.
Show answerHide answer
Answer: C. Corrects mains sags and swells by voltage regulation without using the battery
Line-interactive UPSs include automatic voltage regulation, so moderate voltage variations are corrected without using the battery.
157. Which of the following is NOT a usual component of a static on-line UPS?
Show hintHide hint
Look for the rotating machine.
Show answerHide answer
Answer: C. Synchronous condenser
A static UPS consists of a rectifier/charger, battery, inverter and static bypass switch; a synchronous condenser is a rotating reactive-power device used in power systems.
158. The static bypass switch of a UPS, typically made of anti-parallel thyristors, is used to
Show hintHide hint
A fast switch to an alternative source.
Show answerHide answer
Answer: B. Transfer the load to the mains quickly if the inverter fails or is overloaded
On inverter fault or overload, the static switch connects the load directly to the bypass mains within a fraction of a cycle.
159. A UPS supplies a 3 kW load at 0.8 power factor. The minimum UPS rating needed is
Show hintHide hint
UPS ratings are in kVA.
Show answerHide answer
Answer: D. 3.75 kVA
S = P/pf = 3/0.8 = 3.75 kVA.
160. A UPS uses two 12 V, 100 Ah batteries in series. With inverter efficiency 90 % and a 600 W load, the approximate backup time (ignoring battery derating) is
Show hintHide hint
Battery energy × efficiency ÷ load.
Show answerHide answer
Answer: A. 3.6 h
Energy = 24 V × 100 Ah = 2400 Wh; usable output = 2400 × 0.9 = 2160 Wh; time = 2160/600 = 3.6 h.
161. A UPS with a 48 V battery bank must supply a 1 kW load for 2 hours with an inverter efficiency of 80 %. The minimum battery capacity required is about
Show hintHide hint
Divide by efficiency first, then by battery voltage.
Show answerHide answer
Answer: C. 52 Ah
Battery energy = 1000 × 2/0.8 = 2500 Wh; Ah = 2500/48 ≈ 52 Ah.
162. The battery bank of a UPS operates on a 240 V DC bus using 12 V batteries. The number of batteries in series required is
Show hintHide hint
Series voltages add.
Show answerHide answer
Answer: A. 20
n = 240/12 = 20 batteries in series.
163. The output of a modern on-line UPS inverter is made nearly sinusoidal mainly by
Show hintHide hint
Push harmonics high, then filter.
Show answerHide answer
Answer: A. High-frequency PWM switching with an output LC filter
PWM moves harmonics to high frequencies, where a small LC filter removes them, giving a low-THD sinusoidal output.
164. In a line-commutated (LCC) HVDC link, the main switching devices in the converter valves are
Show hintHide hint
High-power, line-commutated device.
Show answerHide answer
Answer: A. Thyristors
Classical LCC HVDC uses series strings of high-power thyristors, commutated by the AC network voltage.
165. The smoothing reactor on the DC side of an HVDC converter station is mainly used to
Show hintHide hint
A large inductor opposes changes in current.
Show answerHide answer
Answer: D. Reduce ripple in the DC current and limit the rate of rise of fault current
The large series inductor smooths the DC current, limits di/dt during DC faults and helps reduce commutation failures.
166. AC filters at an HVDC converter station serve to
Show hintHide hint
They are capacitive at 50 Hz.
Show answerHide answer
Answer: A. Absorb converter harmonic currents and supply part of the reactive power
Tuned AC filters provide low-impedance paths for characteristic harmonics and, being capacitive at fundamental frequency, supply reactive power.
167. A line-commutated HVDC converter, whether rectifying or inverting,
Show hintHide hint
Think about the phase of the AC line current.
Show answerHide answer
Answer: B. Consumes reactive power from the AC system
Because of firing delay and commutation overlap, the AC current lags the voltage in both modes, so LCC converters absorb reactive power (roughly 50–60 % of the active power).
168. A monopolar HVDC link uses
Show hintHide hint
Mono means one.
Show answerHide answer
Answer: B. One conductor, usually of negative polarity, with return through earth or sea
A monopolar link has a single (usually negative) conductor; the return current flows through earth/sea electrodes or a metallic return.
169. The most widely used HVDC link configuration for long-distance bulk overhead transmission, which can continue at reduced power if one pole fails, is the
Show hintHide hint
Two poles of opposite polarity.
Show answerHide answer
Answer: A. Bipolar link
A bipolar link has +Vd and −Vd conductors; if one pole is out, the other can operate as a monopole with earth return.
170. A homopolar HVDC link has
Show hintHide hint
Homo means same.
Show answerHide answer
Answer: A. Two or more conductors of the same polarity, usually negative, with earth return
In a homopolar link all conductors share one polarity (normally negative, for less corona) and the return is through ground.
171. A back-to-back HVDC station is mainly used to
Show hintHide hint
No line between rectifier and inverter.
Show answerHide answer
Answer: D. Interconnect two asynchronous AC systems with no DC transmission line
Rectifier and inverter are in the same station, allowing power exchange between systems of different frequency or phase without a DC line.
172. A 12-pulse HVDC converter is formed from two six-pulse bridges fed by converter transformers connected
Show hintHide hint
The two bridges must be phase shifted.
Show answerHide answer
Answer: C. Star-star and star-delta, giving a 30° phase shift
The 30° shift between the Y-Y and Y-Δ secondaries cancels the 5th and 7th harmonics, leaving 11th, 13th, … on the AC side.
173. The lowest-order characteristic AC-side current harmonic of a 12-pulse converter on a 50 Hz system is at
Show hintHide hint
Harmonic order 12k ± 1.
Show answerHide answer
Answer: C. 550 Hz
Characteristic harmonics are 12k ± 1; the lowest is the 11th: 11 × 50 = 550 Hz.
174. Which of the following is an advantage of HVDC over HVAC transmission?
Show hintHide hint
Which limit depends on line reactance?
Show answerHide answer
Answer: B. No stability limit on transmissible power over long distances
DC transmission has no reactance-based angle stability limit; the other options are actually advantages of AC.
175. Which of the following is a disadvantage of HVDC transmission?
Show hintHide hint
Three of these are problems of AC.
Show answerHide answer
Answer: B. Converters generate harmonics and need reactive power support
Converter harmonics and reactive demand (plus costly terminals and difficult DC breaking) are HVDC drawbacks; the others are AC problems.
176. For underground or submarine cables, HVDC is preferred over AC for long lengths mainly because
Show hintHide hint
Think of cable capacitance at 50 Hz.
Show answerHide answer
Answer: D. DC cables have no continuous capacitive charging current
AC cable charging current grows with length and quickly uses up cable capacity; with DC there is no steady charging current.
177. In the usual control scheme of a two-terminal LCC HVDC link under normal operation, the rectifier and inverter respectively operate on
Show hintHide hint
The inverter must protect against commutation failure.
Show answerHide answer
Answer: B. Constant current control and constant extinction angle control
The rectifier regulates the DC current, while the inverter holds its extinction angle at a minimum safe value to avoid commutation failure.
178. Compared with line-commutated HVDC, a voltage-source-converter (VSC) HVDC system using IGBTs
Show hintHide hint
Self-commutated devices do not need the AC network to turn off.
Show answerHide answer
Answer: A. Can control active and reactive power independently and can supply a weak or dead AC network
Self-commutated VSCs set the magnitude and phase of their AC voltage, giving independent P and Q control and black-start capability.
179. A bipolar HVDC link operates at ±500 kV with a DC current of 2 kA. The power transmitted is
Show hintHide hint
Each pole carries Vd × Id.
Show answerHide answer
Answer: B. 2000 MW
P = 2 × Vd × Id = 2 × 500 kV × 2 kA = 2000 MW.
180. A bipolar ±400 kV HVDC line transmits 1000 MW. Each pole conductor has a resistance of 10 Ω. The total line loss is about
Show hintHide hint
Find the pole current first; two poles carry it.
Show answerHide answer
Answer: D. 31.25 MW
Id = 1000 MW/(2 × 400 kV) = 1250 A; loss = 2 × Id²R = 2 × 1250² × 10 ≈ 31.25 MW.
181. An LCC HVDC rectifier delivers 1000 MW while operating at an effective AC-side power factor of 0.94. The reactive power it absorbs is about
Show hintHide hint
Q = P × tan φ, not P × sin φ.
Show answerHide answer
Answer: D. 363 MVAr
Q = P tan φ; with cos φ = 0.94, tan φ = 0.363, so Q ≈ 1000 × 0.363 ≈ 363 MVAr.
182. The ripple frequency on the DC side of a 12-pulse HVDC converter connected to a 50 Hz AC system is
Show hintHide hint
Pulse number × supply frequency.
Show answerHide answer
Answer: C. 600 Hz
A 12-pulse converter produces 12 pulses per cycle: 12 × 50 = 600 Hz (DC-side harmonics of order 12k).
